- Page 1 USER'S GUIDE Outdoor Mounting Kit PTU200MIK1 M210226EN-A...
- Page 2 The contents are subject to change without prior notice. Please observe that this manual does not create any legally binding obligations for Vaisala towards the customer or end user. All legally binding commitments and agreements are included exclusively in the applicable supply contract or Conditions of...
-
Page 3: Table Of Contents
Warranty ..................2 CHAPTER 2 PRODUCT DESCRIPTION................3 CHAPTER 3 PTU200MIK1 INSTALLATION ...............4 Installation when static pressure head is on the right side .5 Installation when static pressure head is on the left side..7 Connections in the transmitter box ........8 Probe installations..............9 HMP45 series ................9... -
Page 4: Chapter 1 General Information
Note highlights important information. It calls attention to an essential procedure, practice, condition or the like. Warranty Vaisala issues a guarantee for the material and workmanship of this product under normal operating conditions for one (1) year from the date of delivery. Exceptional operating conditions: damage due to careless handling and misapplication will void the guarantee. -
Page 5: Chapter 2 Product Description
CHAPTER 2 PRODUCT DESCRIPTION PTU200MIK1 mounting kit is for outdoor installation of the PTU200 transmitter and humidity probes HMP45/HMP233 or HMP 243. The kit consists of a protective transmitter box, a support arms, a radiation shield, the static pressure head, pole attachment clamps, a pressure pipe, and a pressure hose. -
Page 6: Ptu200Mik1 Installation
_______________________________________________________________________ UIDE CHAPTER 3 PTU200MIK1 INSTALLATION Plastic bag (2 pcs.) include: Clamp for pole mounting Plastic fitting ring Hex bolt (2 pcs.) M8x40 DIN 931 Washer (2 pcs.) A 8.4 DIN 125 Hex nut (2 pcs.) M8 DIN 934 Allen screw (2 pcs.) -
Page 7: Installation When Static Pressure Head Is On The Right Side
3___________________________________________________ PTU200MIK1 HAPTER INSTALLATION Installation when static pressure head is on the right side Installation plate Radiation shield 1.Mount the support arm on the upper clamp. Use the plate, two hex bolts and 2.Fasten the installation plate washers for the onto the support arm. - Page 8 _______________________________________________________________________ UIDE 7.Attach the pressure hose end to the threaded nipple of the pressure head. Threaded 8.Push the installation plate nipple. into the support arm. 9.Fasten the static pressure head to the end of the support arm (and installation plate) by using the two screws.
-
Page 9: Installation When Static Pressure Head Is On The Left Side
3___________________________________________________ PTU200MIK1 HAPTER INSTALLATION Installation when static pressure head is on the left side Boom adapter 3.Mount the support arm on the upper clamp. Fasten it by using the plate, two hex bolts and washers for the attachement as shown in the figure. -
Page 10: Connections In The Transmitter Box
_______________________________________________________________________ UIDE Connections in the transmitter box 1.Mount the PTU200 transmitter on the back plate of the transmitter box and attach it with the four Allen screws. 2.Thread the cables through the Allen key holes of the box and the gasket for opening body. -
Page 11: Probe Installations
3___________________________________________________ PTU200MIK1 HAPTER INSTALLATION Probe installations HMP45 series 1. Push the HMP45 probe through the plastic nut to the radiation shield as deep as it goes. 2. Pull back about 10 mm. 3. Finally, tighten the plastic nut. HMP233 series 1. -
Page 12: Hmp243 Series
_______________________________________________________________________ UIDE HMP243 series 1. Attach the HMP243 probe to the support with an upper cable tie. 2. Press the probe cable into the groove of the support. 3. Fasten the lower cable tie. 4. Push the probe through the plastic nut into the radiation shield as deep as it goes. -
Page 13: Ptu200Tripod Installation
4_________________________________________________PTU200TRIPOD HAPTER INSTALLATION CHAPTER 4 PTU200TRIPOD INSTALLATION Place the pole onto the tripod stand and fasten it with the attachment screw. The handle of the screw is under the center of the stand. The legs of the stand are adjustable. To release the leg, lift the grip upwards. -
Page 14: Dimensions In Mm (In Inches)
_______________________________________________________________________ UIDE CHAPTER 5 DIMENSIONS in mm (in inches) Static pressure head on the left side 1136 44.7244 5.748 22.185 16.5354 12 __________________________________________________________________ N 2001 OVEMBER... -
Page 15: Static Pressure Head On The Right Side
5__________________________________________________ D HAPTER IMENSIONS IN MM IN INCHES Static pressure head on the right side 1134 44.626 5.748 16.5354 21.0039 _________________________________________________________________________ 13 AISALA... - Page 18 www.vaisala.com...
