Turning Pens
Instructions
Euro Twist Pen Kits Booklet
www.axminster.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Euro Twist Pen Kits and is the answer not in the manual?

Questions and answers

Summary of Contents for Axminster Euro Twist Pen Kits

  • Page 1 Turning Pens Instructions Euro Twist Pen Kits Booklet www.axminster.co.uk...
  • Page 2: Table Of Contents

    European Style Twist Pen Kits..............................02 What’s in the Kit....................................02 Preparing the Bodies..................................03 Turning the Bodies...................................04-05 General Assembly................................05-06-07 Axminster Pen Mandrels................................08 Notes....................................... 9-10 The symbols shown on the cover of this SAFETY!! manual advise that you wear the correct safety protection.
  • Page 3: Instruction For Artisan European Style Twist Pen Kits

    990095 Recommended Accessories Quick Action Pen Blank Vice 600771 Pen Blank Sizing and Cutting Jig 600623 Axminster Pen Assembly Press 200205 European Style Twist Pen Kits... Kit No. 310404 10ct European Pen Kit (A logo) Kit No. 341096 24ct European Pen Kit Kit No.
  • Page 4: Preparing The Bodies

    Using the Barrel Trimmer trim the ends of the blanks squarely and neatly to the ends of the brass tubes; this will also remove any excess glue that may have exuded from the joint. Take care not to undercut the brass tubes. www.axminster.co.uk...
  • Page 5: Turning The Bodies

    Turning the Bodies... Slide 2 or 3 of the mandrel spacers onto the shaft. Add the Cap Bushing from the Bushing Kit. Mount the Upper Pen Body next, then the Centre Bushing, (mount the centre bushing so that the smaller diameter mates against the Upper Pen Body. You may wish to mount the Dummy Centre Band Bushing onto the smaller diameter at the same time.(See Note below).
  • Page 6: General Assembly

    Fig 4 General Assembly ... Note. The Axminster Pen Assembly Press (Part no. 200205) is a very useful accessory for these operations, as it gives greater control over the applied force and keeps the components in line. Put a couple of drops of glue (added security) on the Centre Band and press it on to the prepared journal at the lower end of the Upper Pen Body.
  • Page 7 General Assembly ... Fig 6 21mm Twist mechanism Ballpoint refill Line up the components for the Upper Pen Body. Ensure the Pen Clip Cap Threaded Anchor is correctly oriented (there is a small ‘lead’ on the ‘insert’ end), and aligned with the body. Gently but firmly press it home flush with the end of the body.(Force Fit) See Fig 7.
  • Page 8 ‘friction fit joint’ . Bad alignment etc, could cause the friction fit to deteriorate over time with the subsequent loss of adhesion allowing the pen to separate randomly. www.axminster.co.uk...
  • Page 9: Axminster Pen Mandrels

    Axminster Pen Mandrels... These mandrels are machined with either parallel or Morse taper mounting and have a shoulder to assist with removal. They are supplied with a number of spacers for locating the pen components. See our catalogue for details as to whether or not you will need to purchase additional bushings for the project that you have chosen.
  • Page 10: Notes

    Notes... www.axminster.co.uk...
  • Page 11 Notes... 0800 371822 FREEPHONE...
  • Page 12 Turning Pens Instructions (Euro Twist Pen Kits Booklet) Axminster Devon EX13 5PH UK FREEPHONE 0800 371822...
