VLRM24
V L R M 2 4 / 5 8
MIMO Wireless Solutions
Installation and Operation Instructions for the following models:
VLRM24
Wireless 2.4GHz MIMO access point, 120Vac input (Power supply) 24Vdc POE.
VLRM58
Wireless 5.8GHz MIMO access point, 120Vac input (Power supply) 24Vdc POE.
Before attempting to connect or operate this product, please read these instructions completely.
VLRM58
www.videolarm.com
81-IN5468
02-10-2011
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Moog Videolarm VLRM24
- Page 1 © 2011, Moog Videolarm, Inc. All Rights Reserved VLRM24 VLRM58 V L R M 2 4 / 5 8 MIMO Wireless Solutions www.videolarm.com Installation and Operation Instructions for the following models: VLRM24 Wireless 2.4GHz MIMO access point, 120Vac input (Power supply) 24Vdc POE.
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS SAFETY PRECAUTIONS Read these instructions. Keep these instructions. CAUTION Heed all warnings RISK OF ELECTRIC SHOCK DO NOT OPEN Follow all instructions. Do not use this apparatus near water. CAUTION: TO REDUCE THE RISK OF Clean only with damp cloth. ELECTRIC SHOCK, DO NOT REMOVE COVER ( OR BACK). -
Page 3: Limited Warranty
LIMITED WARRANTY FOR VIDEOLARM INC. PRODUCTS VIDEOLARM INC. warrants this Product to be free from defects in material or workmanship,as follows: PRODUCTCATEGORY PARTS LABOR All Enclosuresand Electronics Five (5) Years Five (5) Years Pan/Tilts Three (3) Years **6 months if used in autoscan Three (3) Years **6 months if used in autoscan /tour operation /tour operation... -
Page 4: Electrical Specifications
Power Supply: 24Vdc, .5A POE Supply Included Max Power Consumption: 6.5 Watts (2.4GHz) 8 Watts (5.8GHz) Power Method: Passive Power over Ethernet (pairs 4,5+; 7,8 return) VLRM24 English An all pole main switch with a contact of at least 3mm in each pole shall be incorporated in the electrical installation of the building. -
Page 5: Product Description
Product Description The VLRM24/58 is a Wi-Fi Station with WPA and WPA2 supplicant support. It is specially designed to act as a Transparent Wireless Bridge that associates to a service provider and authenticates using 802.1x, if required, on start up. -
Page 6: Led Description
NOTE - Connection to the VLRM24/58 will be lost if the IP address is changed at this time. A connection will need to be made to the new IP address that has just been assigned in order to view the configuration page again. -
Page 7: Wireless Configuration
Wireless Configuration Click on the Wireless tab on the configuration page. Note that the unit is set to a Wireless Mode of Access Point and the default SSID for the wireless network is set to videolarm. The default SSID can be changed by clicking in the SSID box, typing in the new SSID that is required, and clicking on the Change button at the bottom right hand corner of the window. - Page 8 NOTE - Connection to the VLRM24/58 will be lost if the IP address is changed at this time. A connection will need to be made to the new IP address that has just been assigned in order to view the configuration page again.
- Page 9 Changing Wireless Mode Change the Wireless Mode to Access Point WDS. Place a check mark in the Auto box beside the selection. Connect to the second device and complete the proceeding steps. In most cases the units will connect to one another using the Auto mode.
- Page 10 For your convenience and future reference, the following form has been included to record your wireless surveillance systems IP and Mac addresses. Once completed, remove the form from instruction packet and place in a secure place or inside the Moog Videolarm wireless product. The information recorded will prove bene cial when servicing or expanding your wireless system.
