- Page 1 20'' LCD HDTV Owner's Manual Model : LVQ2001...
-
Page 2: Table Of Contents
Please read all the safety and operating instructions carefully before you begin. Safety class This is an IEC safety class I product and must be grounded for safety. TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS......................PREFACE................................WARNING AND CAUTIONS..........................SPECIFICATIONS.............................. ACCESSORIES ..............................TV ASSEMBLY DRAWINGS.......................... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS 1.Read these safety instructions. 2.Keep these safety instructions. 3.Heed all warnings. 4.Follow all safety instructions. 5.Do not use this apparatus near water. 6.Clean only with dry cloth. 7.Do not block any ventilation openings. Install in accordance with manufacturer instructions. 8.Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including Amplifiers) that produce heat. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN! CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. T h e s y m b o l i n d i c a t e s t h a t d a n g e r o u s v o l t a g e c o n s t i t u t i n g a r i s k o f e l e c t r i c s h o c k i s p r e s e n t w i t h i n t h i s u n i t . -
Page 5: Preface
PREFACE Thank you for purchasing this TV. To enjoy your set from the very beginning, read this manual carefully and keep it handy for ready reference. INSTALLATION Position the TV in the room where light does not strike the screen directly Total darkness or a reflection on the picture screen can cause eyestrain. -
Page 6: Warning And Cautions
WARNINGS AND CAUTIONS Warning High voltages are used in the operation of this television receiver. Do not remove the cabinet back from your set. Refer servicing to qualified service personnel. Warning To prevent fire or electrical shock hazard, do not expose the television receiver to rain or moisture. -
Page 7: Warning And Cautions
WARNINGS AND CAUTIONS Caution Never stand on, lean on, or suddenly push the television or its stand. You should pay special attention to children. Serious injury may result if it should fall. Caution Do not place your television on an unstable cart, stand, shelf or table. -
Page 8: Specifications
SPECIFICATIONS AND ACCESSORIES SPECIFICATIONS Model LVQ2001 LCD panel 20 INCH TFT LCD Television system NTSC-M/N PAL-M/N PAL-4.43MHz-50Hz NTSC-3.58MHz-60Hz SECAM-4.29MHz-50Hz AV system NTSC-4.43MHz-60Hz PAL-3..58MHz-50Hz PAL-3.58MHz-60Hz PAL-4.43MHz-60Hz VHF-L: 199 MHz Channel coverage VHF-H: 499MHz UHF: 933 MHz Analog RGB mode 640X480/60Hz, 800X600/60Hz... -
Page 9: Tv Assembly Drawings
TV ASSEMBLY DRAWINGS 1. Adjust the angle of the screen. The horizontal angle could be adapted to suit yourself. It’s range is up to 40°. Seeing drawings below. 40° 2. Hang the TV on the concrete wall. 3. Assemble stand Step1:Disassemble the pedestal. -
Page 10: Installation
INSTALLATION FRONT VOL+ VOL- MENU AUTO/EXIT IR IR Buttons: 1.MENU: To enter main menu or enter the item where the cursor is. 2.CH+/CH-:Move the cursor in the main menu or change program in TV mode. 3.VOL+/VOL-: Adjust the item you select or adjust volume. 4.AUTO/EXIT: Act as AUTO adjustment hot key when OSD is not displayed. - Page 11 INSTALLATION STEPS: 1. Connect Video Cable a. Make sure both the TV and computer are powered-OFF. b. Connect the video cable to the computer. 2. Connect the Audio cable. 3. Connect power cord Connect the AC ADAPTOR to the TV, then to a properly grounded AC outlet. 4.
-
Page 12: Antenna
INSTALLATION ANTENNA -10-... -
Page 13: Av Equipment
INSTALLATION AV EQUIPMENT This TV provides one group of AV input terminals including one S-Video and one group of YCbCr for convenient connection to VCR, DVD or other video equipment. Please refer to the owner’s manual of the equipment to be connected as well. You can use the AV and YCbCr input terminals on TV set rear as follows. -
Page 14: Battery Installation (Remote Control Unit)
BATTERY INSTALLATION (REMOTE CONTROL) Insert Batteries Into the Remote Control 1. Remove the battery cover. 2. Insert the two AAA 1.5V batteries and ensure correct polarity (+ or -) 3. Replace the battery cover. Replace with new batteries when the TV set shows no response to the remote control. Note: 1. -
Page 15: Remote Control Description
REMOTE CONTROL DESCRIPTION POWER POWER MUTE MUTE INPUT INPUT SLEEP SLEEP AUTO AUTO MENU MENU SYSTEM SYSTEM RETURN RETURN DISPLAY DISPLAY SOUND SOUND PICTURE PICTURE 1.POWER:turn on or off the TV 2.NUMBER BUTTONS 3.VOL+/- :adjust volume 4.CH+/- :change program forward/backward 5.MENU: access main menu 6.BUTTONS : move cursor in main menu... -
Page 16: Remote Control Description
REMOTE CONTROL DESCRIPTION 14.SYSTEM:shift frequency system(STD,HRC,IRC,AIR) VCR: rectify distorted signal from VCR (video cassette recorder ). AUTO: auto adust the position and size of the picture in PC mode 17.SOUND:3 sound mode.SPEECH STANDARD MUSIC 18.PICTURE:3 picture mode.SOFT STANDARD RICH DIRECT PROGRAM SELECTION (0-9 BUTTONS) 1.To select one-digit channel: Press 0-9 digit buttons and wait for 2 seconds. -
Page 17: Operation Instructions
OPERATION INSTRUCTIONS PART I (PC) All MENUs are shown below -15-... - Page 18 OPERATION INSTRUCTIONS PART I (PC) AUTO CONFIG: -16-...
