Contents
1.
Your mobile.................................................................................................................................. 1
2.
Getting started............................................................................................................................. 5
3.
Basic functions ............................................................................................................................ 5
4.
FM Radio..................................................................................................................................... 8
5.
Recent calls ................................................................................................................................. 8
6.
Entertainment .............................................................................................................................. 9
7.
Alarm........................................................................................................................................... 9
8.
Contact ...................................................................................................................................... 10
9.
Messages ....................................................................................................................................11
10.
Settings ...................................................................................................................................... 14
11.
Profile........................................................................................................................................ 15
12.
Tools .......................................................................................................................................... 15
13.
FAQ............................................................................................................................................ 16
14.
Safety and use............................................................................................................................ 17
Friendly reminder:
This user manual applies to the OT-S319C mobile phone. If there are minor differences in the
description or illustrations between the manual and the actual product the actual product shall
take precedence. Customers will not be notified separately of any upgraded model of this
mobile phone. Please contact our Customer service.
We reserve the right to revise anytime the contents of this manual without prior notice.
1. Your mobile
1.1 Basic specifications
Item
Specifications
Size: 105.5mm[L]×45.5mm[W]×13mm[Thickness]
Mobile Phone
Weight: 69.16g approx.(Including lithium battery）
Screen resolution
128×128
Contacts
500 entries
Call Memory
30 entries
Rated capacity: 750mAh
Standard voltage: 3.7V
Talk time: 120 to 180 minutes
Li-ion battery
Standby time: 80 - 120 hours (approx.)
Operating temperature: -10℃ to +55℃
1
Advertisement
Table of Contents
Related Manuals for Alcatel OT-S319C
Summary of Contents for Alcatel OT-S319C
-
Page 1: Table Of Contents
Safety and use..........................17 Friendly reminder: This user manual applies to the OT-S319C mobile phone. If there are minor differences in the description or illustrations between the manual and the actual product the actual product shall take precedence. Customers will not be notified separately of any upgraded model of this mobile phone. - Page 2 Explanation: Standby time refers to the time when the phone although in operating mode is not used for making calls or remains idle. Standby time and call time are both related to the conditions of use, the network situation and the environment. The SAR standard is 2.0W/Kg.
- Page 3 Vibration Alert: Contact Access to change the mode of Profile New Event: Access to browse unread SMS and call history 1.3 Main Menu From the main menu, use the navigation key to select the item you want. After selection, press the left soft key to confirm. FM Radio: Enter the FM Radio, FM radio only with earphone insertion.
- Page 4 Contact: Enter the contact list where you can check or create a contact (the person data) and select a contact’s phone number Messages: Read, write and send SMS messages, view the Inbox and the Outbox. Manage the settings applied to the messages. Settings: Set the Time, Date, Language, Answer and security modes in your phone Profiles:...
-
Page 5: Getting Started
Alarm clock activated Roaming instructions Signal strength indicator 2. Getting started 2.1 Removing the back cover 2.2 Installing / removing the battery After remove the back cover then remove the battery and cover the back as shown (direction of the arrow). 3. - Page 6 as soon as you enter the password or the PIN code. For details on the use of the PIN code and password, please refer to Menu/Settings/Security settings. When the phone is on, press and hold the End key to turn it off. 3.2 Making a call 3.2.1 Entering the number directly In the standby mode, use the number key to enter a phone number, and then press the Call...
- Page 7 3.4.2 Changing the text input method In the text input mode, press the“#” to change the input method. Press the “*” key to switch from the upper case to the lower case characters when you need. 3.4.3 Text input methods The phone includes four text input methods: He, T9He, English, T9English and numbers.
