GSM TELEPHONE
Schematics & manuals on www.mobilchips.com
GSM TELEPHONE
SGH-E860V
1.
Specification
2.
Flow Chart of Troubleshooting
3.
Exploded Views and Parts List
4.
Electrical Parts List
5.
PCB Diagrams
6.
Block Diagrams
___Mobilchips__
CONTENTS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SGH-F860V and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung SGH-F860V

Summary of Contents for Samsung SGH-F860V

  • Page 1 GSM TELEPHONE SGH-E860V GSM TELEPHONE CONTENTS Specification Flow Chart of Troubleshooting Exploded Views and Parts List Electrical Parts List PCB Diagrams Block Diagrams Schematics & manuals on www.mobilchips.com ___Mobilchips__...

  • Page 2: Gsm General Specification

    1. SGH-E860V Specification 1-1. GSM General Specification GSM900 E G S M 9 00 DCS1800 PC S1 90 0 Ph ase 1 Ph ase 2 Ph ase 1 Freq. Ban d [M Hz ] 89 0~ 91 5 88 0~ 91 5 1 71 0~ 1 78 5 18 50 ~1 91 0 Upl in k/Downl in k...

  • Page 3: Gsm Tx Power Class

    SGH-E860V Speclflcation 1-2. GSM Tx Power Class TX Power TX Power TX Power GSM900 DCS1800 PCS1900 control level control level control level 33±2 dBm 30±3 dBm 30±3 dBm 31±2 dBm 28±3 dBm 28±3 dBm 29±2 dBm 26±3 dBm 26±3 dBm 27±2 dBm 24±3 dBm 24±3 dBm...

  • Page 4: Flow Chart Of Troubleshooting

    Flow Chart of Troubleshooting 2. SGH-E860V 2-1 BASEBAND 2-1-1. Power ON 'Power ON' does not work check the current consumption Download again >= 100mA Check the Voltage of the Battery Charge the battery >= 3.3V Check the pin C417 Check check keypad of U401 is "Power On"...
  • Page 5 SGH-E860V Flow Chart of Troubleshooting Vccd_2.8 Vcca_2.8 Vrf_2.9 Vccd_1.8 C400 C401 C402 C403 Vbat Ear_check C408 Vdd34 Dsp_db(0:15) Vdd12 Dsp_db(15) Simclk Db15 Up_clk Dsp_db(14) Simrst Db14 Up_rst Dsp_db(13) Db13 Up_io Simdata Dsp_db(12) Sim_io Db12 Sim_io Dsp_db(11) Vrtc_1.5 Sim_rst Db11 Sim_rst Dsp_db(10) Sim_clk Db10...
  • Page 6 SGH-E860V Flow Chart of Troubleshooting 2-1-2. Initial Initial Failure Check the U401 The voltage at the C417=1.8V? (If it has some problem, The voltage at the C420=2.8V? it has to be replaced Check the U401 The voltage at the V509 (If it has some problem, it has to be replaced ) "...
  • Page 7 SGH-E860V Flow Chart of Troubleshooting...
  • Page 8 SGH-E860V Flow Chart of Troubleshooting VCCD_1.6 VCCD_1.8 VRTC_1.5 C200 C208 C201 C202 C203 C204 C205 C206 C207 CLK13M_TR R210 A(1:24) B7 A_A0 DSP_TMS A(0) A(1) C8 A_A1 TDO T12 DSP_TDO A(2) D8 A_A2 DSP_TDI A(3) A6 A_A3 DSP_TCK A(4) R211 A_A4 CKO_IACK A(5)

  • Page 9: Sim Part

    SGH-E860V Flow Chart of Troubleshooting 2-1-3. Sim Part "Insert SIM" is displayed on the LCD The voltage is 2.8V Check the U401 at the pin#1 of CN400 Is there any signal Check the U401 & U200 pin #2,3,4 of CN400? Check the SIM Card Cn400 Vsim...

  • Page 10: Microphone Part

    SGH-E860V Flow Chart of Troubleshooting 2-1-4.Microphone Part * Call with Sim before testing. MicroPhone does not work Check the soldered Resolder microphone status of microphone Check the reference Resolder or change voltage on mic path C360, C361, R349, R328, R329 C360 ≒...
  • Page 11 SGH-E860V Flow Chart of Troubleshooting VCCA_2.8 R349 C360 C361 AGND R328 C332 R323 MICINP MAIN_MIC_P R324 MICOUTP C334 R325 MICINN MAIN_MIC_M R326 MICOUTN C340 C339 R329 AGND AGND AGND MIC300 MIC+ C333 MIC- C335 C336 AGND AGND V300 V307...

