Tappan TRS20WRH Factory Parts Catalog

Side by side
Hide thumbs
Table of Contents

Advertisement

Quick Links

PRODUCT NO.
BASE MODEL NO.
TRS20WRHD0
TRS20WRH
TRS20WRHW0
TRS20WRH
MARKET
North America
WIRING DIAGRAM - # 218875901
OWNER'S GUIDE - # 218947500
SERVICE DATA SHEET - # 218905000
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a
almond
R134a
white
Publication No.
5995324760
990611
-EN/SERVICE/KB
357

SIDE BY SIDE

REFRIGERATOR
VOLTS
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
TRS20WRH
©1999 White Consolidated Industries, Inc.
All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRS20WRH and is the answer not in the manual?

Questions and answers

Dee Smith
March 10, 2025

Can I get a phone number?

0

Subscribe to Our Youtube Channel

Related Manuals for Tappan TRS20WRH

Summary of Contents for Tappan TRS20WRH

  • Page 1: Side By Side

    PRODUCT NO. BASE MODEL NO. TRS20WRHD0 TRS20WRH TRS20WRHW0 TRS20WRH MARKET North America WIRING DIAGRAM - # 218875901 OWNER’S GUIDE - # 218947500 SERVICE DATA SHEET - # 218905000 101 Masters Blvd. Anderson, SC 29624 FACTORY PARTS CATALOG REFRIGERATOR SERIES COLOR...

  • Page 2: Freezer Door

    Publication No. TRS20WRH 5995324760 FREEZER DOOR 06/99...
  • Page 3 A = TRS20WRH (TRS20WRHD0) B = TRS20WRH (TRS20WRHW0) POS. NO 37A* 37A* # = Fast-moving Parts * = Non-Illustrated Parts TRS20WRH FREEZER DOOR PART NO DESCRIPTION 215734301 Gasket-frzr door,almond ,magnetic 215734311 Gasket-frzr door,white ,magnetic 215473601 Support-door rack,RH/LH 5303324303 Support-door rack,LH...

  • Page 4: Refrigerator Door

    Publication No. TRS20WRH 5995324760 REFRIGERATOR DOOR 06/99...
  • Page 5 A = TRS20WRH (TRS20WRHD0) B = TRS20WRH (TRS20WRHW0) POS. NO 37A* 37A* # = Fast-moving Parts * = Non-Illustrated Parts TRS20WRH REFRIGERATOR DOOR PART NO DESCRIPTION 215734302 Gasket-refr door,almond ,magnetic 215734312 Gasket-refr door,white ,magnetic 218749301 Panel-inner door,refr 5304412774 Rack-door 215267701 Support-door rack,"2-liter"...
  • Page 6 Publication No. TRS20WRH 5995324760 CABINET 06/99...
  • Page 7 A = TRS20WRH (TRS20WRHD0) B = TRS20WRH (TRS20WRHW0) POS. NO 30A* 101* # = Fast-moving Parts * = Non-Illustrated Parts TRS20WRH CABINET PART NO DESCRIPTION 218748901 Cover-air duct 5303209814 Nut,"U" type ,8-15(A) ,fan mtr mtg 218751301 Cover-evap coil,lower 5303208309 Plug-hole,factory test...
  • Page 8 Publication No. TRS20WRH 5995324760 SHELVES 06/99...
  • Page 9 A = TRS20WRH (TRS20WRHD0) B = TRS20WRH (TRS20WRHW0) POS. NO 100A 100B # = Fast-moving Parts * = Non-Illustrated Parts TRS20WRH SHELVES PART NO DESCRIPTION 5303300707 Trim-basket 218298005 Shelf-freezer,sliding ,wire 5304405989 Shelf-freezer 215919136 Frame-refr shelf,cantilever ,(3) 218015301 Trim-storage pan cvr,snap-on ,front...
  • Page 10 Publication No. TRS20WRH 5995324760 CONTROLS 06/99...
  • Page 11 A = TRS20WRH (TRS20WRHD0) B = TRS20WRH (TRS20WRHW0) POS. NO 13 # 17A* 21 # 23 # 114# # = Fast-moving Parts * = Non-Illustrated Parts TRS20WRH CONTROLS PART NO DESCRIPTION 215028605 Knob-damper control 5308000010 Fan Blade,red 5308000124 Ring-fan orifice...
  • Page 12 Publication No. TRS20WRH 5995324760 SYSTEM 06/99...
  • Page 13 A = TRS20WRH (TRS20WRHD0) B = TRS20WRH (TRS20WRHW0) POS. NO 13 # 14 # 15 # 21 # 30 # 60 # # = Fast-moving Parts * = Non-Illustrated Parts TRS20WRH SYSTEM PART NO DESCRIPTION 218787700 Condenser 5303208866 Spacer-cond tube,black...
  • Page 14 Publication No. 5995324760 06/99 TRS20WRH DISPENSER...
  • Page 15 A = TRS20WRH (TRS20WRHD0) B = TRS20WRH (TRS20WRHW0) POS. NO 16 # 17A* 33 # 35 # 38A# # = Fast-moving Parts * = Non-Illustrated Parts TRS20WRH DISPENSER PART NO DESCRIPTION 5318582501 Tube-water inlet, 93", plastic, cut-to-size 215294101 Tube-water inlet, formed, plastic, dispenser...

  • Page 16: Ice Container

    Publication No. TRS20WRH 5995324760 ICE CONTAINER 06/99...
  • Page 17 A = TRS20WRH (TRS20WRHD0) B = TRS20WRH (TRS20WRHW0) POS. NO 16 # 18 # # = Fast-moving Parts * = Non-Illustrated Parts TRS20WRH ICE CONTAINER PART NO DESCRIPTION 5304404344 Auger-ice 5304404343 Cam-drive 218815300 Container-ice 5304404346 Drum-ice disp 218815400 Front-ice container...

  • Page 18: Ice Maker

    Publication No. TRS20WRH 5995324760 ICE MAKER 06/99...
  • Page 19 A = TRS20WRH (TRS20WRHD0) B = TRS20WRH (TRS20WRHW0) POS. NO 11 # 12 # 13 # 15 # 17 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts TRS20WRH ICE MAKER PART NO DESCRIPTION 5318582501 Tube-water inlet, 93", plastic, cut-to-size...

  • Page 20: Wiring Schematic

    Publication No. TRS20WRH 5995324760 WIRING SCHEMATIC 06/99...

  • Page 21: Wiring Diagram

    TRS20WRH Publication No. 5995324760 WIRING DIAGRAM # = Fast-moving Parts 06/99 * = Non-Illustrated Parts...
