Summary of Contents for Pelican MD3200M
- Page 1 Installation Guide MD3200M (v 1.0)
- Page 2 Caution Since this device is operation purpose and registered as suitable electromagnetic waves, seller or user should be cautios on this point. If the device is sold or purchased wrongly, it is required to replace as Home use. FCC Compliance Statement Caution : Any changes or modifications in construction of this device which are not expressly approved the party responsible for compliance could void the user's authority to operate the equipment.
- Page 3 Important Notice 1. Do not place heavy objects on the top of the eDVR 2. eDVR is for indoor use. It is not weatherproof. Use eDVR with referring to its environmental specifications (Temperature & Humidity). To clean the eDVR, gently wipe the outside with a clean dry cloth.
-
Page 4: Table Of Contents
5.1. Using menu ......................... 14 5.2. Dialogue box to edit a word ..................15 Setting remote controller...................... 16 6.1. Setting ID of MD3200M ....................16 6.2. Selecting MD3200M....................17 6.3. Operable range of remote controller ................17 6.4. Loading the batteries into remote controller ..............17 MD3200M configuration ..................... - Page 5 10.1. IEEE1394 port ......................38 10.2. Connecting IEEE1394 Device ................... 38 10.3. Available HDD ......................39 10.4. Registering & Formating HDD.................. 39 Network monitoring & managing..................40 11.1. Connecting Ethernet ....................40 11.2. Configuring Network infomraiton of MD3200M ............41...
- Page 6 Using Control Center Lite ....................42 12.1. Starting........................42 12.1.1. PC system requirements for running Control Center Lite.......... 42 12.2. Installing Control Center Lite ..................42 12.3. Log-In ........................43 12.4. Configuration Tool ....................44 12.5. Monitor ........................44 12.6. Playback........................
-
Page 7: Overview
OVERVIEW 1. What is MD3200M? The eDVR MD3200M is a 16-analog channels network digital video recorder. Video, Audio, Text and Event-Logs are digitized and stored on two internal Hard-Drives □ 32 analog video channels □ 4 channel two-way audio recording & playback □... -
Page 8: Supplied Accessories
2. Supplied accessories Unpack and check all the items as below; 1. eDVR MD3200M (1EA) 2. AC Power Cord (1EA) 3. CD (Including Software) (1EA) 4. Remote Controller (1EA) 5. RACK FIXING KIT (1SET) 6. R-HDD screw (8EA) <Note> Attention for the system without HDD installed In case of system without HDD, HDD only can only be installed in R-HDD(Removable Hard disk rack). -
Page 9: Description & Function
3. Description & Function MD3200M front (1) Power switch (2) Function buttons (3) LED (4) USB port (5) Remote controller receiver (6) CD/DVD-RW ROM (7),(8) Built-in Hard Disk Rack... - Page 10 MD3200M rear (9) AC power connector (10) BNC connector for video input (11) Terminal block for sensor, relay, and serial input/output (12) RS232 connector (13) VGA connector (14) IEEE1394 connector (15) eSATA connector (16) Network Storage connector(RJ45) (17) GND (18) Ethernet connector...
-
Page 11: Installation And Connection
75-Ohm termination register is always connected on video input, and can't be removed. So MD3200M's video input must be a terminal of the connection. Video Type(NTSC/PAL) should be changed after opeting MD3200M. The order of camera recognition follows Ch1 camera through Ch32 camera and 1 recognized camera type leads other camera type. -
Page 12: Connecting Audio
<Note> Monitor out put of MD3200M is separated as A(Normal) and B(Spot). Connect to Monitor A if only one Monitor is used . Monitor output is fixed depend on channel. Video Out 1, 3 is output channel 1 to 16, and Video 2, 4 is output channel 17~32. -
Page 13: Supplying Power
When supplying power, MD3200M starts booting automatically. 2. In order to cut off power, press the power switch on MD3200M front during 4 seconds and enter admin password after appearing a pop window. 3. For supplying again, push the power switch. -
Page 14: Running Osd Menu
5. Running OSD menu 5.1. Using menu Press the [MENU] in keypad of front to open the OSD Configuration Menu ① Main Menu ② Sub-menu ③ Setting Page (1) Main Menu : The selected tab is shown in blue and the related sub-menu will be shown below the tab. -
Page 15: Dialogue Box To Edit A Word
5.2. Dialogue box to edit a word There are two methods to input a word.. (1) Entering words Move pressing [▶] arrow button to enter next word until the word is looking for is shown using [▲ /▼ ] arrow buttons. In case of spacing words, press [▶] to move one space and enter the word. To exit the Dialogue box, press the [▷] arrow button. -