  • Page 12: Bluetooth Part

    SGH-E860V Flow Chart of Troubleshooting 2-1-5.Bluetooth Part When you play MPEG file, if Audio is not active Bluetooth does not work Check C123 = 1.8V? Resolder U103 Check pin22 of U102 Resolder U102 ≥ 1.5 dbm ? Change CN101...
  • Page 13 SGH-E860V Flow Chart of Troubleshooting CN101 VBT_1.8 U102 R107 RESETB DEBUG_CTS PCM_CLK UART_CTS PCM_CLK DEBUG_RTS PCM_IN UART_RTS PCM_IN DEBUG_TXD PCM_OUT UART_RX PCM_OUT DEBUG_RXD PCM_SYNC UART_TX PCM_SYNC VDD_1.8V PIO_0 VDD_REG PIO_1 VDD_UART PIO_2 PIO_3 PIO_4_UART_TX2 PIO_5_UART_RTS2 PIO_6_UART_CTS2 PIO_7_UART_RX2 C124 C128 C130 VBAT U103 VBT_1.8...

  • Page 14: Speaker Part

    SGH-E860V Flow Chart of Troubleshooting 2-1-6. Speaker Part There is no sound from speaker Check the connection status of speaker module reconnect speaker module to CN103 to CN103(LCD PCB) Are there any signal at the C148,C149? Replace the speaker module (LCD PCB) The type of sound from the speaker is Melody?
  • Page 15 SGH-E860V Flow Chart of Troubleshooting LCD PCB 2-12...
  • Page 16 SGH-E860V Flow Chart of Troubleshooting VCCD_2.8 VBAT VCCD_1.8 C500 C501 C511 CN500 R501 BLCD_RD SVC_WHITE BL_ADS BLCD_D(0) BLCD_D(1) BLCD_D(2) BLCD_D(3) BLCD_D(4) BLCD_D(5) BLCD_D(6) BLCD_D(7) BLCD_D(8) BLCD_D(9) BLCD_D(10) BLCD_D(11) BLCD_D(12) BLCD_D(13) BLCD_D(14) BLCD_D(15) BMLCD_CS BLCD_WEN KEY_ROW(0) KEY_ROW(1) KEY_COL(0) KEY_COL(1) KEY_COL(2) KEY_COL(3) KEY_COL(4) BACKLIGHT_EN VIB_EN...
  • Page 17 SGH-E860V Flow Chart of Troubleshooting VBAT C125 U110 1 V+ MELODY- 2 NO1 COM2 9 MELODY+ SPK1N COM1 SPK1P 4 IN1 AMP_SHDN AUDIO_N 5 NC1 GND 6 AUDIO_P 12 13 VBAT U104 L101 VOM A3 MELODY- C153 R126 A1 VIP PVSS C133 AMP_IN+...
  • Page 18 SGH-E860V Flow Chart of Troubleshooting VBAT V_AUDIO_3.3 F300 R348 C322 R350 MSPK+ AMP_IN+ LOUT D4 12 EAR_L R351 1 1S2 R319 U302 MP3+ AOUTBN 3-4IN 10 2 1-2IN AUDIO_OUT_SEL EAR_OUT_SEL R352 MSPK- ROUT 4 D2 AMP_IN- C329 R342 R353 MP3- EAR_R R322 AOUTBP...

  • Page 19: Camera Part

    SGH-E860V Flow Chart of Troubleshooting 2-1-7. Camera Part Camera function does not work Check the connection Connect the CN105 precisely CN105?(LCD PCB) Check C163 = 1.6 V Resolder U101 (LCD PCB) C136 = 2.8 V ? (LCD PCB) Is there any signal Is there any signal at L105, L106? pin #41,42,43,44,45,...
  • Page 20 SGH-E860V Flow Chart of Troubleshooting 2-17...
  • Page 21 SGH-E860V Flow Chart of Troubleshooting VCCD_1.8 VDD_TV_3.3 VCCD_2.8 VDD_AC_2.8 L303 C311 C310 C317 C309 C358 C363 C370 A(1) A(2) M_SA0 S_SCK M_SA1 S_MOSI D[0:15] M_SA2 S_MISO D(0) LCD_D[0:15] M_SD0 S_SSN D(1) M_SD1 D(2) LCD_D(0) M_SD2 L_DA0 D(3) LCD_D(1) M_SD3 L_DA1 D(4) LCD_D(2) M_SD4...
  • Page 22 SGH-E860V Flow Chart of Troubleshooting CAM1.5VD CAM2.8VD CAM2.8VD R102 L100 CN105 M_CLK HOR_REF VER_REF P_CLK BCAM_D(0) BCAM_D(1) 11 11 BCAM_D(2) 13 13 15 15 BCAM_D(3) BCAM_D(4) 19 19 CAM_RST BCAM_D(5) BCAM_D(6) BCAM_D(7) 23 23 C107 C164 C104 C105 ZD103 ZD102 ZD101 VRF_2.9 C120...

