Sony VAIO TX VGN-TX37GP/W Specifications

VAIO TX
VGN-TX37GP/W
Intel ® Centrino ® Mobile Technology
Platinum sophistication wherever you go
Specifications
Model VGN-TX37GP/W
Platform Intel ® Centrino ® Mobile Technology
1
• Intel ® Core ™ Solo Processor U1400 (1.20GHz)* • Intel ® PRO/Wireless 3945ABG Network Connection • Intel
Operating System Microsoft ® Windows ® XP Professional with Service Pack 2 (English version) Multilanguage User Interface (pre-installed Traditional Chinese)
Processor System Bus 533MHz
Memory Bus 533MHz
Cache Memory L1 Cache: 64KB L2 Cache: 2MB (on CPU)
2
Main Memory 1GB DDR2 SDRAM (512MB on board, upgradeable up to 1.5GB)*
1 SO-DIMM slot (The pre-installed memory module uses one)
3
Hard Disk 80GB (C: 30GB, D: 45GB, HDD recovery storage: 5GB* ) Ultra ATA/100
4
Optical Drive DVD±RW Drive (supporting DVD+R DL)*
Maximum reading speed: DVD+R, DVD-R, DVD+RW, DVD-RW, DVD+R DL: 4× / DVD-ROM: 8× / CD-RW: 12× / CD-R, CD-ROM: 24×
Maximum writing speed: DVD-RW: 2× / DVD+R DL, DVD+RW: 2.4× / DVD+R, DVD-R: 4× / CD-RW: 10× / CD-R: 24×
Graphics Accelerator Intel ® Graphics Media Accelerator 950
Video Memory Maximum 128MB (shared with main memory)
× 768) TFT colour display (Clear Bright LCD: White LED, Wide View)
Display 11.1˝ Wide (WXGA: 1366 ˝
• USB 2.0 × 2* 5
Interfaces • i.LINK (IEEE 1394) S400 (4 pin) • Network (RJ-45) connector (100BASE-TX/10BASE-T) • Headphone jack (stereo mini)
• Microphone jack (stereo mini) • Monitor connector (VGA, D-SUB 15 pin) • Modular (RJ-11) connector • Port Replicator connector
6
• Memory Stick slot* (Standard/Duo Size compatible, MagicGate compatible, Memory Stick PRO compatible, High-speed data transfer compatible)
7
• SD Memory Card slot* (MMC card compatible)
8
Wireless LAN • Integrated Wireless LAN IEEE 802.11a/802.11b/802.11g* • Intel ® PRO/Wireless 3945ABG Network Connection
9
• Data rate: maximum 11Mbps (802.11b)/54Mbps (802.11a/g)* • Frequency: 5GHz (802.11a), 2.4GHz (802.11b/g)
Security Chip TCG Ver 1.2 compliant Trusted Platform Module (TPM)
Fingerprint Sensor Built-in Fingerprint Sensor
® 9
Bluetooth • Bluetooth ® standard version 2.0+EDR* • Output: maximum +6dBm • Frequency: 2.4GHz
Modem V.92 and V.90 compliant
Type I/II × 1, CardBus support
PC Card Slot
Audio • Intel ® High Definition Audio compatible • 3D audio (Direct Sound 3D support) • Built-in stereo speakers
Keyboard / Input Device • 17mm Key pitch / 1.7mm Key stroke • 82 Keys • Intelligent Touchpad
10 11
Battery VGP-BPS5A* Lithium-ion battery: up to 9.5 hours of use*
Dimensions (W s × H × D) 272.4 × 21-28.5 × 195.1mm
Weight 1.25kg (including the supplied battery)
Software Applications • Adobe Reader 7 • Adobe Photoshop Elements 4.0 (Installer) • Adobe Premiere Elements 2.0
• Image Converter 2 Plus • Infineon TPM Professional Package 2.5 (Installer) • Instant Mode 1.1
• Roxio DigitalMedia SE 7 • Protector Suite QL 5.3 • PictureGear Studio 2.0
• SonicStage Mastering Studio Audio Filter 2.0 • VAIO Control Center 1.1
• VAIO Media 5.0 • VAIO Original Screen Saver • VAIO Recovery Utility 2.6
Supplied Accessories
• AC adapter (VGP-AC16V8) • Lithium-ion battery (VGP-BPS5A) • Headphone (MDR-Q22LP/S02)
12
Warranty One year*
Features and specifications are subject to change without notice.
*1 CPU speed will be reduced under certain operating conditions. *2 By removing the pre-installed 512MB memory module and adding one 1GB memory module.
