GSM TELEPHONE
SGH-E490
GSM TELEPHONE
CONTENTS
1. Specification
2. Exploded View and Parts list
3. Chart of Troubleshooting
4. Array course control
5. Block Diagrams
6. PCB Diagrams
7. MAIN Electrical Parts List
8. Reference data
9. Safety Precautions
10. Product Function

Advertisement

Table of Contents
loading

Related Manuals for Samsung SGH-E490

Summary of Contents for Samsung SGH-E490

  • Page 1 GSM TELEPHONE SGH-E490 GSM TELEPHONE CONTENTS 1. Specification 2. Exploded View and Parts list 3. Chart of Troubleshooting 4. Array course control 5. Block Diagrams 6. PCB Diagrams 7. MAIN Electrical Parts List 8. Reference data 9. Safety Precautions 10. Product Function...

  • Page 2: Table Of Contents

    Contents 1. Specification 1-1. GSM General Specification ..................1-1 1-2. GSM TX power class ....................1-2 2. Exploded View and Parts list 2-1. Cellular phone Exploded View ..................2-1 2-2. Cellular phone Parts list ....................2-2 2-3. Disassembly .......................2-9 2-4. Assembly ........................2-11 3. Chart of Troubleshooting 3-1.
  • Page 3 Contents 4. Array course control 4-1. Downloading Binary Files ..................4-2 4-2. Pre-requsite for Downloading ................4-2 4-3. S/W Downloader Program ..................4-3 5. Block Diagrams 6. PCB Diagrams 7. MAIN Electrical Parts List 8. Reference data 8-1. Reference Abbreviate ....................8-1 9. Safety Precautions 9-1.

  • Page 4: Specification

    1. Specification 1-1. GSM General Specification GSM900 EG SM 900 DCS1 800 PCS190 0 Phase 1 Phase 2 Phase 1 Fr eq. Band [MHz] 890~9 15 880~ 915 1710~1 785 18 50~191 0 Uplink/ Downlink 935~9 60 925~ 960 1805~1 880 19 30~199 0 0~ 124 &...

  • Page 5: Gsm Tx Power Class

    Speclflcation 1-2. GSM Tx Power Class TX Power TX Power TX Power GSM900 DCS1800 PCS1900 control level control level control level 33±2 dBm 30±3 dBm 30±3 dBm 31±2 dBm 28±3 dBm 28±3 dBm 29±2 dBm 26±3 dBm 26±3 dBm 27±2 dBm 24±3 dBm 24±3 dBm 25±2 dBm...

  • Page 6: Exploded View And Parts List

    QLC01 QMO01 QSH01 QCB01 QAR01 QMP01 QCA01 QAN02 QHI01 QSD01 QCK01 QRE01 QFL01 QRF03 QVO01 QCR05 QSC07 QSC05 QBA01 QMW01 QRF01 QCR04 QBC01 QBC02 QBC06 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 7: Cellular Phone Parts List

    MPR-TAPE LOWER L GH74-26669A QSH01 IPR-SHEILD COVER GH70-01860A QSP01 SPEAKER_yellow 3001-002071 QSP02 SPEAKER_Blue 3001-002080 QFR01 ASSY CASE-FRONT GH98-02199A QMI03 ASSY COVER-MIC HOLDER GH98-03236A QFL01 ASSY CASE-LOWER GH98-02200A SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 8 QCR57 SCREW-MACHINE 6001-002001 QRE01 ASSY CASE-REAR GH98-02215A QCK01 PMO-CAMERA KEY GH72-36437A QRF03 PMO-COVER EAR JACK GH72-34107A QSD01 PMO-MICRO SD COVER GH72-36594A QVO01 PMO-KEY VOLUME GH72-34110A SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 9 MPR-TAPE LOWER R GH74-26669A QSC06 MPR-TAPE LOWER L GH72-36594A QSD01 PMO-MICRO SD COVER GH70-01860A QSH01 IPR-SHEILD COVER 3001-002071 QSP01 SPEAKER 3001-002080 QSP02 SPEAKER GH72-34110A QVO01 PMO-KEY VOLUME SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 10 RMO-RUBBER PBA A GH73-08606A RMO-RUBBER PBA B GH74-28709A MPR-GASK TAPE GH73-09056A RMO-RUBBER INTENNA GH73-09072A RMO-RUBBER PBA C GH97-06285A MEA FRONT-COVER E490(OPEN) GH74-26663A MPR-FRONT LABEL GH74-29017A MPR-INSU TAPE SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 11 GH74-29725A MPR-TAPE RCV HOLE GH73-09178A RMO-RUBBER LOWER GH74-26586A MPR-SPONGE CAMERA GH74-26665A MPR-TAPE UPPER DUMMY GH74-28513A MPR-TAPE CAMERA DECO GH71-07148A NDC-FOLDER UPPER GH72-36555A PMO-FOLDER UPPER BOTTOM SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 12 MPR-INSU TAPE LCD C GH74-30542A MPR-VINYL BOHO AUTO GH68-02026A LABEL(P)-WATER SOAK GH74-28143A MPR-SPONGE KEY CON GH74-29014A MPR-GASK TAPE GH61-00292A SPRING ETC-BATT LOCKER GH72-36593A PMO-REAR COVER GH72-36595A PMO-BATT LOCKER SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 13 MPR-VINYL BOHO MAIN GH72-36722A PMO-BATT COVER V4 GH74-28760A MPR-VINYL BOHO COVER GH74-30396A MPR-TAPE GATE GH72-36722B PMO-BATT COVER V4 GH74-28760A MPR-VINYL BOHO COVER GH74-30396B MPR-TAPE GATE SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 14: Disassembly