-
Page 19: Preset Modes
OPERATION INSTRUCTIONS PART I (PC) OPERATION OF MAIN MENU There are 12 items listed in the main menu Step1:Press menu to enter the main menu Step2:press to select an item Step3:press menu to enter this item Step4:press to adjust this item Item Function description Increase or decrease contrast... -
Page 20: Video
OPERATION INSTRUCTIONS PART II(VIDEO) TUNING PROCEDURE(NOTE) STEP 1: Turn on the TV STEP 2: AUTO MEMORY 1. Press the MENU button on your TV (or remote controller) three times to enter TUNING menu. If it is in VIDEO/S-VEDIO/YCbCr /PC mode, it can't enter TUNING menu. 2. - Page 21 OPERATION INSTRUCTIONS PART II(VIDEO) STEP 3 FINE TUNING If signal is weak, the fine tuning is necessary. 1. Enter the channel you want to by CH+/CH- buttons or NUMBER KEY(0-9). 2. According to mentioned steps above, enter TUNING menu. 3. Select "FINE" by button.
- Page 22 OPERATION INSTRUCTIONS PART II(VIDEO) ADJUST PICTURE 1.According to mentioned steps above, enter PICTURE menu. 2.Selecttheitem to be adjusted by buttons. 3.Adjust the image quality by buttons. ADJUST SOUND 1.According to mentioned steps above, enter SOUND menu. 2.Select the item to be adjusted by buttons.
- Page 23 OPERATION INSTRUCTIONS(VIDEO) SELECT LANGUAGE 1.According to mentioned steps above, enter SETUP menu. 2.Select the LANGUAGE item to be adjusted by buttons. 3.Adjust the language you want by buttons. There are 5 languages:ENGLISH and SPANISH,PORTUGUESE,ITALIAN,FRENCH. COLOR TEMP COLOR TEMP WARM WARM CC/V-CHIP CC/V-CHIP SET COLOR TEMPERATURE...
- Page 24 OPERATION INSTRUCTIONS(VIDEO) CCD/VCHIP(CCD and VCHIP are in one menu-VCHIP SETTING menu) COLOR TEMP COLOR TEMP WARM WARM CC/V-CHIP I Setting Closed Caption(CCD) 1.Press button to select Closed Caption item. 2.Press the button to select. You can select the caption data channel (C1/C2/C3/C4), the text service channel (T1/T2/T3/T4) or turn off the Closed Caption (Off).
- Page 25 OPERATION INSTRUCTIONS(VIDEO) PART 2:MPAA RATING SET-UP To enable V-chip setting, you should set V-CHIP ENABLE to ON in VCHIP SETTING menu. Rating guidelines are provided by broadcast stations. Most television programs and television movies can be blocked by TV Rating and/or Individual Categories. Movies that have been shown at the theaters or direct-to-video movies use the Movie Rating System (MPAA) only.
-
Page 26: Video
OPERATION INSTRUCTIONS(VIDEO) PART 3:TV BLOCKING TV Parental Guidelines may have one or more letters added to the basic rating to let parents know when a show contains higher levels of violence, sex, adult language or suggestive dialogue: 1.Press button to select TV BLOCKING item. 2.Press button to enter into TV BLOCKING sub-menu. -
Page 27: Troubleshooting Guide
TROUBLESHOOTING GUIDE PART I (PC) This LCD TV has pre-adjusted using factory standard VGA timings. Due to the output timing differences among various VGA cards in the market,users may initially experience an unstable or unclear display whenever a new display mode or new VGA card is selected. ATTENTION This LCD TV Supports Multiple VGA Modes. -
Page 28: Service Tips
SERVICE TIPS Incorporated in your TV receiver are the most up-to-date devices to eliminate interference. Local radiation however, can create disturbances which visibly affect your picture. Proper installation, a good aerial are your best safe-guards against these disturbances. Moving ripples across the screen are caused by nearby transmitting or receiving-short-wave radio equipment. - Page 29 Call us for technical support Monday to Friday 8:00 am to 6:00 pm Pacific Time Tel:1-877-851-2528 Web: WWW.VISIONQUESTTV.COM VISIONQUEST SERVICE CENTER 4906 BLEECKER STREET Baldwin Park, CA 91706...
