CH0600/1000 GB 30/07/99 14:00 Page 2
INTRODUCTION
This CD changer is designed for use only with car radios which have CD changer controls based
on the DIGITAL standard. Consult your dealer for suitable types of car radio.
The functions of the CD changer are described in the operating instructions for the car radio.
General
Precautions
........................................................................................................................................................................
Installation
Preparation
.......................................................................................................................................................................
Mounting
...........................................................................................................................................................................
Operation
...........................................................................................................................................................................
Troubleshooting
.............................................................................................................................................................
Specifications
...................................................................................................................................................................
Laser Product Class 1
GENERAL
PRECAUTIONS
WARNING: To prevent short-circuiting, disconnect the negative car battery terminal until the
whole system has been mounted and connected (fig. 1). See separate installation card.
Voltage and polarity: 12 V, negative earth.
• Do not attempt to repair or service the CD changer yourself. Return the unit, plus magazine
with the transport screws in place, to your dealer or an authorised Service Agency (see
addresses at the end of this booklet).
• Temperatures inside the parked car will fluctuate considerably during summer and winter.
They should not exceed +70°C or –20°C when operating the CD changer.
• To avoid too high temperature, never install the changer on top of the dashboard or on the
rear parcel shelf.
- If the temperature is too high, a built-in protection mechanism prevents the CD changer
from operating until the temperature reaches a safe level. During this time a warning
message is displayed by the car radio.
2
..................................................................................................................................................
English
2
3
5
7
9
10
10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CH0600, CH1000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for VDO CH0600, CH1000

  • Page 1 CH0600/1000 GB 30/07/99 14:00 Page 2 INTRODUCTION English This CD changer is designed for use only with car radios which have CD changer controls based on the DIGITAL standard. Consult your dealer for suitable types of car radio. The functions of the CD changer are described in the operating instructions for the car radio. General Precautions ..................................
  • Page 2: Installation

    CH0600/1000 GB 30/07/99 14:00 Page 3 INSTALLATION PREPARATION FIXING MATERIAL SUPPLIED Fig. 2 Only use screws and fixing material supplied! brackets (L) left and (R) right base-plates with screws (M6 x 20) and double-sided self-adhesive tape hexagonal bolts with washer (M5 x 10) hexagonal nuts (M6) tapping screws (5 x 12) F 12 round stickers for dust protection...
  • Page 3: Shock Absorber Adjustment

    CH0600/1000 GB 30/07/99 14:00 Page 4 SHOCK ABSORBER ADJUSTMENT The CD changer is pre-set at the factory for horizontal mounting (Fig. 7). If you mount the CD changer horizontally no adjustment is needed. In this case go to the next section “MOUNTING”.
  • Page 4 CH0600/1000 GB 30/07/99 14:00 Page 5 MOUNTING Caution: Take care not to drill into the fuel tank, the exhaust pipe system, the catalytic converter or the cables laying behind or below any drilled holes! • To prevent dust and dirt entering the unit, glue the supplied stickers F over all unused mounting holes of the CD changer (see Figs.
  • Page 5 CH0600/1000 GB 30/07/99 14:00 Page 6 MOUNTING CONNECTING THE CABLES (Fig. 20) Only use the cables supplied to connect the CD changer to the car radio! Ensure that the negative car battery terminal is disconnected. Connect the car radio as described in the car radio’s mounting instructions. Connect the blue plug C3 of the extension cable to the rear of the car radio (socket C3’) (fig.
  • Page 6: Operation

    CH0600/1000 GB 30/07/99 14:01 Page 7 OPERATION FILLING THE MAGAZINE Pull the tab on the magazine’s disc tray to remove one of the trays. Place the disc on the tray with its play surface facing up (label surface facing down). •...
  • Page 7: Handling Discs

    CH0600/1000 GB 30/07/99 14:01 Page 8 OPERATION HANDLING DISCS • Do not drop discs. • Keep discs free from dirt and fingerprints. Scratched discs may cause skipping of music parts. • Do not glue paper or labels on discs. • Do not write on discs. •...
  • Page 8: Troubleshooting

    CH0600/1000 GB 30/07/99 14:01 Page 9 TROUBLESHOOTING An error made in operation or in the connections is sometimes mistaken for a failure or breakdown. Perform the checks described in the following table before calling a Service Agency. Symptom Cause Remedy CD-Changer does not react.
  • Page 9: Specifications

    CH0600/1000 GB 30/07/99 14:01 Page 10 SPECIFICATIONS CH 0600 Power requirement: 14.4 V DC (11 – 16 V) Weight: 2.0 kg Dimensions (W x H x D): 263mm x 65mm x 175 mm CH 1000 Power requirement: 14.4 V DC (11 – 16 V) Weight: 2.2 kg Dimensions (W x H x D):...
