Summary of Contents for Frontier Lite/Pro
- Page 1 ’ ’...
- Page 2 Thank you for purchasing our Frontier Touch Terminal. This terminal offers highly enhanced features, with easy connection to various optional devices for optimal performance. This user manual describes how to setup and connect your terminal. © Copyright 2006 All rights reserved. This product and related documentation are protected by copyright and are distributed under licenses restricting their use, copying, and distribution.
- Page 3 Preface • Keep this manual for future reference. • Keep this equipment from moisture and dust. • Place the equipment on a stable surface before setting it up. • If there is any of the following situation arise, notify a qualified service technician immediately: The power cord or plug is damaged.
- Page 4 This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: • This device may not cause harmful interference. • This device must accept any interference received including interference that may cause undesirable operation. This equipment has been tested and found to comply within the limit of a Class A digital device, pursuant to Part 15 of the FCC Rules.
-
Page 5: Table Of Contents
Chapter 1 ...1 Welcome ... 1 Overview of Frontier ULV... 1 Rear View ... 2 OSD Control Buttons ... 3 Features ... 4 Unpacking ... 5 Chapter 2 ...6 Getting Started ... 6 Pre-installation Notice... 6 Default Setting ... 6 Limitations ... -
Page 6: Welcome
Congratulations on your purchase of this POS terminal. Your easy-to-use POS terminal is designed to help you enhance your business flexibility by offering a superior customer experience. ULV Lite Counter space-saver Model Lite VIA Eden 1GHz (Fan-less) Chipset 2.5” x 1 Storage devices 3 (Touch &... -
Page 7: Chapter 1
Chapter 1 — Welcome The rear panel view, with the input and output ports, is shown in the illustration. Upper I/O Ports (ULV Lite/ Pro) DESCRIPTION Line Out LAN port USB port x 2 COM 3 CF Card slot VGA port (ULV Pro only) K/B, M/S Combo port 24V DC input... -
Page 8: Osd Control Buttons
ICON FUNCTION Press the Power button to start up the system. Press the Power button for 4 seconds to shut down the system from hardware. Press the Power button and “Brightness +” button for 4-6 seconds to reset the system from the hardware. Power LED Red: Standby mode. -
Page 9: Features
Chapter 1 — Welcome This POS terminal comes equipped with the following features: • Noise-free • Low power consumption • Saving cost of ownership • Compact size/ Aesthetic design • Dust/water- proof • WEPOS/XPE solution • Environment protection • Higher stability The fan-less, noise free design of the Frontier ULV is ideal for noise-intolerant environment such as... -
Page 10: Unpacking
Before setting up your Frontier ULV, check that the package contains the following items. If any of the items are missing or damaged, contact your vendor immediately. Frontier Touch Terminal AC Power Cord Customer Display (optional) Power Adapter Accessory Package 1. -
Page 11: Chapter 2
This chapter describes how to install the optional accessories on your Frontier Touch Terminal for optimal serviceability. Before you start installing your Frontier ULV, please read the following notices carefully. The Frontier ULV does not support PCI slot. Do not plug in or unplug any interior devices, such as memory module or any function card, when the ATX PSU is powered on. -
Page 12: Limitations
Preset voltage setting for MSR The MSR default setting is ISO Track 1 & 2. (For customized track settings, advise the manufacturer before production.) In event of any requirement to change the setting of the MSR, run Setting utility in the driver CD provided in the accessory package. The normal swiping card speed of the MSR is 10 to 100 cm/sec. -
Page 13: Hardware Installation
Chapter 2 — Getting Started To install the adapter and Internet cable for Lite type, do the following: Connect the Internet RJ 45 cable and the power cable to the connectors and arrange the cables in the clamps as shown. RJ 45 connector Replace the extension base cover and affix it to the base with two M3 back... -
Page 14: Installing The Adapter And Internet For Pro Type
To install the adapter and Internet cable for Pro type, do the following: Take out the cable clamps from the accessory package and attach them to the position as shown. Connect the Internet RJ 45 cable and the power cable to the connectors and arrange the cables in the clamps. RJ 45 connector Replace the extension base cover with two M3 screws and then affix the... -
Page 15: Installing The Customer Display For Lite Type
Chapter 2 — Getting Started Follow the procedures below to install the Customer Display. Connect the VFD DB 9 cable to the connector as shown. Replace the base cover and affix it with two M3 screws. Attach the Customer Display to the base of the Frontier ULV Terminal with two M3 screws. -
Page 16: Installing The 2Nd Display (For Pro Type Only)
To install the 2 display onto the Frontier ULV Terminal, do the following: Connect the DB 15 cable to the connector on the back of the Frontier ULV Terminal LCD screen and arrange the cable in the clamp as shown. Cable clamp Replace the base cover. -
Page 17: Installing The Msr
Chapter 2 — Getting Started Install the 2 Display and lock it to the stand with four M3 screws. To install the MSR onto the LCD display, do the following: Attach the MSR device jack to the MSR socket on the side of the LCD display. -
Page 18: Appendix
ITEM SPECIFICATION Model Name Frontier ULV All in One Touch POS System Processor Supports VIA Eden CPU 1.0 GHz or C7 CPU up to 2.0GHz Memory 200-pin DDR RAM *1, up to 2GB (DDR333/400) System Core North Bridge: VIA CN-700 Chipset South Bridge: VIA 8237R+ BIOS... -
Page 19: Appendix - Technical Information
Appendix — Technical Information ITEM SPECIFICATION Thermal Solution One heat-sink (Fan-less) or heat-sink with Fan (Base on Fan Speed Control technology) for CPU and North Bridge Chip Compact Flash One bootable compact flash card socket (Type I/II) Card Cash Drawer Port One cash drawer port with status sensor. -
Page 20: Frequently Asked Questions (Faq)
ITEM SPECIFICATION 32 Keys Programmable POS Keyboard Note: Specifications are subject to change without notice. Question 1: Why does the system appear unstable after updating BIOS? Answer: Load optimized defaults (or load SETUP Default) after flashing BIOS. If the system remains unstable, clear CMOS to solve the problem.
