Thank you for choosing PPI audio epuipment. Now, HANG ON! PPI
products are engineered and manufactured to deliver a wild ride of
performance, sound quality, and reliability. This PPI product reflects our com-
mitment to offer you versatility and quality for years of incredible power and
listening enjoyment!
SERVICE
Do not attempt to service PPI products yourself. Performing exploratory
surgery on your audio equipment yourself will void the warranty. All parts of
your PPI gear have been built to our specifications. These parts are not made
available to any unauthorized PPI dealer nor are they for sale. Our goal is to
make sure that your PPI product will always perform as good as the day it
was purchased. Contact your authorized PPI dealer about obtaining any war-
ranty service through PPI . (See Warranty inside back cover.)
CAUTION!
The extended use of a high powered audio system may result in hearing loss
or damage. While PPI systems are capable of "Concert Level" volumes, they
are also designed for you to enjoy at more reasonable levels all of the cre-
ative expressions made by musicians. Please stay seated while driving and
observe all local sound ordinances.
Advertisement
Related Manuals for Precision Power PPI4.2
Summary of Contents for Precision Power PPI4.2
- Page 1 Thank you for choosing PPI audio epuipment. Now, HANG ON! PPI products are engineered and manufactured to deliver a wild ride of performance, sound quality, and reliability. This PPI product reflects our com- mitment to offer you versatility and quality for years of incredible power and listening enjoyment! SERVICE Do not attempt to service PPI products yourself.
- Page 2 Please read this entire manual before beginning your installation. If you have questions or do not feel that your installation skills are up to the challenge of installing your new speakers yourself, refer to the authorized PPI retailer that you purchased the speakers from. Your speakers incorporate some or all of the following features: Woven Carbon Fiber Woofer Cones - This rigid and light material provides powerful bass and rich midrange without...
- Page 3 Contents of the PPI series component system include: pair of woofers pair of tweeters pair of passive crossovers pair of 2 piece speaker grilles with adhesive pair of stick-on logos for speaker grilles and pairs of 2 conductor speaker cable with push on speaker terminals 12 mounting screws for woofers and crossover 12 speed clips for woofers and crossover pair of tweeter surface mount plates with appropriate hardware...
- Page 4 PPI4.2 Woofer Size 4 inch Tweeter Size 19 mm Swivel Tweeter Surface and Flush Mounts Tweeter Cup Diameter (for flush mount) 2.04 inches Maximum power handling 80 Watts Nominal power handling 40 Watts Frequency Response 70 Hz - 22 kHz...
- Page 5 PPI5.2 Woofer Size 5.25 inch Tweeter Size 19 mm Swivel Tweeter Surface and Flush Mounts Tweeter Cup Diameter (for flush mount) 2.04 inches Maximum power handling 90 Watts Nominal power handling 45 Watts Frequency Response 60 Hz - 22 kHz Crossover Slope 12 dB/Octave Efficiency @ 1W/1M...
- Page 6 PPI6.2 Woofer Size 6.5 inch Tweeter Size 19 mm Swivel Tweeter Surface and Flush Mounts Tweeter cup Diameter (for flush mount) 2.04 inches Maximum power handling 100 Watts Nominal power handling 50 Watts Frequency Response 40 Hz - 21 kHz Crossover Slope 12 dB/Octave Efficiency @ 1W/1M...
- Page 7 The installation of your PPI component system should be relatively simple, especially if you are replacing factory speakers of the same size. However, if you are installing your speakers where there are not any currently installed or if you are planning to install speakers larger than the factory speakers, the process will be more difficult.
- Page 8 listening to the system with the tweeters in different places until a location is found that sounds best. Mounting locations for the crossovers include the kick panels, between the door panel and the door, or under the seat. The crossovers must be mounted in a dry location where they will not interfere with the operation of the vehicle.
- Page 9 The cables should be connected to the passive crossover, the woofer, and the tweeter as shown on diagram 1. Polarity must be observed on both the speakers and crossover. Now that the cables are in place on the crossover they can be connected to the speakers.
- Page 10 Passive Crossover Tweeter Woofer To Amplifier or Headunit Diagram 1 Diagram 2 2-twist to lock Surface mount Flush mount...
- Page 11 Look for anything that could be damaged such as wiring har- nesses, computers, or brake and fuel lines. Speaker cables will need to be run all the way to the amplifier or head unit when performing a non-factory install. Route the cables safely out of the way of any hazards such as the pedals and levers under the dash.
- Page 12 NO SOUND Is the head unit and / or amplifier on? Check that speaker leads are Check power and remote turn-on wire connected to the speaker and for voltage. Make sure ground wire is head unit or amplifier. secure. ANY SOUND NOW? Check that the speaker leads are not You are done shorted or contacting ground.
- Page 13 Authorized Dealer for assistance with the return and factory repair of your PPI product. If an Authorized Dealer is not available, return the unit including your name, telephone number, return address, a copy of your sales receipt, and a description of the problem to: Precision Power , Inc. Service Department 4829 S. 38th Street...
