SST-64P PCI Adapter
and Subsystem
Installer/User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SST-64P and is the answer not in the manual?

Questions and answers

Related Manuals for Avocent SST-64P

Summary of Contents for Avocent SST-64P

  • Page 1 SST-64P PCI Adapter and Subsystem Installer/User Guide...
  • Page 2 USA Notification Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
  • Page 3 SST-64P PCI Adapter and Subsystem Installer/User Guide Avocent and the Avocent logo are registered trademarks of Avocent Corporation or its affiliates. All other marks are the property of their respective owners. © 2006 Avocent Corporation. All rights reserved. 590-629-501A...
  • Page 4 Instructions This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. Dangerous Voltage This symbol is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

  • Page 5: Table Of Contents

    Part Numbers ............................. 3 Chapter 2: Installation and Configuration ..............5 Getting Started ........................... 5 Items supplied with the SST-64P PCI adapter ................5 Additional items needed......................5 Installing the SST-64P PCI Adapter ....................6 Installing Port Modules ........................7 Port Module LEDs ..........................
  • Page 6 SST-64P PCI Adapter Installer/User Manual...

  • Page 7: List Of Figures

    Figure 2.2: Port Module ........................7 Figure 2.3: Port Module Mounting Options..................8 Figure 2.4: SST-64P PCI Adapter - Host Bus Cable - Port Module..........8 Figure 2.5: SST-64P PCI Adapter with Four Port Modules Connected using HBCs....... 9 Figure 2.6: 100 Foot (30.5 m) EBC....................9 Figure 2.7: Port Modules Extended Distance Using EBCs.............
  • Page 8 SST-64P PCI Adapter Installer/User Manual...

  • Page 9: Chapter 1: Product Overview

    The SST-64P PCI Adapter The SST-64P PCI adapter (see Figure 1.1) occupies one PCI slot in the host computer and provides the intelligent communications functions to “off-load” the CPU from serial communications processing tasks.

  • Page 10: Compatibility With Prior Models

    You can also use rack-optimized port modules with prior model SST-64P adapters and port modules. Low profile SST-64P PCI adapters may be installed together with prior model SST PCI adapters in the same server.

  • Page 11: Part Numbers

    (for example, use of power strips). Part Numbers Table 1.1 lists part numbers for the SST-64P PCI adapter, port modules, power supply, modular adapters and cables. Table 1.1: SST-64P PCI Adapter Part Numbers...
  • Page 12 SST-64P PCI Adapter Installer/User Manual...

  • Page 13: Chapter 2: Installation And Configuration

    SST-64P PCI adapters into system memory. The device driver soft-configures all SST-64P PCI adapters each time you start (boot) your computer. Before installing your SST-64P PCI adapter, refer to the following list to ensure that you have all the items necessary for your installation.

  • Page 14: Installing The Sst-64P Pci Adapter

    Installer/User Manual SST-64P PCI Adapter Installing the SST-64P PCI Adapter The following procedure describes how to physically install your SST-64P PCI adapter in your computer. Alternatively, you can follow the installation instructions provided in your host computer documentation. To install the SST-64P PCI adapter: Turn off the host computer and disconnect the power cord.

  • Page 15: Installing Port Modules

    The 26-pin expansion bus port is a ring topology, which contains dedicated time slots for 64 ports of full-duplex serial data. The last port module connected to the adapter terminates the ring. Two types of expansion bus cables are provided to connect port modules to SST-64P PCI adapters: •...

  • Page 16: Using Rack Mount Ears

    Figure 2.4: SST-64P PCI Adapter - Host Bus Cable - Port Module Using 4-foot and 1-foot HBCs You can connect up to four port modules to the expansion bus port of the SST-64P PCI adapter using Host Bus Cables (HBCs). First, interconnect the port modules from the OUTPUT connector of one to the INPUT connector of the next using 1-foot HBCs.

  • Page 17: Using Ebcs

    POWER POWER ONLINE Figure 2.5: SST-64P PCI Adapter with Four Port Modules Connected using HBCs Using EBCs You can place port modules farther than the supplied 4-foot (1.2m) HBC allows by replacing the HBC with an EBC. As shown in Figure 2.6, a group of four port modules are located 100 feet (30.5m) from the host computer using an EBC.