-
Page 8: Fm Radio
1，commonly-used symbols a，b，c，A，B，C，2 d，e，f，D，E，F，3 g，h，i，G，H，I，4 j，k，l，J，K，L，5 m，n，o，M，N，O，6 p，q，r，s，P，Q，R，S，7 t，u，v，T，U，V，8 w，x，y，z，W，X，Y，Z，9 Number input method (123) Press the number key to enter the corresponding number, press “*” to enter “*”. 4. FM Radio You can use the phone as the FM radio only with earphone insertion. Earphone will act as an antenna for FM radio function. -
Page 9: Entertainment
left and right keys to toggle between: Outgoing calls, Missed calls and Received calls. In the “recent calls” menu you can also access the following options: Missed calls, Received calls, outgoing calls, Call time and Delete all. 5.1 Missed calls, received calls, outgoing calls Select Missed calls/ received calls/ outgoing calls from the Call Memory Menu to access the submenus of the various call logs. -
Page 10: Contact
deactivated. The 24 hour system is used for the time format. The available modes are: One day, Monday to Friday, Monday to Saturday and Everyday. Disable: Stop using the alarm clock Clear: Clear the alarm settings Clear All: Clear all alarm settings 8. -
Page 11: Messages
8.5 Speed dial Select Menu/Contact/Speed dial to set keys 2 to 9 for speed dialling. If the number key has not been set, press the left soft key and select a phone number from Contacts. If the number key has been set, press the left soft key and the following options will be available: Add new number, clear. - Page 12 View: Review the contents of the current messages. From the contents, press the left soft key for the following options: Reply, Delete, Forward, Extract details, Call, IP call. Reply: Send a message to the sender of the current message. Delete: Delete a message. Forward: Modify the contents of a message and send it.
- Page 13 Select Menu/SMS/Delete message to access delete function. You may delete the messages in Inbox, Outbox, and Draft box and also clear all the messages. 9.7 Setting message Select Menu/SMS/Setting to access submenu with below options: Priority, Delivery report, Call back number, Message Validity. Priority: Choose the priority sequence such as normal, urgent, Emergency.
-
Page 14: Settings
Settings Select Menu/Settings to access to set the parameter of mobile. 10.1 Phone Language: Choose language for message, Traditional Chinese and English available. Time Format: Set 12 hrs mode and 24 hrs mode. Date Format: Set date format and you may have three options: dd/mm/yy, mm/dd/yy, yy/mm/dd. -
Page 15: Profile
Select menu/settings/security, then enter the security submenu by inputting the phone code (default code is 1234). You can set entry code for your SMS, phone book, call memory there. Phone lock: including phone code activation and inactivation, and password resetting, if you activate the phone code, you have to enter the phone code every time when the cell phone powers on Contact lock: setting protective code to phone book, the default code is the same as phone... -
Page 16: Faq
12.2 Calculator Your phone has a timer function and can carry out simple operations, i.e. the “Four Arithmetic Operations”. Numbers are entered using number keys, “*” can be used to input decimal points, the left soft key can be used to insert the plus and minus symbols, the right soft key is used to clear the entries, the left key to insert “-“and the right key to insert “÷”, the upper key is used to insert “+”... -
Page 17: Safety And Use
Item to be checked The other party cannot Make sure the mouthpiece is not blocked. hear you during a call The receiver volume is Check if the receiver volume is set to maximum. The phone signal is poor Make sure the phone antenna is not damaged. or switches off frequently Check the phone signal strength. - Page 18 Mobile phones should be forbidden inside an operating theatre, Intensive Care Unit (ICU) or Cardiac Care Unit (CCU). Pay attention to the settings of the sound volume and the vibration to avoid disturbing the patients. Flammable or explosive areas Turn off your phone near flammable or explosive areas. Do not install/remove or charge the battery or use the phone in these areas to prevent any explosion or fire.
- Page 19 Do not place sharp metallic items such as needles, near the receiver because the receiver will attract them and you may be injured when using the phone. Do not place the phone in the back pocket of your trousers or skirt to avoid damaging it when you sit down Child health Keep the phone, battery and charger out of the reach of children.
- Page 20 agents or abrasive cleaning agents to avoid damaging its parts or causing a malfunction. You may clean with a slightly damp anti-static soft cloth. Do not scrape or alter the phone case as paint substances may cause an allergic reaction. If such a reaction occurs, cease using the phone immediately and seek medical help.
- Page 21 Warning: The manufacturer disclaims any liability for damage, which may result as a consequence of improper use of this mobile phone or use contrary to the instructions contained in this manual. Alcatel logo and Alcatel name are Trademark of Alcatel-Lucent used under license by TCT Mobile Limited All rights reserved ©...