  • Page 23: Lcd Backlight

    SGH-E860V Flow Chart of Troubleshooting 2-1-8. LCD backlight Backlight does not work Backlight ON "TIME" Select backlight "15 sec" mode mode in the menu? Check conecting between PBA and LCD Check FPCB conector Check CN102 pin 26 = Check the LCD 10V ? (PCB LCD) 2-20...
  • Page 24 SGH-E860V Flow Chart of Troubleshooting 2-2 RF 2-2-1. GSM Rx CONTINOUS RX ON RF INPUT : 62CH AMP : -50dbm Normal condition catch the Check ANT, C112,144,L100 channel ? Check F100 Resolder or change pin 6 ≥ -65 CN100, C109 dbm ? Check F100 Resolder or change...
  • Page 25 SGH-E860V Flow Chart of Troubleshooting 2-22...
  • Page 26 SGH-E860V Flow Chart of Troubleshooting 2-2-2. DCS Rx CONTINOUS RX ON RF INPUT : 698CH AMP : -50dbm Normal condition catch the Check ANT, C112,144,L100 channel ? Check F100 Resolder or change pin 6 ≥ -65 dbm ? CN100, C109 Check F100 Resolder or change pin 12,13 ≥...
  • Page 27 SGH-E860V Flow Chart of Troubleshooting 2-24...
  • Page 28 SGH-E860V Flow Chart of Troubleshooting 2-2-3. PCS Rx CONTINOUS RX ON RF INPUT : 660CH AMP : -50dbm Normal condition Check ANT, C112,144,L100 catch the channel ? Check F100 Resolder or change pin 6 ≥ -65 dbm ? CN100, C109 Check F100 Resolder or change pin 14, 15 ≥...
  • Page 29 SGH-E860V Flow Chart of Troubleshooting 2-26...
  • Page 30 SGH-E860V Flow Chart of Troubleshooting CN100 DCS_TX_EN C106 C112 ANT1 ANT_GND L100 C144 GSM_TX_EN C109 C110 L108 F100 C114 EGSMTX 3 CONT2 EGSMRX1 11 CONT1 GSM_LNA_IN_P EGSMRX2 DCSTX1 L101 PCSRX1 DCSRX1 C115 14 PCSRX2 DCSRX2 GSM_LNA_IN_N 17 19 20 C116 DCS_LNA_IN_P L104 C117...
  • Page 31 SGH-E860V Flow Chart of Troubleshooting 2-2-4. GSM Tx CONTINUS TX ON CONDITION TX POWER DAC : 554 CODE APPLIED CH : 62ch RBW : 100KHz Check F100 Check and VBW : 100KHz Check F100 pin 3 : about change SPAN : 10MHz pin 4 : 2.8V ? 2~3 dbm? U200,U401...
  • Page 32 SGH-E860V Flow Chart of Troubleshooting 2-2-5. DCS/PCS Tx CONTINUS TX ON CONDITION TX POWER DAC : 560 CODE Check F100 Check and APPLIED Check F100 pin 1 : about change CH : 698CH(DCS), pin 2 : 2.8V ? 2~3 dbm? 660CH(PCS) U200,U401 RBW : 100KHz...

  • Page 33: Cellular Phone Exploded View

    QCA01 QSR03 QKP01 QME04 QMO01 QME01 QKP02 QMI01 QAN02 QLC01 QME02 QCK01 QVO01 QMP02 QRF01 QRE01 QCR47 QRF03 QFL01 QCR49 QCR04 QIF01 QSC01 QCR05 QBA01 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 34: Cellular Phone Parts List

    QCR47 SCREW-MACHINE;BH,+,M1.4,L2,ZPC(WHT), 6001-001695 　 QCR49 SCREW-MACHINE;CH,+,M1.4,L2,NI PLT,SW 6001-001823 QMP02 　 PBA SUB-SGHE860V;SGH-E860V,VDF,EU,PB GH92-02213A QME02 　 UNIT-METAL DOME(SUB);SGH-E860V,9KW95 GH59-01980A QLC01 　 ELA UNIT-SGHE860V LCD MODULE;SGH-E86 GH96-01813A SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 35 MPR-BOHO VINYL WINOW 1;SGH-E860V,ELE GH74-15917A MPR-BOHO VINYL WINOW 2;SGH-E860V,3M GH74-15918A MPR-LCD DOME EMI TAPE R;SGH-E860V,DT GH74-16891A MPR-TAPE LED INSULATION;SGH-E860V,PE GH74-16894A MEC-HANGER;SGH-Z500,TMN,STRAP,-,BLK, GH75-03673H MEC-SUB SLIDE LOWER;SGH-E860V,VODA,E GH75-07479A SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 36 3-3. Test Jig (GH80-00865A) 3-3-1. RF Test Cable 3-3-2. Test Cable 3-3-3. Serial Cable (GH39-00283A) (GH39-00127A) 3-3-4. Power Supply Cable 3-3-5. DATA CABLE 3-3-6. TA (GH39-00331A) (GH44-00954A) SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 37: Electrical Parts List