    1. Take off a FRONT LABEL. 2. Be caredful that you do not make scratch 2. Separate Antenna and RF cable from Unit. when you press down a Hinge. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 15 1. Seperate UPPER from LOWER. - Release a HOOK which locate upside. ※ caution 1. Be careful Hook damage when you disjoint a REAR. 1. DONE 2-10 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 16: Assembly

    2. Be caredful that you do not make scratch when you assemble a Hinge. Left Right 3. Check folder Tention and F-PBC connected with accuracy. 2-11 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 17 SIDE KEY of REAR) with accuracy. 2. Press Antenna part horizontally. 4. Chack RF CABLEconnected with accuracy. 3. Check GAP is exist after finish assembly. 2-12 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 18: Chart Of Troubleshooting

    Check C384 of U302 U302=1.8V Check UCD301 and C315 Check VRF of UCD301=2.9V Check Pin #8 of U101 Check U101 Freq=13Mhz, Vpp>0.4V Check the initial operation SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 19 Flow Chart of Troubleshooting and Circuit Diagrams SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 20 VEXT VBAT C321 CH_BDRV VCCB_2.9V CH_ISEN CH_RES ICHRG U301 ADC_AUX2 ADC_AUX1 R301 VREF CREF E9 RTC_ALMN C333 C332 R302 C334 22nF R304 3.3K,1% 6.3V RTCALARM SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 21 C111 R101 C110 CLK13M_TR R102 C112 CLK13M_MC _RES XOUT CLK13M_WM R104 R105 RTXIP RTXIN RTXQP RTXQN SCLK SERCLK SDIO SERDAT _SEN SERLE C121 C122 C123 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 22: System Initial

    Check the VCCD_1.8V of Check U302 U302 is "High" LCD display is O.K? Check CN301 and LCD part Check Audio part Sound is O.K? SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 23 CAM_DATA(2) CAM_DATA(1) 1 IN1 OUT1 SUBLCD_CS CAM_DATA(0) LED_R 2 IN2 OUT2 MLCD_CS LCD_RD LED_G LED_B RCV+ 3 IN3 OUT3 LCD_WEN EL_EN RCV- OUT4 LCD_ADS C373 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 24: Sim Part

    Check the related circuit of SIM300 Check the related circuit of SIM300 Check the circuit around U300 output and Check the related circuit of UCD300 voltage supply circuit SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 25 Flow Chart of Troubleshooting and Circuit Diagrams SIM300 VSIM SIM_RST SIM_CLK SIM_IO C305 C306 C307 C308 C309 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 26: Charging Part

    Flow Chart of Troubleshooting and Circuit Diagrams 3-1-4. Charging Part Abnormal charging part Battery contact at BTC400 Battery Check BTC400 Charger input of IFC400 Check the IFC400 3-10 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 27 15 15 JIG_ON_IF USB_D+ 17 17 USB_D- 19 19 NC 25 C407 24 NC NC 28 ZD401 ZD400 C411 C412 C413 C414 SDS_TXD_J SDS_RXD_J JIG_ON_J 3-11 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 28: Microphone Part

    Check the assembled status of Reassemble microphone microphone Check the reference voltage on Resolder or Change mic path R411=2.9V (R411,R414,R416,R418,R420,R421, R422,C404,C405,C406,C408,C410) Is Microphone O.K? Check UCD301 3-12 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 29 Flow Chart of Troubleshooting and Circuit Diagrams 3-13 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 30 Flow Chart of Troubleshooting and Circuit Diagrams VCCA_2.9V R411 R414 R418 MICINP MIC+ MICOUTP C405 C404 R416 C406 R420 MICINN MIC- MICOUTN C408 TA401 R422 R421 C410 3-14 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 31: Speaker Part

