Summary of Contents for Planet UPS-400
- Page 1 400 Watts UPS Redundant Power for WGSW-2620PV UPS-400 User’s Manual...
- Page 2 Copyright PLANET Technology Corp. 2005~2006. Contents subject to which revision without prior notice. PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners. Disclaimer PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for a particular purpose.
- Page 3 Rev: 1.0(December.2005) Part No. 2011-A92340-000...
-
Page 4: Table Of Contents
Table of Content Chapter 1 Introduction ..............4 1.1 Product Description............4 1.2 Packet Contents ............... 4 1.3 Features ................5 1.4 Specifications ..............5 1.5 Software Feature.............. 5 1.6 Product Outlook..............6 1.7 LED Definition ..............6 Chapter 2 Installation ..............7 2.1 Hardware Installation............ -
Page 5: Chapter 1 Introduction
48V DC by the UPS-400 Uninterruptible Power Supply. Once both the AC and the DC are used, the UPS-400 take the UPS-400 as the redundant power supply for power backup to prevent the power interrupt. This protects the critical data from the PoE devices powered by the WGSW-2620PV and keep the network alive for the data transmission. -
Page 6: Features
Provide DC 48V for Power over Ethernet equipment 1 U height design 19” rack mountable FAN detect through RS-232 1.4 Specifications Model UPS-400 Power Input 100~240V AC, 50/60Hz, 5A max. Power Consumption 500 watts (system) Output DC Power 48V DC, 400 watts output capability... -
Page 7: Product Outlook
1.6 Product Outlook Front Panel Rear Panel 1.7 LED Definition AC Input: Lights to indicate the UPS-400 is powered. Fault: Lights to indicate the fan is failed, system over temperature, or over load. DC Output: Lights to indicate UPS-400 is providing power. -
Page 8: Chapter 2 Installation
Chapter 2 Installation 2.1 Hardware Installation To install the UPS in a 19-inch standard rack, please follows the instructions described below. Step1: Place the switch on a hard flat surface, with the front panel positioned towards the front side. Step2: Attach the rack-mount bracket to each side of the UPS with supplied screws attached to the package. -
Page 9: Battery Charge Up
1. Connect the UPS to the 100~240V AC power outlet to get power. 2. Click on the ON/OFF button on the front panel for over 5 seconds to power on the UPS-400. The system is started up by a "beep" buss. The "AC input" and the "DC output" LED then lighted up. - Page 10 [NOTE] When the Managed Power Supply unit AC power is down, the internal UPS can provide the power to connected POE switch for 30 seconds in full power consumption and 30 minutes in only switch basic operation.
-
Page 11: Chapter 3 Operation
WGSW-2620PV and the data loading on the network. 3.2 UPS Status Monitoring The UPS-400 passes its status information to the WGSW-2620PV by the console cable. To view the status from the web interface, please make sure the console cable is well connected between the WGSW-2620PV and UPS-400. -
Page 12: Chapter 4 Specifications
Chapter 4 Specifications Battery: 4 * 12V 2.2Ah Valve Regulated Lead-Acid Batteries. Charging Instruction Type Voltage Regulation Initial Current Stand-by Use 13.5 – 13.8V No Limit Cycle Use 14.4 - 15.0V 0.66A max Maximum charging current: 0.58A Charging voltage: 14.4 to 15.0V Float charging voltage: 13.50 to 13.80V Volts: 12 Nominal Capacity (20 Hr Rate - Ah): 2.25...
