Dot Hill Systems RAIDCore User Manual page 45

Element
10. More Driver Disks? window
11. Choose a Language window
12. Keyboard Type window
13. Installation Method window
14. Installation Number window
15. Skip dialog box
16. Warning dialog box
17. Red Hat Enterprise Linux 5
window
18. RAIDCore array check box
19. Warning dialog box
20. Region window
21. Root account window
Action
a. Tab to No.
b. Click Enter.
NOTE: If the Arrays section of the BIOS Configuration Utility
contains more than one array, increase sdb to sdx. For example, if
there are two virtual disks, increase sdb to sdx.
NOTE: If an Error Downloading Kickstart File window appears,
modify the kickstart parameter. Tab to OK. Click Enter.
a. Choose the default language (English).
b. Tab to OK.
c. Click Enter.
a. Choose the default keyboard type (US).
b. Tab to OK.
c. Click Enter.
a. Choose the default installation method (Local CDROM).
b. Tab to OK.
c. Click Enter.
a. Choose one of the following:
• Enter Installation Number:
• Skip entering Installation Number
b. Click OK.
Click Skip.
If the text is OK, click Yes.
NOTE: If No is selected, the bootable array created in step 3 will
not be used.
Choose Remove all partitions on selected drivers and create
default layout from the pull-down menu.
a. Check the check box next to the RAIDCore array that was created in
the BIOS Configuration Utility.
b. Un-check the check-box(es) next to other arrays.
c. Click Next.
Click Yes.
a. Mouse-over the world map, or use the pull-down menu, and choose
the applicable time zone.
b. Click Next.
a. Enter the applicable root password.
b. Re-enter the root password.
c. Click Next.
RAIDCore User Manual 43
