KOB KPB 2200-1 Spec Sheet

Burner Slide-out System [Art. No. KPM-E-OBA / 7387410]
For left- or right-hand side installation on the PYROMAT; manual retraction of the burner against spring pressure; when
pulled out, a weighted shutter closes automatically, thus protecting the burner from soiling; protected by a limit switch.
Flange diameter, inside:
Hole circle diameter:
Retracting stroke:
Weight without burner:

Scope of delivery:

- 1 limit switch mounted on slide-out system
1 limit switch uninstalled, for installation by the customer on filler lid
-
burner when moved out
with shutter closed
(wood-burning operation)
Köb Holzheizsysteme GmbH, Flotzbachstr. 33, A-6922 Wolfurt, Tel. +43/5574/6770-0, Fax 65707, E-Mail: office@kob.cc
Spec Sheet
Accessories for the PYROMAT-ECO
Functions of the boiler
128 mm
150 mm
160
24 kg
burner when moved in
(oil-burning operation)
Subject to technical changes
insulation
boiler casing
weighted shutter
2200-1
2009-03-01_GB
limit switch
