Bacharach Microprocessor Module Replacement Kit Instruction Manual

For portable area gas monitors (pagms)
Hide thumbs Also See for Microprocessor Module Replacement Kit:
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

See also: Instruction Manual
Microprocessor Module Replacement Kit
for Portable Area Gas Monitors (PAGMs)

1. Scope

The Bacharach PAGM family of portable area gas monitors is designed for easy maintenance and enhancement. One
element of that design is the ability to replace system programming (firmware) with a simple plug-in microprocessor
module, minimizing downtime.
This instruction manual describes how to replace or upgrade the microprocessor module in your PAGM infrared gas leak
detector. It is assumed that the user is familiar with the operation of the device. If necessary, refer to the instructions for
detailed operation and maintenance information for each PAGM model.

2. Items Required

•
Replacement Microprocessor Module Kit (P/N: 3015-5579)
•
Medium Phillips head screwdriver
•
Original PAGM instruction manual (optional)
3015-5576 Rev 2
621 Hunt Valley Circle
New Kensington, PA 15068
Tel:
724-334-5000
Fax:
724-334-5001
Instruction Manual
3015-5576
Revision 2
May 2013
