Summary of Contents for TerraTec TerraCAM 2move
- Page 1 Manual (English)
- Page 2 Meticulous care has been taken in the preparation of all text passages and illustrations in this manual. TerraTec Electronic GmbH and its authors, however, accept no liability, legal or otherwise, for errors or the consequences of such errors. We reserve the right to technical modifications.
-
Page 3: Hardware Overview
Hardware Overview Release button On / Off / erase button Lens Function display Camera stand Menu button Hold for wrist loop USB Interface Finder Battery compartment lid TerraCAM 2move (English) -
Page 4: Key Features
System requirements · 1 free USB port · Pentium 200 MHz or higher · 32 MB RAM · CD-ROM drive (to install the drivers and software) · Windows 98 / 98SE / ME / 2000 / XP TerraCAM 2move (English) -
Page 5: Package Contents
Package Contents · TerraCam 2move with camera stand · Wrist belt · CD-ROM with software and drivers · USB connection cable · Manual/Quick reference · Service card · Registration card · Batteries Technical specifications · Color sensor 1/4" · Focal range from 30 cm to infinity ·... -
Page 6: Operation
On / Off: To activate the TerraCAM 2move, simply press the button "On / Off Erase . Attention, switching off the camera will delete all picures taken. If the On / Off button is not being pressed during the operation, TerraCAM 2move will switch off automatically after 30 seconds, with all picures remaining stored. - Page 7 Installing the drivers under Windows 98SE Naturally you'd like to plug in your new TerraCAM 2move and get started right away, but please read the following installation information carefully first to ensure that everything goes smoothly. In some cases, Windows may ask you to insert the Windows installation CD during the installation.
- Page 8 5. The hardware assistant will search and install the drivers automatically When the driver for the TerraCAM 2move has been found, click "Next". Click "Finish" to complete the installation After the installation has been finished, TerraCAM 2move is ready for use in all supported applications. TerraCAM 2move (English)
- Page 9 5. The hardware assistant will search and install the drivers automatically Windows detects the new hardware and starts the Hardware Assistant. Click "Next". Click "Finish" to complete the installation. After the installation has been completed, TerraCAM 2move is available in all applications TerraCAM 2move (English)
- Page 10 Insert the installation CD into your CD-ROM drive. When the autostart menu appears, please close it Connect the TerraCAM 2move connection cable to a free USB port. Windows detects the new hardware and starts the Hardware Assistant. Click "Next". When the following menu appears click on "Next".
- Page 11 Select the "CD-ROM drive" check box and click "Next". When the driver for the TerraCAM has been found, click on "Next".. TerraCAM 2move (English)
- Page 12 Click on "Yes", to allow the driver to be installed despite the missing signature. A missing signature has no effect on the quality or functionality of the driver. Click "Finish" to complete the installation After the installation has been completed, TerraCAM 2move is available in all applications TerraCAM 2move (English)
- Page 13 2. Insert the installation CD into your CD-ROM drive. 3. When the autostart mennu appears, please close it. 4. Connect the TerraCAM 2move connection cable to a free USB port. Windows detects the new hardware and starts the Hardware Assistant. Click "Next".
- Page 14 Click "Finish" to complete the installation After the installation has been completed, TerraCAM 2move is available in all applications TerraCAM 2move (English)
- Page 15 It will then be shown in the window on the right, next to "Live View". Stills Stills enables you to load the pictures from your TerraCAM 2move to your computer. Camera Settings Enables you to choose a USB port on your computer Close This button closes all applications.
- Page 16 With this feature you can use the TerraCAM 2 move lieka webcam. Attention! Changing the video mode deletes all pictures in the camera. Capture Use Capture to create photos or use your TerraCAM 2move's Snap Shot button. Settings Offers you to configure your drivers, For more information, refer to pageFehler! Textmarke nicht definiert..
- Page 17 Cancel Closes the dialog window. TerraCAM 2move (English)
-
Page 18: Driver Configuration
TerraCAM 2move driver configuration. TerraCAM 2move supports two different driver models: 1. Windows Driver Model or WDM is used for displaying and recording video clips. 2. TWAIN is an interface, originally developped for scanner operation, used for the recording of still pictures with the TerraCAM. - Page 19 If an object is positioned in front of a bright light source, it may appear too dark. Activating this function will automatically correct this. Zoom Using this function enables you to magnify the center of a picture. TerraCAM 2move (English)
- Page 20 Net Meeting: Eye to eye NetMeeting – the mother of all videoconferences is also included in the TerraCAM 2move package. If you own a modem or an ISDN card, you can use this software to participate in videoconferences worldwide or install a convenient picture telephone solution.
- Page 21 Device Manager. If you have any questions about enabling the USB port, please check the manual of your mainboard. If your system crashes after installing the TerraCAM 2move, first make sure that the interrupt (IRQ) of the USB port is not also being used by another component. Although Windows will not indicate any problems in the Device Manager, problems may occur, when using the TerraCAM 2move.