Page 16: Setting Remote Controller
6. Setting remote controller When controlling several eDVRs with one remote controller, set Remote Contorl ID as follows. 6.1. Setting ID of MD3200M (1) Press the [MENU] button (2) Select “System” with using [▶] button and press the [▷] or [▼ ] button (3) Select “Miscelleaneous”... -
Page 17: Selecting Md3200M
Selecting MD3200M If several eDVRs are set with unique ID numbers, they can be controlled with one remote controller. To select a specific eDVR (MD3200M), Keep pressing the ID button of remote controller until a buzzer sounds during 2 seconds. -
Page 18: Md3200M Configuration
7. MD3200M configuration 7.1. Basic configuration 7.2. Advanced configuration... -
Page 19: External Storage & Back Up Configuration
7.3. External storage & Back up configuration 7.4. Internet/ Intranet configuration... -
Page 20: Edvr Md3200M Basic Setting
8. eDVR MD3200M basic setting 8.1. Viewing Image When power is on, MD3200M starts automatically and images are displayed in basic 16ch-split screen after the booting. <Note> If user password is set, a prompt for entering the password will appear. Facotry default is reserved as... -
Page 21: Setting Date & Time
8.2. Setting Date & Time (1) Press [MENU] button and select “Quick Setup” tab. (2) Select “Date/Time” using the [▷] or [▼ ] and press [EXIT] button. 8.2.1. Time Zone (1) Select “Time Zone” using the [◀/▶] or [▲ /▼ ] buton and press [▷] to configure. (2) Select Time Zone using the [◀/▶] button and press [EXIT]. -
Page 22: Time Format
8.2.4. Time Format (1) Select “Time Format” using the [◀/▶] or [▲ /▼ ] button and press [▷] button.. (2) Two time formats are available; ‘DD/MM/YYYY,’ ‘MM/DD/YYYY’, ‘YYYY/MM/DD’; Select a value using [▲ /▼ ] buttons and press the [EXIT] button when it is finished. (Factory default is set as ‘MM/DD/YYYY’) 8.2.5. -
Page 23: Setting Recording Condition
8.3. Setting recording condition Recording conditions under the “Quick Setup” menu tab apply the same values to all analog channels 1~16. All settings are applied for 24 hours/ day regardless of the value set for “Time Schedule” or “Alarm Rec.” (1) Press [MENU] button and select “Quick Setup”... -
Page 24: Recording Speed/Quality
8.3.2. Recording Speed/Quality (1) Select “Recording Speed/ Quality using [▲ /▼ ] buttons and press [▷]. (2) Select a value using the[◀/▶] button. Press the [EXIT] button when it is finished. <Note> Recording Speed/Quality means Low : Speed=7.5(6)ips and Quality=Q3 and Resolution=CIF Standard. -
Page 25: Connecting And Configuring Dio Ports
9. Connecting and configuring DIO ports <Note> Wire Handling Trimming Wire When connecting a wire to a terminal block, follow the instructions below. Note the different types of wire that can be used. Standard Wire : Peel off the wiring, cover 8~10mm and solder it. -
Page 26: Connecting Sensor Input
9.1.2. Connecting sensor input Connect S1 ~ S16 with referring to the followings. It shows to connect a dry contact (Please refer to “<Note> Wire Handling” on page 27). When connecting a non-dry contact type of sensor (e.g. Open collector output) please contact WEBGATE’ s customer Support team. -
Page 27: Configuring Sensor At Osd Menu
9.1.3. Configuring sensor at OSD menu (1) Press the[Menu] button and select “Alarm Source”. (2) Press [▷] or [▼ ] button to move to Sub-Menu, select “Sensor” and press [▷]. 9.1.3.1. Global Use when selecting all 16 sensors simultaneously, which can be selected as “Do not use”(Off). “Normal Open”... -
Page 28: Connecting & Configuring Relay Out
Please refer to “Alarm Rec” for saving and “Alarm Act” for relay-out on the “eDVR User’ s Guide” 9.2. Connecting & configuring relay out 9.2.1. Specifications In order to run relay output of eDVR MD3200M normally, the following conditions are required. Output Ch. 4Ch relay differential outptus Output type Dry Contact Spec. -
Page 29: Connecting Relay Out
9.2.2. Connecting relay out Connect R1 ~ R4 with referring to the followings, It shows to connect a warming light. Please refer to “<Note> Wire Handling” on page 27. -
Page 30: Configuring Relay Out As Osd Menu
9.2.3. Configuring relay out as OSD menu. Relay can run by sensor or MD and its condition can be set differently according to schedule. When using the [Relay] button + [Number] button on the front panel or Control Center Lite-D S/W, relay can be operated from remote site. -
Page 31: Connecting Serial Port
9.3. Connecting serial port 9.3.1. Configuring serial ports for Pan/Tilt/Zoom The MD3200 series have most major PTZ protocols already pre-programmed. Makes and models not supported can still be controlled using the Transparent Protocol. For a list of supported protocols, refer to the list on the OSD Configuration menu. -
Page 32: Diagram Of Serial Ports