    U401 = "High" Check the pin #4,6,16,18 of Change the U401 U401 Change or Resolder Check the L400,L401,L402,L403 L400,L401,L402,L403 Is Speaker O.K? Change the LCD module 3-15 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 32 Flow Chart of Troubleshooting and Circuit Diagrams 3-16 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 33 C452 VCCD_2.9V U403 1 V+ WM_SN 2 NO1 COM2 9 WM_SP AOUTBN COM1 AOUTBP 4 IN1 ASW_SPEAKER AOUT_SW_N 5 NC1 GND 6 AOUT_SW_P R428 3-17 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 34: Camera Part

    Is that clock signal at the pin # Check OSC400 B2 of U400=27Mhz Check the F301,F302 Change F301,F302 Is Camera function O.K? Change the Board 3-18 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 35 Flow Chart of Troubleshooting and Circuit Diagrams 3-19 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 36 OUT4 CAM_DATA(3) CAM_D(3) GND GND F301 IN1 1 OUT1 CAM_DATA(4) CAM_D(4) OUT2 CAM_DATA(5) CAM_D(5) IN3 3 OUT3 CAM_DATA(6) CAM_D(6) OUT4 CAM_DATA(7) CAM_D(7) 9 10 3-20 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 37: Lcd

    Have a some problem of Replace the connector(CN301) connector (CN301) Display is not Check the UCD301 Check the pin #J2,J7,G3,H3,J3 Backlight does work of U400 3-21 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 38 Flow Chart of Troubleshooting and Circuit Diagrams 3-22 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 39: Egsm Rx

    Resolder or Change OSC100 26Mhz Check the pin #4,5,6,7 of U101 Resolder or Change U101 Vp-p=100mV GSM RX path component GSM Receiver is O.K? resolder or change 3-23 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 40: Dcs Rx

    Resolder or Change OSC100 26Mhz Check the pin #4,5,6,7 of U101 Resolder or Change U101 Vp-p=100mV GSM RX path component GSM Receiver is O.K? resolder or change 3-24 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 41: Pcs Rx

    Resolder or Change OSC100 26Mhz Check the pin #4,5,6,7 of U101 Resolder or Change U101 Vp-p=100mV GSM RX path component GSM Receiver is O.K? resolder or change 3-25 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 42 Flow Chart of Troubleshooting and Circuit Diagrams 3-26 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 43: Egsm Tx

    Check pin #1,2,3,4 Check pin #34,35 Check and Change of U101 = 1.7V of U101=26Mhz OSC100 Check and Change Check and Change Change UCD301 U101 U101 3-27 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 44: Dcs & Pcs Tx

    Check pin #34,35 Check and Change of U101 = 1.7V of U100 = 26Mhz OSC100 Check and Change Check and Change Change UCD301 U101 U101 3-28 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 45 Flow Chart of Troubleshooting and Circuit Diagrams 3-29 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 46: Bluetooth

    Pin #3 of Q100 = 1.8V Resolder Q100 Check pin #12 of Resolder MOD100 MOD100 ≥ -6dBm Check the signal of ANT100 Resolder ANT100 3-30 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 47 Flow Chart of Troubleshooting and Circuit Diagrams 3-31 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 48: Array Course Control

    4. Array course control Test Jig (GH80-03307A) Test Cable (GH39-00484A) RF Test Cable (GH39-00397A) SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 49: Software Downloading

    • Three binary files for downloading E900. – E490XXYY.s3 : Main source code binary. 4-2. Pre-requsite for Downloading • Downloader Program(OptiFlash.exe) • E490 Mobile Phone • Data Cable • Binary files SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 50: S/W Downloader Program

    2. Select the “Options” -> “Settings” -> “Generic” -> “Specify hardware platform ”. Choose hardware platform for the downloader file setting. Set the everything else as the default values which are shown below SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 51 4. Select the“ Flash&Verify” -> “Browse ” Set the directory path and choose the latest s/w binary, for example “ X810XXYY.s3”, for the downloader binary setting. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 52 7. After finishing downloading, Certain memory resets should be done to guarantee the normal performance. 8. Confirm the downloaded version name and etc. : *#1234# Full Reset : *2767*3855# SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 53: Block Diagrams

    5. Block Diagrams SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 54 Block Diagrams SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 55: Pcb Diagrams

    CN201 CN301 U305 U403 TA404 UCD401 TA405 TA406 U302 TP205 TP203 TP200 TP206 TP202 TP201 TP204 U204 U201 U202 U401 SIM300 ZD402 TA400 RFS101 RFS100 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 56 PCB Diagrams TA403 MOD100 Q100 IFC400 U301 V403 V402 U205 OSC100 F100 U400 F101 OSC400 F102 TP216 UCP201 BTC400 U203 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 57: Main Electrical Parts List

