Vauxhall Zafira Quick Reference Manual

Electric windows 3: Luggage compartment:
Operated via 2 or 4 3 switches in the To unlock
driver's door. Front switches operate the
Press button q on the radio remote
front windows and rear switches 3
control and pull button beneath handle.
operate the rear windows.
Vehicles with Open&Start system 3 the
tailgate is unlocked automatically by
For incremental operation, briefly pull or
pulling the button beneath the handle
press the switch. For automatic opening
when the electronic key is in the external
or closing, pull or press switch for longer.
reception range of the vehicle.
Pull or press again to stop.
To hold the bonnet in the open position,
insert support rod located at right
angles above the radiator grille into the
small slot in the underside of the bonnet,
at its front edge.
Before closing bonnet, press support rod
firmly into its retainer. Lower the bonnet
gradually and then allow it to fall into
the lock under its own weight.
Check that the bonnet is locked in
position by pulling at its front edge. If it
is not engaged, repeat the procedure.
To open completely, locate safety catch
as viewed from the front:
lift upwards and open the bonnet.
Refuelling continued:
Before refuelling, switch off engine and if
applicable any auxiliary heating with
combustion chambers. Switch off mobile
phones.
To close, position fuel filler cap and
rotate past resistance until cap audibly
clicks over retainer. Close tank flap and
wipe off any overflowing fuel.
Petrol engines - use unleaded fuel only.
Refuelling:
Diesel engines - use diesel fuel meeting
Open tank flap, unscrew fuel filler cap,
specifications of DIN EN 590
remove and suspend from tank flap. The
fuel tank has a limiting system which
Fuel tank capacity (all models) - 56 litres.
prevents overfilling of the tank.
Bonnet:
Starting the engine:
To open the bonnet, pull the release
Manual transmission in neutral with
lever located below the instrument
clutch depressed, depress foot brake,
panel on the driver's side. The bonnet
automatic transmission 3 in P or N,
will then be unlocked and will partially
do not accelerate, (diesel engines; turn
open. Return release lever to its original
key to 2, wait for preheating indicator !
1)
position. to go out) , turn key to 3.
1)
Pre-heating system switches on only if
outside temperature is low.
Engine oil:
Check every 300 miles or prior to long
journeys.
Important:
It is the owner's responsibility to
maintain the correct level of an
appropriate quality oil in the engine.
Electronic immobiliser:
The vehicle checks whether the vehicle
may be started with the mechanical key
or electronic key of the Open&Start
system 3 that is being used. If the key is
recognised as "authorised" the vehicle
Easytronic transmission 3:
can be started.
Engine may be started only in P or N.
The electronic immobiliser activates
To move out of P; switch on ignition,
itself automatically after the key has
depress foot brake and pull up button
been removed from the ignition or with
on selecter lever.
the Open&Start system 3, when the
P: Only with vehicle stationary, first
engine is switched off by pressing the
apply hand brake
Start/Stop button.
R: Only with vehicle stationary
Tyre pressures:
Check tyre pressures, including spare
wheel, every 14 days and prior to any
long journey; tyres should be checked
when cold.
Release handbrake:
Raise handle slightly, press release
button, lower handle all the way.
Starting the engine continued:
Petrol engine: press button;
Diesel engine: briefly press button when
1)
control indicator ! goes out) , press
button again for 1 second; release
button when engine is running.
Press button again to repeat the starting
procedure or switch off the engine.
Only press briefly to switch on the
ignition if the brake or clutch pedal has
not been depressed.
Do not start unless vehicle is stationary.
Starting the engine: 1)
Pre-heating system switches on only if
Vehicles with Open&Start system 3 the
outside temperature is low.
electronic key must be within reception
range of interior. Manual transmission in
neutral with clutch depressed, depress
foot brake, automatic transmission 3 in
P or N, do not accelerate.
Manual transmission: Automatic transmission 3:
Engine may be started only in P or N.
Reverse gear: With vehicle stationary,
To move out of P; switch on ignition,
wait 3 seconds after declutching and
depress foot brake and pull up button
then pull up button on selector lever and
on selector lever. To engage P or R; pull
engage gear.
up button on selector lever.
P: Only with vehicle stationary,
first apply hand brake.
R: Only with vehicle stationary.
Tyre pressures (psi) Tyre pressures (psi)
for load of up to 3 persons: for load of up to 3 persons:
Engine Tyres Front Rear Engine Tyres Front Rear
1.6, 1.8 All except 29 29 1.9 All except 36 33
below below
225/40 R18 32 32 205/55 R16 35 32
Z 22 YH All except 32 29 225/45 R17
below 1.9 Vehicles 36 33
225/40 R18 35 32 with
Z 20 LER All except 36 33 automatic transmission
below & Panoramic roof
225/40 R18 38 35 All models
Z 20LEH All 36 33 Spare wheel 3 61 61
T 115/70 R16
Zafira
Quick Reference Guide
Refer to Owner's Manual for detailed information.
Instruments and controls
1. Side air vents 6. Turn signals, headlight flash, dipped
2. Front passenger's airbag and main beam, cruise control 3,
3. Centre air vents parking lights, door-to-door light
4. Hazard warning lights, Heated seats function 3
3, Deflation detection system 3, Tyre 7. Remote control for infotainment
pressure monitoring system 3, Parking system 3
distance sensor 3, Central locking
8. Instruments
system, SPORT mode 3
9. Horn
5. Display for time, date, outside
10. Windscreen wiper and wash system,
temperature and infotainment system
headlight wash system 3 and rear
3, check control 3, Trip computer 3,
window wash system
Climate control system 3
11. Parking lights, dipped beam,
instrument illumination, Fog tail light,
Fog lights 3, headlight range
adjustment 3
Vehicle security
Unlocking: Locking:
Press button q on remote control and Press button p on remote control.
pull door handle. Vehicles with the Vehicles with the Open&Start system 3.
Open&Start system 3, the vehicle is The electronic key must be in the
unlocked automatically by pulling a external reception range of the vehicle
door handle if the electronic key is in the
(approx. 1 metre). Touching the sensor
external reception range of the vehicle
in the driver or passenger side door
(approx. 1 metre).
handle locks the doors and luggage
compartment.
TS 1640-A-07
3
Note: some items described may be optional .
12. Bonnet release lever
13. Starter switch with steering wheel lock
14. Accelerator pedal
15. Brake pedal
16. Clutch pedal 3
17. Steering wheel adjustment 3
18. Star/stop button 3
19. Ashtray 3, cigarette lighter
20. Selector lever, manual transmission
Automatic transmission 3
21. Climate Control
22. Infotainment system 3
23. Glove compartment
Open&Start system 3:
Allows the vehicle to be locked /
unlocked providing the electronic key is
in the external reception range of the
vehicle (approx. 1 metre). Vehicle can
then be started using the start/stop
button providing the driver has the
electronic key on his person.
July 2006