  • Page 18: Power Options

    To AC Power Source Figure 2.7: Port Modules Extended Distance Using EBCs NOTE: The maximum distance between the SST-64P PCI adapter and the first port module is 100 feet (30.5m). The maximum distance between port modules is also 100 feet (30.5m).

  • Page 19: Figure 2.8: Default Power Jumpersettings

    Chapter 2: Installation and Configuration SST-64 adapter jumper settings The default power jumper setting, shown in Figure 2.8, selects the PCI bus as the power source for attached port modules. Refer to Table 2.1 for more jumper settings. Power LED HDR6 Expansion Bus Connector HDR6...

  • Page 20: Figure 2.9: Connected Port Modules Draw Power From Host

    OFF. HDR6 In simple configurations, the SST-64P PCI adapter supplies power to all port modules attached to the expansion bus through the supplied 4-foot (1.2m) HBC (see Figure 2.9). The SST-64P PCI adapter provides power through the HBC to the first port module and to the next port module through the 1-foot HBC.

  • Page 21: Figure 2.10: Ps-4 Supplying Power To Port Modules

    Port modules connected to an EBC (not an HBC) must be externally powered using the PS-4 optional power supply (PN 990274). Connect the power supply (purchased separately) to the first port module on the expansion bus (see Figure 2.10). SST-64P PCI Adapter Port Modules 100 Feet (30.5m)
  • Page 22 Installer/User Manual SST-64P PCI Adapter...

  • Page 23: Chapter 3: Port Module To Device Cabling

    (DB-25, DB-9, DTE and DCE) using 10-wire modular serial cables. All serial ports provide a standard RS-232 interface with full modem control signals. To help wire the serial ports, Avocent sells a complete set of cabling accessories. Refer to SST-64P PCI Adapter Part Numbers on page 3.

  • Page 24: Figure 3.2: Rj-45 Jack Pinouts

    Installer/User Manual SST-64P PCI Adapter Figure 3.2: RJ-45 Jack Pinouts Please note the following cabling considerations: • All port module jacks face toward the front with the key on the bottom. Refer to Figure 3.3, Figure 3.4 and/or Figure 3.5 for modular jack cable pinouts.

  • Page 25: Figure 3.4: Cable Pinouts For Rj-45 To Pc Db-9

    Chapter 3: Port Module to Device Cabling Figure 3.4: Cable Pinouts for RJ-45 to PC DB-9 Figure 3.5: Cable Pinouts for RJ-45 to Modem DB-25...

  • Page 26: Modular Cables

    RJ-45 modular plug (connector) which is inserted into the modular jack of an appropriate wiring module. Standard modular cables available from Avocent are reversing. That is, the pins are reversed on each end so that pin 1 on one end is connected to pin 10 on the opposite end.

  • Page 27: Figure 3.7: Ten-Wire Modular Adapters Internal Wiring

    Chapter 3: Port Module to Device Cabling Figure 3.7: Ten-wire Modular Adapters Internal Wiring...
  • Page 28 Installer/User Manual SST-64P PCI Adapter...

  • Page 29: Index

    Ambient Temperature 2 INPUT connector 8 installation instructions 6 installation manuals 1, 6 booting your computer 5 installing port modules 7 installing the SST-64P PCI adapter 6 cable diagrams 18 cables 2 Linux 1 Circuit Overloading 2 connecting serial devices 8...
  • Page 30 7, 8 SST 1 power for the downstream port modules 7 SST-64P PCI Adapter 1, 6 power jumpers 10 SST-64P PCI adapter 1, 2, 5 power LED 7 SuperSerial Proccessor 1 power LED indicator 7 SuperSerial Technology (SST) 1...
  • Page 31 For Technical Support: www.avocent.com/support Avocent Corporation Avocent International Ltd. 4991 Corporate Drive Avocent House, Shannon Free Zone Huntsville, Alabama 35805-6201 Shannon, County Clare, Ireland Tel: +353 61 715 292 Tel: +1 256 430 4000 Fax: +353 61 471 871 Fax: +1 256 430 4031 Avocent Germany Gottlieb-Daimler-Straße 2-4...