*3 Necessary data for recovery (setting back to initial shipment settings) in the hard disk drive consuming approximately 5GB in size is available separately. *4 This
product is designed to playback discs that conform to the Compact Disc Digital Audio standard specifications (CD Standard). A DualDisc is a two sided disc product
which mates DVD recorded material on one side with digital audio material on the other side. Please be aware that the audio side (non-DVD side) of a DualDisc may not
play on this product because it does not conform to the CD Standard. *5 High-speed/Full-speed/Low speed compatible. *6 Compatibility confirmed with Sony branded
"Memory Stick" media only. *7 Does not support SD card's copyright technology. *8 Deploying IEEE 802.11b and IEEE 802.11g products on the same wireless network
may reduce the communication speed due to radio interference. Taking this into consideration, the IEEE 802.11g products are designed to reduce the communication
speed to ensure communication with IEEE 802.11b products. When the communication speed is not as fast as expected, changing the wireless channel on the access
point may increase the communication speed. *9 The communication speed varies depending on the distance between communication devices, existence of obstacles
between such devices, the device configuration, the radio conditions, and the software in use. In addition, communication may be cut off depending on the radio
conditions. *10 This product may only function with a genuine Sony battery designed for this model. *11 Estimated battery life (under JEITA Battery Run Time
Measurement Method (ver.1.0).) When the power-saving mode is on. Actual battery life may vary with different operating conditions and settings. For further details,
please visit vaio-online.sony.com *12 Warranty conditions may vary by region.
The trademarks, including but not limited to "SONY", "VAIO", "Memory Stick" and "SonicStage" are either trademarks or registered trademarks of Sony Corporation
and/or its subsidiaries. Adobe, Adobe Photoshop, Adobe Reader and Adobe Premiere are trademarks of Adobe Systems Incorporated in the United States and/or other
countries. Intel, Intel Inside, the Intel Inside logo, the Centrino logo, Centrino, Intel SpeedStep, Pentium, and Pentium Inside are trademarks or registered trademarks of
Intel Corporation or its subsidiaries in the United States and other countries. Microsoft and Windows are either trademarks or registered trademarks of Microsoft
Corporation in the United States and other countries. All other product and brand names may be trademarks or registered trademarks of their respective owners. Whilst
information given is true at time of printing, small production changes in the course of our company's policy of improvement through research and design might not
necessarily be included in the specifications. E&OE. Actual models may differ slightly in appearance to illustrations provided.
Windows Vista TM Capable PC
Buying a new PC that is Windows Vista TM Capable enables
you to upgrade, once available, to the next version of
Microsoft ® Windows ® and the future of computing.
For more information, please access:
http: //www.css.ap.sony.com/ vaio/ vista
This product is Windows Vista TM Capable PC.
vaio-online.sony.com
Sony recommends Microsoft
Windows ® XP Professional.
® 945GMS Express Chipset
VGN-TX37GP/W
1 2
7
9
10
12 13
17 18
19 20 21
24
• Click to DVD 2.5 • DVgate Plus 2.2
1. AV Mode button
2. Play/Pause button
• Norton Internet Security 2006
3. Stop button
• SonicStage 3.4 • SonicStage Mastering Studio 2.2
4. Previous track button
• VAIO Edit Components 6.0 • VAIO HDD Protection 1.1
5. Next track button
• VAIO Update 2.1 • VAIO Zone 1.4 • WinDVD 5 for VAIO 6. Disc eject button
7. Indicators
8. Network (RJ-45) connector (100BASE-TX/10BASE-T)
9. DC-IN connector
10. i.LINK (IEEE1394) S400 (4 pin) connector
11. Fingerprint sensor
12. USB 2.0 connector
PC Card Slot (Type I/II × 1)
13.
14. PC Card eject button
15. Modular (RJ-11) connector
16. USB 2.0 connector
17. Memory Stick slot
(Standard/Duo Size compatible, MagicGate compatible, Memory Stick
PRO compatible, high-speed data transfer compatible)
18. SD card slot (MMC card compatible)
19. Wireless LAN switch
20. Mute button
21. Volume buttons
22. Headphone jack (stereo mini)
23. Microphone jack (stereo mini)
24. DVD±RW drive (supporting DVD+R DL)
25. Manual eject hole
26. Disc eject button
27. Monitor connector (VGA, D-SUB 15 pin)
Optional Accessories for VGN-TX37GP/W
(availability depends on region)
VGP-PRTX1 VGP-UMS50
Port Replicator USB Optical Mouse
● DC-IN ● Stylish, easy-to-use sloping design
● Monitor connector (VGA, D-SUB 15 pin) ● Innovative PTFE sole for precise operation
● Network connector ● Sensor resolution: 800 dots per inch
● USB 2.0 connector (×3)
VGP-BPL5A VGP-CKTX1
Lithium-ion Battery Carrying Case
● Rechargeable battery ● Perfect size for VAIO TX
● Up to 16 hours battery life *11 ● Ideal slim, lightweight PC case
● Seven layer cushioning fabric
● Soft, luxurious feel in hand
®
3 4 5 6
8
11
14 15 16
22 23
25 26 27