    C-CER,CHIP 2203-005288 C126 C-CER,CHIP 2203-005682 C127 C-CER,CHIP 2203-006194 C129 C-CER,CHIP 2203-006423 C130 C-CER,CHIP 2203-006423 C131 C-CER,CHIP 2203-006562 C132 C-CER,CHIP 2203-006423 C133 C-CER,CHIP 2203-006423 C134 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 58 C-CER,CHIP 2203-005482 C224 C-CER,CHIP 2203-005482 C225 C-CER,CHIP 2203-006562 C226 C-CER,CHIP 2203-006423 C227 C-CER,CHIP 2203-000254 C228 C-CER,CHIP 2203-006423 C229 C-CER,CHIP 2203-001153 C300 C-CER,CHIP 2203-006423 C301 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 59 C-CER,CHIP 2203-006562 C339 C-CER,CHIP 2203-005682 C340 C-CER,CHIP 2203-006562 C341 C-CER,CHIP 2203-005683 C356 C-CER,CHIP 2203-005682 C357 C-CER,CHIP 2203-005682 C358 C-CER,CHIP 2203-005682 C359 C-CER,CHIP 2203-005682 C360 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 60 C-CER,CHIP 2203-006562 C414 C-CER,CHIP 2203-006194 C415 C-CER,CHIP 2203-006562 C416 C-CER,CHIP 2203-000627 C417 C-CER,CHIP 2203-000627 C418 C-CER,CHIP 2203-006423 C419 C-CER,CHIP 2203-005482 C420 C-CER,CHIP 2203-006562 C421 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 61 CN301 HEADER-BOARD TO BOARD 3711-005345 CN303 HEADER-BOARD TO BOARD 2904-001602 F100 FILTER-SAW 2904-001628 F101 FILTER-SAW 2904-001604 F102 FILTER-SAW 2904-001600 F103 FILTER-SAW 2901-001422 F301 FILTER-EMI SMD SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 62 CRYSTAL-SMD 2801-004340 OSC400 CRYSTAL-SMD 1203-003688 Q100 IC-POSI.FIXED REG. 1203-003737 Q400 IC-POSI.FIXED REG. 1203-003737 Q401 IC-POSI.FIXED REG. 2007-008056 R100 R-CHIP 2007-008548 R101 R-CHIP 2007-008048 R102 R-CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 63 R-CHIP 2007-001323 R300 R-CHIP 2007-000775 R301 R-CHIP 2007-009167 R302 R-CHIP 2007-007316 R304 R-CHIP 2007-008055 R306 R-CHIP 2007-009170 R308 R-CHIP 2007-008483 R309 R-CHIP 2007-000162 R311 R-CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 64 R-CHIP 2007-009157 R416 R-CHIP 2007-009115 R417 R-CHIP 2007-007741 R418 R-CHIP 2007-008531 R419 R-CHIP 2007-007741 R420 R-CHIP 2007-009157 R421 R-CHIP 2007-008590 R422 R-CHIP 2007-009084 R423 R-CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 65 C-TA,CHIP 2404-001352 TA406 C-TA,CHIP 2404-001352 TA407 C-TA,CHIP 1201-002457 U100 IC-POWER AMP 1205-003093 U101 IC-TRANSCEIVER GH71-07065A U102 NPR-SHEILD FRAME 0406-001200 U201 DIODE-TVS 1203-003789 U202 IC-POWER SUPERVISOR SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 66 1405-001082 V403 VARISTOR 1405-001082 VR200 VARISTOR 0406-001167 ZD302 DIODE-TVS 0406-001167 ZD303 DIODE-TVS 0403-001411 ZD400 DIODE-ZENER 0406-001190 ZD401 DIODE-TVS 0403-001547 ZD402 DIODE-ZENER 0406-001190 ZD403 DIODE-TVS 7-10 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 67: Reference Data

    PS : Pilot Symbol QPSK: Quadrature Phase Shift Keying RS : Reed-Solomon SI : Service Information TDM : Time Division Multiplexing TS : Transport Stream SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 68: Safety Precautions

    ● Don't use as you pleases after change other material than replacement registered on SEC System. Otherwise engineer in charge isn't charged with problem that you don't keep this rules. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 69: Esd(Electrostaically Sensitive Devices) Precaution

    ● You must maintain electric contact between ESD and place due to be set up until ESD is connected completely to the proper place or a circuit board. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 70: Product Function

    - Java - Offline mode - Bluetooth - Web browser - Multimedia Message Service(MMS) - Name card - Alarm - Voice recorder - Organiser 10-1 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 71 This Service Manual is a property of Samsung Electronics Co.,Ltd. Samsung Electronics Co.,Ltd. ⓒ Any unauthorized use of Manual can be punished under applicable International and/or domestic law. 2007. 01. Rev.1.0...
