Bloomfield F-1725 Features And Specifications

W M
E L L S A N U F A C T U R I N G
F-1725 COUNTERTOP FRYER
F-1725

Specifications

Overall Dimensions:
Width
Depth
Height
(incl. 4" legs)
Oil Capacity:
F-1725
Temperature Range:
F-1725 275º to 375º 135º to 191º
Pre-Heat Time to 350˚ F: 6 minutes
Watts Per Hour to Maintain 350˚ F:
Typical Production:
French Fries
(2 oz. servings)
Chicken
(pounds)
Weights:
Installed
Shipping
Accessories / Options
Basket, half-size (2 per fry pot), 20820
Fry Pot, replacement, 20519
Legs, set of four, metal,
4" adjustable, 20563
Wells F-1725 Countertop Fryer is one of the most
durable and versatile fryers in the industry. A swing-up
element allows the fry pot to be easily removed for
cleaning, and the low watt density provides for extended
oil life. Fry two separate loads at the same time using
the individual fry baskets. The unique STS (Safety
Test System) can be used to periodically check the
temperature-limiting thermostat.
Inches MM
15 381
29 1/2 749
18 457
Lbs. KG
40 18
Fahrenheit Celsius
760
Per Hour
900
60
Lbs. KG
82 37
85 39
I T E M N O .
Features
• Swing-up element, located below the baskets,
allows easy removal of the fry pot for cleaning.
Element is heavy-duty stainless steel with low
watt density for longer oil life.
• Element control housing has a spring-loaded
support rod to secure element when in a
raised position.
• A positive-off thermostat controls the element
allowing for adjustable and more consistent
temperatures. A signal light indicates that the
heating element is energized.
• Removable fry pot is made of nickel-plated steel
and can hold up to forty pounds of oil.
• A manual reset safety thermostat will shut off the
heating element power and illuminate the signal
light if an over-temperature condition is reached.
• A terminal block is provided for field wiring
connection to the main power supply.
• The F-1725 is provided with a front-mounted
Safety Test System (STS) to enable periodic
checks of the temperature-limiting thermostat.
• An auxiliary terminal block allows for
connection to an external flame sensor fire
suppression system.
• Two half-size, rear-hanging, interchangeable
fry baskets are provided and allow for
product versatility.
• The F-1725 Fryer is Underwriters Laboratories,
Inc. LISTED and meets NSF International standards.
• A one-year warranty against defects covers
parts and labor.
WELLS
