Summary of Contents for Firenzi FFR 100
- Page 1 FREEZER FFR 100 INSTRUCTION BOOKLET 2222739-14...
-
Page 2: Important Safety Instructions
Important Safety Instructions These warnings are provided in the interests of your safety. Ensure that you understand them all before installing or using this appliance. Your safety is of paramount importance. If you are unsure about any of the meanings of these warnings contact the Customer Care Department. Prior to Installation General Safety ¥... -
Page 3: Table Of Contents
Servicing At the end of the Appliance Life ¥ This product should be serviced by an authorised ¥ When disposing of your appliance use an engineer and only genuine spare parts should be authorised disposal site. used. ¥ Remove the plug and ensure that any locks or ¥... -
Page 4: Operation
Operation Before use Remove all securing tapes. Wash inside the appliance with lukewarm water and bicarbonate of soda (5 ml to 0.5 litre of water). Do not use soap or detergent as the smell may linger. Dry thoroughly. Freezer controls (1) Fast freeze switch (4) Pilot light (green) (2) Fast freeze light (yellow) -
Page 5: Freezing Fresh Food
food to be frozen in the appliance's two top Important compartments; if freezing only a small amount of Do not put carbonated liquids, (fizzy drinks food, use the top compartment. etc.), in the freezer. Once the food is completely frozen (which could take Ice lollies, if consumed immediately after up to 24 hours) return the fast freeze button to the removal from the freezer, can possibly result in... -
Page 6: Cold Accumulator
Cold accumulator Ice making The freezer contains one cold accumulator which Fill the ice tray 3/4 full with water to allow the ice to can be found in the top compartment. The cold expand and place it in the freezer. To release the ice accumulator increases storage times in the event of cubes, twist the tray along its length. -
Page 7: Defrosting
Defrosting The freezer compartment will become progressively covered with frost. This should be removed with the special plastic scraper provided, whenever the thickness of the frost exceeds 1/4". During this operation it is not necessary to switch off the power supply or to remove the foodstuffs. However, when the ice becomes very thick on the inner liner, complete defrosting should be carried out and it is advisable to carry out this operation when... -
Page 8: Maintenance And Cleaning
Maintenance and Cleaning Periodic cleaning Warning Before any maintenance or cleaning work The appliance is equipped with a ventilation grid. is carried out, DISCONNECT the appliance Keep clean to guarantee good ventilation and good from the ELECTRICITY supply. working order of the appliance. Important An accumulation of dust will affect the performance This appliance contains hydrocarbons in... -
Page 9: Something Not Working
Something not Working? Before contacting your local Service Force Centre check the following points. IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee. Symptom Solution No power to appliance... -
Page 10: Service And Spare Parts
Service and Spare Parts In the event of your appliance requiring service, or if you wish to purchase spare parts, please contact your local Service Force Centre by telephoning:- 08705 929929 Your telephone call will be automatically routed to the Service Force Centre covering your post code area. For the address of your local Service Force Centre and further information about Service Force, please visit the website at www.serviceforce.co.uk Before calling out an engineer, please ensure you have read the details under the heading ÒSomething Not... -
Page 11: Guarantee Conditions
Standard guarantee conditions EHP, undertake that if within 12 months of the date of purchase this Firenzi appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: ¥... -
Page 12: Technical Specifications
Technical Specifications DIMENSIONS Height 81,5 Width 59,6 Depth POWER SUPPLY VOLTAGE AND FREQUENCY 220-240 V / 50 Hz TOTAL POWER ABSORBED 90 W AVERAGE DAILY UNITS ELECTRICITY (*) 0,78 kWh GROSS CAPACITY 108 l NET CAPACITY 100 l STAR RATING (*)This figure is based on standard test results in accordance with European Standard EN153. -
Page 13: Electrical Connection
Electrical Connection If you fit your own plug, the colours of the wires in the WARNING mains lead of your appliance, may not correspond THIS APPLIANCE MUST BE EARTHED. with the markings identifying the terminals in your The manufacturer declines any liability plug, proceed as follows: should this safety measure not be Connect the Green and the Yellow (earth) wire to the... -
Page 14: Door Reversal
Door reversal To reverse the opening direction of the door, proceed as shown in the figures: Attention After completion of the door reversing operation, check that the door gasket adheres to the cabinet. If the ambient temperature is cold (i.e. in Winter), the gasket may not fit perfectly to the cabinet. -
Page 15: Building-In Instructions
Building-in instructions Before carrying out any work, remove the plug from Building in the appliance under a the power socket. worktop The dimensions of the recessed installation area Grid preparation must correspond with those indicated in the figure. Left door opening: Remove the left side (A) of the grid cutting it from the rear (see figure). - Page 16 2. Push the appliance into place. The plug socket N.B. The joint cover (B) is to be assembled after necessary for connection of the appliance to the having installed the appliance in the recess. electricity supply should be positioned, so that the plug is not placed in the recess.
- Page 17 6. To mount the furniture door proceed as shown in UPPER PART OF KITCHEN FURNITURE PANEL the figures: LOWER PART OF KITCHEN FURNITURE PANEL clic clic...
-
Page 18: Fitting The Plinth
Fitting the plinth Important For the efficient operation of the appliance, it is important that the original ventilation grid is used. ¥ For an opening height dimension A=820 mm and a plinth height dimension a=100 mm, the plinth may be fitted without adjustments. The same applies to an opening height dimension B=870 mm and a plinth height dimension b=150 mm.