9.3.2. Diagram of serial ports 9.3.2.1. Diagram of COM1(RS232) 9.3.2.2. Diagram of COM2/COM4 9.3.2.3. Diagram of COM3... -
Page 33: Configuring Serial
9.3.3. Configuring Serial Configure PTZ COM ports and available models at “System/ Serial Setup” in MD3200 Series. After completing serial setup, configure base address or port for each channel at “ Camera menu” tab. When connecting PTZ devices to several cameras, be sure base address matches address for the camera. -
Page 34: Connecting External Device With Serial Port
The MD3200 Series can record text data received from POS/ATM through the COM/RS232 serial port. Connect to COM1/RS232 (9Pin D-Sub) of MD3200M and configure the “Serial Setup” sub-menu under the “System” tab and “Text” sub-menu under the “Alarm Source” tab shown as above figure. -
Page 35: Configuring Serial Setup (Com1) At Osd Menu
9.4.2. Configuring serial setup (COM1) at OSD menu (1) Set the “System” in OSD menu and move to “Serial Setup” menu. (2) Select COM in “Serial Setup”, set Devices as “Text”. (3) Set Baud Rate/ Parity/ Stop bit with referring to manual of the connected external device. -
Page 36: Configuring Text
9.4.3. Configuring text (1) Select the “Alarm Source” menu among OSD menus. (2) Select the “Text” and set each value. <Note> Before installing any external device, consult with the local WEBGATE distributor. Some external devices may not be compatible with the eDVR. -
Page 37: Connecting Usb Device
9.5. Connecting USB device USB port can be used to copy up to 1 minute of images to a USB Flash memory disk. When connecting USB Device, do not exceed the rated values of USB device as below; USB Spec. Ver 1.1 (Max 12M bps) Available Device USB Memory Stick,... -
Page 38: Connecting External Storage
<Note> MD3200 Series detect external HDD, even though MD3200 series run. If not, it is recommended to connect as follows; Power off MD3200M Connect external HDD to IEEE1394 port. Power on external device Power on MD3200M... -
Page 39: Available Hdd
10.3. Available HDD It is recommended to use following HDD models with the MD3200M. If a non-recommended HDD is used, WEBGATE Inc. will guarantee the warranty. 10.4. Registering & Formating HDD “Disk Manager” will automatically run on start-up installing a HDD as below;... -
Page 40: Network Monitoring & Managing
(9) Shut down “Disk Manager” by pressing [EXIT] button. 11. Network monitoring & managing MD3200M can be accessed, controlled, and managed from remote site using PC via Internet/ Intranet, which is same way as local access for controlling & monitoring features. -
Page 41: Configuring Network Infomraiton Of Md3200M
11.2. Configuring Network infomraiton of MD3200M The following description is based on Ethernet connection. For more detailed information on the Network setting page and way of using xDSL, please refer “eDVR USERS’GUIDE”. (1) Press [MENU] button (2) Select “System” using the [◀/▶] buttons and press the [▷] button. -
Page 42: Using Control Center Lite
12. Using Control Center Lite Control Center List is a DVR Management Software and it makes DVR installtion & setting more easier throguth a PC which is connected with DVR in Network. All configuration could be handled in OSD menu of DVR without a PC, however, Control Center Lite makes the complete setting more simply. 12.1. -
Page 43: Log-In
3> Select components which wish to install and press “Next” button. “WESP SDK” must be installed. 4>.Click the “Install” button after selecting a directory to be insatalled. 12.3. Log-In Enter User Name, Password and press “Ok” button. The factory default value : User Name:Administrator, Password:admin... -
Page 44: Configuration Tool
Click the icon on the desk top to run “Control Center Lite Configuration Tool”. 12.5. Monitor * Max. 5 users could be connected simultaneously in one unit of MD3200M. Click the icon on the desk top to run “Control Center Lite Monitor”. -
Page 45: Playback
12.6. Playback * Max. 2 user could be connected for playback in one unit of MD3200M. Click the icon on the desk top to run “Control Center Lite Playback”. -
Page 46: Appendix
APPENDIX APPENDIX APPENDIX... -
Page 47: Hdd
#1. HDD #1.1. Fundamental notions & terms eDVR storing constructure (VFS2) eDVR series has a peculiar storing constructure, and its features are as follows. (1) It is possible to connect 2 sets of HDD internally (Internal, ATA Interface) and 63 sets of HDD externally (External, 2 ports of IEEE1394 / External, 2 ports of eSATA / Storage Network). - Page 49 (2) HDD Type at Disk Manager Available recording status Connected and formatted as eDVR’ s file system. If using ‘Add Used’command, it will be changed to [R]. There is no need to format. Connected but not available eDVR’ s file system. After using ‘Add’, need to format for making as [R].
