Eco Drive V5-H Series Manual

Sensorless vector control (field-oriented control) frequency inverters, pid feedback closed loop control
Hide thumbs
Table of Contents

Advertisement

Quick Links

V&T Technologies Co., Ltd.
http://www.ecodrivecn.com
Foreword
The V5−H series inverter is a kind of high-performance vector control inverter
provided by V&T Technologies Co., Ltd. The product adopts speed sensorless
vector control technology technology, the internationally leading technology, to
offer
excellent
control
performance
and
combines
the
application
characteristics of China to further enhance the product reliability, environment
adaptability and customized and industrialized design. It can better meet the
demands of the various drive applications.