    IC-DC/DC CONVERTER 2203-005571 C435 C-CER,CHIP 1203-003565 U401 IC-POWER SUPERVISOR 2203-005682 C406 C-CER,CHIP 1203-003754 U402 IC-POSI.FIXED REG. 2203-005682 C407 C-CER,CHIP 1204-002138 U400 IC-MELODY 2203-005682 C409 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 38 C-CER,CHIP 2007-000157 R201 R-CHIP 2203-006194 C205 C-CER,CHIP 2007-000162 R332 R-CHIP 2203-006194 C207 C-CER,CHIP 2007-000163 R324 R-CHIP 2203-006194 C210 C-CER,CHIP 2007-000163 R326 R-CHIP 2203-006194 C337 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 39 C-CER,CHIP 2007-007009 R208 R-CHIP 2203-006423 C348 C-CER,CHIP 2007-007009 R209 R-CHIP 2203-006423 C370 C-CER,CHIP 2007-007014 R403 R-CHIP 2203-006423 C402 C-CER,CHIP 2007-007142 R314 R-CHIP 2203-006423 C403 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 40 INDUCTOR-SMD 2007-008419 R508 R-CHIP 2703-002313 L301 INDUCTOR-SMD 2007-008419 R510 R-CHIP 2703-002313 L302 INDUCTOR-SMD 2007-008419 R517 R-CHIP 2703-002547 L104 INDUCTOR-SMD 2007-008483 R107 R-CHIP 2703-002665 L105 INDUCTOR-SMD SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 41 2203-000359 C335 C-CER,CHIP GH74-12612A MPR-MAIN FPCB SHIELD EMI 2203-000359 C336 C-CER,CHIP GH74-12813A MPR-MAIN GROUND EMI TAPE 2203-000386 C214 C-CER,CHIP GH74-16894A MPR-TAPE LED INSULATION 2203-000386 C215 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 42 C-CER,CHIP 2007-000143 R102 R-CHIP 2203-006423 C115 C-CER,CHIP 2007-000161 R103 R-CHIP 2203-006423 C117 C-CER,CHIP 2007-000161 R104 R-CHIP 2203-006423 C119 C-CER,CHIP 2007-000174 R134 R-CHIP 2203-006423 C122 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 43 2203-000254 C152 C-CER,CHIP GH74-12604A MPR-MAIN FPCB TAPE 2203-000254 C153 C-CER,CHIP GH74-12606A MPR-LCD DOME EMI TAPE R 2203-000812 C148 C-CER,CHIP GH74-16891A MPR-LCD DOME EMI TAPE R SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 44: Pcb Diagrams

    5. SGH-E860V PCB Diagrams 5-1. Main ANT1 ANT_GND V306 V305 V303 F100 V302 U303 U101 U304 V409 U305 U401 TH400 OSC200 U201 TP304 U404 U103 U202 CN400 U102 CN101 U405 CN503 V506 ZD500 V300 V307 TP306 C510 MIC300 CN501 5- 4...
  • Page 45 SGH-E860V PCB Diagrams ZD301 U306 CN500 TP404 F200 U203 F500 F501 F507 F508 V406 V404 V408 TP403 F502 V405 V407 TP402 TP401 U302 U400 V400V401 DSP_TDI DSP_RWN DSP_TCK GND1 DSP_TDO SHARP DSP_TMS V403 ZD505 U402 V402 5- 2...
  • Page 46 SGH-E860V PCB Diagrams 5-2. LCD U106 CN103 CN105 D103 U101 U103 U107 U100 CN104 U109 5- 3...
  • Page 47 SGH-E860V PCB Diagrams CONFIRM V107 V105 LED101 LED103 DOWN SEND 5- 4...

  • Page 48: Block Diagrams

    Sound Generator OSC13M 3.1V CAMERA CTRL LDOs Audio 1.8V with Flash melody Switch AK4640 SAPA1D1 MP3, CTRL MP3 Decorder Audio AMP Audio melody Switch Data, clock SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 49 ⓒ This Service Manual is a property of Samsung Electronics Co.,Ltd. Samsung Electronics Co.,Ltd. Any unauthorized use of Manual can be punished under applicable International and/or domestic law. Code No.: GH68-07384A 2005. 08. Rev.1.0...