-
Page 50: Installing Hdd
#1.2. Installing HDD Compatible HDD It is recommended to use the following HDD models with the MD3200M. If a non-recommended HDD is used, WEBGATE Inc. will not guarantee the warranty. Installation and extension of internal HDD-RACK HDD In case of installation/adding or exchange HDD, follow the procedure as followings (1) Cut off the power to eDVR. - Page 51 <Note> When assemble HDD, the base of HDD should be HDD below. (5) After insertion of BRAKET that HDD installed to RACK, take the handle down to fix. (6) Rock HDD-RACK using KEY to complete installation When installing one primary disk...
- Page 52 (3) Select “Action” as “Add”, configure a size of alarm partition, and press “Apply” button. Then [F] is changed to [R]. (4) Press the [EXIT] button to shut down “Disk Manager”. (If recording schedule is set, MD3200M will start recording.)
- Page 53 When using Disk Farm The following description is when MD3200M has internal primary disk and 3 sets of IEEE1394 HDD. (1) When external HDD farm is connected to IEEE1394 port, “Disk Manager” runs automatically. If not, run it manually in “MenuUtilityDisk Manager”.
- Page 54 When using RAID The following description is when MD3200M has internal primary disk and 1 set of IEEE1394 RAID. <Note RAID> Even though several HDDs are connected to RAID, MD3200M will recognize them as only one HDD. For connection and setup of RAID, please refer to the manual of related device.
- Page 55 Replacing HDD Checking HDD MD3200M file system (VFS2) sensors bad sector automatically, and the sensored bad sector is not used. The following means when HDD is broken or has some problem in connection. (1) When playback is stopped or MD3200M is rebooted in specific playback range or image searching per event is impossible.
- Page 56 (5) Set backup range and press the “Start” button after selecting backup HDD. <Note> Backup HDD should be formatted as FAT32 type. Backup data can be replayed with specific S/W in PC such as Control Center Lite-D or MiniPlayer. Backup data is made as “*.re4” file and recognized as CD-R 700MB / DVD-R 4G per each file. Support CD-R backup and should be over CD-R 700MB / DVD-R 4G media.
- Page 57 Caution in using HDD For handling or guaranteeing HDD, WEBGATE follows HDD guaranty condition. WEBGATE doesn’t bear the responsibility about data loss by user’s mistake in operating. <Note> Attention for the system without HDD installed In case of system without HDD, HDD only can only be installed in R-HDD(Removable Hard disk rack).
-
Page 58: Using Cd-Rom
#2. Using CD-ROM Components of CD- ROM disc Installation Guide : eDVR MD3200M Installation Guide User’ s Guide : eDVR MD3200M User’ s Guide : Control Center Lite-D User’ s Guide Control Center Lite-D (Control Center lite-D Remote Management Program) Acrobat Reader : Version 7.0... -
Page 59: How To Recognize Manufacturing Date
Please see the below table for manufacturing month. The example of verifying manufacturing date using serial number The below S/N can be verified as following as: 『 D60507B22051 』 (1) “D6” means “MD3200M” product (2) “07B” means that it was manufactured on November of 2007... -
Page 60: Specification
#4. Specification General 32bit RISC Processor Flash memory 32MB 256MB Main memory Embedded LINUX Video channel 32Ch. analog video inputs via BNC connector NTSC or PAL video format are supported (Auto detect) Storage device Int.: 4 HDD bays including 2 hot swap-bay Ext: 2 IEEE 1394b (FireWire) connection ports* 2 eSATA connection ports 1 Network Storage port (RJ45)*... - Page 61 Daily : Day / Night / Four-segment time frame Schedule recording Weekly : Weekdays / Weekends, Exception days Conditions : Normal / Event Text Data recording POS/ATM transaction information archived along with corresponding video data Manual(Emergency) record triggered by font key Manual recording Audio Recording &...
- Page 62 -10 ~ 55℃ Storage temperature 30~80%, free of condensation Operation humidity 93% below, free of condensation Storage humidity Data Backup/Expansion/Copy External HDD(via 1394b or eSATA) Data backup Internal CD-R/DVD-R Backup reminder 5~ 95% alarm AVI Copy External USB memory disk(USB 1.1 compatible) on USB port Input/Output Video Output 4 CVBS main monitor...
- Page 63 Mechanical 430.0 x 362.0 x 88.0 mm Dimension (WⅹDⅹH) Weight 5.5 kg (with one HDD)
- Page 64 PelikanCam 555 West Lambert Road, Suite A Brea, CA 92821 Tel : (714) 672-0333 Fax : (714) 672-0360 sales@pelikancam.com www.pelikancam.com The contents of this manual can be modified in accordance with Firmware or Software upgrade. In the interest of continually improving products, approval & outlook can be modified without prior notice...
