TOSHIBA
Satellite ® 2250CDT
!
Part Number: PS225U-N91J08

Product Highlights:

Performance: Intel® Celeron™ processor
600MHz with 100MHz Frontside bus support
and 64MB of SDRAM
Multimedia: 12.1" diagonal TFT active-
matrix color displays; Trident Cyber 9525
Graphics Controller; built-in 24X (max.) CD-
ROM; Toshiba Sound System
Connectivity: Integrated V.90/K56Flex
data/fax modem
All-in-one-design: built-in 24X CD-ROM,
6.0 billion byte HDD and diskette drive –
they're all built in so nothing gets left behind
Toshiba Great
Productivity Tools:
Software Offer
; Toshiba Active Menu,
Toshiba Owner Privileges Offers
VirtualTech
service and support
Processor
Intel® Celeron™ processor 600MHz
Integrated co-processor
128KB on-die internal cache
Data/Address Bus Width: 64-bit/32-bit
100MHz Front side bus
Memory
64MB of SDRAM, 3.3V
Internal memory expansion slot, expandable to
192MB total
BIOS
APM V1.2; ACPI V1.0b; PnP V1.0a; VESA V2.0;
DPMS; DDC2B; SM BIOS V2.3, PCI BIOS V2.1
System Architecture
PCI Bus V2.2
Hard Disk
6.0 billion byte Enhanced IDE, 2.5"
Service removable
9.5 mm height
13ms average access time
Supports Ultra DMA Mode2 (33MB/sec.) or Multiword
DMA Mode2 or PIO Mode4
Diskette Drive
Built-in 3.5", 1.44MB
CD-ROM
Built-in 24x max. speed
130ms average access time
1545/3600 Kb/sec. Maximum data transfer rate
Compatibility: CD-ROM, CD-R (read only), CD-RW
(read only)
Video
Trident Cyber 9525 Graphics Controller
64-bit Graphics Accelerator
AGP bus with sidebands
64 BitBLT hardware
2.5MB internal video memory
Display
12.1" diagonal TFT Active Matrix (800 x 600)
Internal display supports up to 16M colors at 800 x
600
External Color Support
640 x 480: 60/75/85Hz Non-Interlaced @ 16M Colors
800 x 600: 60/75/85Hz Non-Interlaced @ 16M Colors
1024 x 768: 60/75/85Hz Non-Interlaced @ 64K
Colors; 87Hz Interlaced @ 64K
1280 x 1024: 60Hz Non-Interlaced @ 256K Colors;
87Hz Interlaced @ 256K Colors
Audio
ESS1978S on PCI bus
3D sound support with HRTF 3D positional audio
16-bit stereo, .WAV and Sound Blaster® Pro
compatible, MIDI playback
2 built-in stereo speakers
Full duplex sound support
Hardware acceleration for DirectMusic and
DirectSound
Microphone and Headphone ports
Communications
Integrated V.90/K56flex data/fax modem
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice. Copyright 2000 TAIS
Satellite2250CDT.doc Rev. 3 08/01/00
Keyboard
Full sized 85 keys with 12 function keys
2.7mm travel
Dedicated Windows® keys
Integrated AccuPoint® II pointing device with user-
programmable scroll buttons
Expansion
Type III PC Card, supports only one type II or type III
PC Card; 32-bit CardBus ready
15-pin analog SVGA video port
PS/2™ mouse/keyboard port (Y-connector supported)
Universal Serial Bus port
ECP parallel port
High speed serial port (16550 UART equivalent)
Microphone and Headphone jack
RJ-11 telephone port
Dimensions (LxWxH)
12.4" x 10.3" x 1.9"
Weight
6.3 lbs.
Power Supply
45W Autosensing External AC Adapter
and
100-240V input voltage
50-60Hz frequency
4.9"L x .9"H x 2.5"W, .7 lbs
Battery
Rechargeable, removable Lithium Ion battery (10.8V,
4,000mAh)
2.0+ hours battery life
Recharge time: 3 hours unit off / 4-10 hours unit on
ACPI V1.0b support
Battery life may vary depending on applications, power
management settings and features utilized. Recharge time
varies depending on usage.
System Management
ACPI power management
Year 2000 Compliance: NSTL Hardware Tested
Security
Power-on password (2-level password support)
HDD access password
Main system memory modem and internal HDD
security (screws included)
Cable lock slot
Secure Sleep (Screen Blank)
Keyboard Lock
Operating System
Microsoft® Windows 98 Second Edition
Additional Software
AT&T WorldNet Services
Customizable Toshiba/My Yahoo! Start Page
Microsoft Internet Explorer
McAfee ActiveShield
RingCentral™
Satellite Series Online Documentation
Toshiba Custom Utilities
VirtualTech™
Toshiba Great Software Offer
your choice two software titles. The software
selection includes titles from the follow categories:
productivity, education/reference, creativity and
entertainment.
Warranty
1 year parts, labor and battery
Environmental Specifications
Temperature:
O
Operating: 5
to 35
Non-operating: -20
Thermal gradient: 15
O
(operating), 20
operating)
Relative Humidity:
Operating: 20% to 80% non-condensing
Non-operating: 10% to 95% non-condensing
Altitude (relative to sea level):
Operating: -60m to 3,000m (-197' to 9,842')
Non-operating: -60m to 10,000m (-197' to 32,808')
Shock:
Operating: 10G (11ms)
Non-operating: 60G (66ms)
Vibration:
Operating: 0.5G
Non-operating: 1G
Fulfillment: Receive
O
O
O
C (41
to 95
F)
O
O
O
O
to 65
C (-4
to 149
F)
O
C per hour maximum
C per hour maximum (non-
Part Number
PS225U-N91J08
Accessories
KTT-SO100/32
32MB SDRAM memory module
KTT-SO100/64
64MB SDRAM memory module
KTT-SO100/128
128MB SDRAM memory module
PA2444U
Universal AC Adapter (standard)
PA2487URG
Battery Pack (Accessory)
PA2488U
Battery Charger
NWCC38440
Standard CarryAll (Black)
3COMCFE575
3Com 10/100 Ethernet LAN
CardBus Card with RJ-45
3COMMXFE57
3Com 10/100 Ethernet LAN
CardBus Card with XJACK
