NB PCIE Voltage Control
Allows you to set the North Bridge PCIe voltage.
Normal
1.800V ~ 2.200V
CPU NB VID Control
Allows you to set the CPU Northbridge VID voltage. Auto sets the CPU Northbridge VID voltage as re-
quired. The adjustable range is dependent on the CPU being installed. (Default: Normal)
Note: Increasing CPU voltage may result in damage to your CPU or reduce the useful life of the CPU.
CPU Voltage Control
Allows you to set the CPU voltage. Auto sets the CPU voltage as required. The adjustable range is de-
pendent on the CPU being installed. (Default: Normal)
Note: Increasing CPU voltage may result in damage to your CPU or reduce the useful life of the CPU.
Normal CPU Vcore
Displays the normal operating voltage of your CPU.
Supplies the North Bridge PCIe voltage as required. (Default)
The adjustable range is from 1.800V to 2.200V.
- 43 - BIOS Setup
