Insignia NS-46E440NA14 Quick Setup Manual

A Carefully place your TV face-down on a cushioned, clean surface to protect the screen from damages
QUICK
B Align the front of the stand column with the front of the stand, then insert the column into the base
SETUP GUIDE C Secure the column to the stand with three provided M5 x 12 mm screws.
D Align the stand cover with the column, then secure the cover to the column with one provided
46" LED TV
E Secure the cover to the TV using four M5 × 12 mm screws (provided).
NS-46E440NA14
Thank you
How do I prepare my TV for wall mounting?
for purchasing this state-of-the-art
A Carefully place your TV face-down on a cushioned, clean surface to protect the screen from damages
Insignia television. We hope you enjoy
the quality and reliability of this
B Locate the mounting screw holes on the back of your TV.
television for years to come. C Insert four spacers (provided) into the mount screw holes on the back of your TV, then attach the
Warning: This apparatus is intended to be supported by a UL Listed wall-mount bracket.
FIND YOUR
USER GUIDE ONLINE!
We are going green so a copy of your
User Guide is not provided in the box
but is available online.
Go to www.insigniaproducts.com,
then click Support & Service. Enter your
model number in the box under Manual,
Firmware, Drivers & Product Information,
then click .
START HERE
How do I attach the stand to my TV?
(not for wall mounting)
You'll need: Phillips screwdriver and a soft surface to lay the TV on.
and scratches.
making sure that the grooves in the column align with the ridges in the stand.
M5 × 12 mm screw. Make sure that the bottom of the cover is flush against the top of the column.
- OR -
and scratches.
wall-mount bracket to your TV using the four provided M6 × 25 mm spacer screws or screws that come
with the wall-mount bracket. See instructions that came with the wall-mount bracket for information
about which screws to use and how to correctly hang your TV.
Which cables do you have?
Your TV has several different jacks for connecting devices.
For the best video quality, use the best available
STOP!
connection. Use the cables that came with your devices.
Do not plug your
power cord in until
all other devices have
VIDEO QUALITY
been connected.
BEST
BETTER
Included accessories
GOOD
Remote control GOOD
and two AAA batteries
Note: You can use the HDMI3/DVI jack to connect a DVI device to your TV. Attach an HDMI-to-DVI
adapter to the end of the HDMI cable. The adapter connects to the DVI device's jack. See your
online User Guide for more information about different types of HDMI (ARC, DVI, MHL).
Features
Front view
Stand cover
Stand column
Back view
TV stand
M5 screws
(12 mm length)
(8 pcs.)
Spacers (4 pcs.)
AUDIO/OUT
M6 spacer screws
USB HDMI2/ARC
(25 mm length)
(4 pcs.)
Images do not necessarily represent the exact design of your television.
B
A
(not for use with a TV stand)
MAKING CONNECTIONS
How do I watch TV (cable or satellite receiver) and/or connect a device such as a DVD
or Blu-ray Disc player, game console, MHL-enabled device, Roku Streaming Stick, or camcorder?
Using an HDMI
JACK TYPE CABLE CONNECTOR
cable (BEST)
HDMI video/audio
Component video and analog audio
Composite video and analog audio
Coaxial video/audio
Using component cables (BETTER)
- OR -
Using an AV cable (GOOD)
Remote control sensor
Power indicator
How do I connect my TV to an antenna or cable wall jack?
Y / VIDEO
P B P R L - AUDIO - R
HDMI3/DVI AV/COMPONENT IN
Before using your new product, please read these instructions to prevent any damage.
Stand cover
D
Stand column
C
B C
AUDIO/OUT
HDMI2/ARC HDMI3/DVI
USB
AUDIO/VIDEO OUT
Component cable option
Y / VIDEO P P L - AUDIO - R
B R
/DVI AV/COMPONENT IN
AUDIO/VIDEO
OUT
AV cable option
E
Front
Spacer
Multi-purpose jacks: You can plug
any device that uses HDMI into any
HDMI jack. However, certain devices
must be connected the HDMI ARC,
HDMI DVI, or HDMI MHL jack. See
the instructions that came with your
ARC, DVI, or MHL device for more
information.
Note: The component and AV jacks
are shared. This means you can
connect only one component or AV
device at a time. We suggest using
HDMI if your device supports it.
Note: Connect the yellow video cable
connector to the green Y/VIDEO jack
on the back of your TV.
CABLE
OVER
