REMOTE CONTROL
Thermostat
Thermostat
Remote Control
Remote Control
& Receiver
& Receiver
Allows remote control operation of
basic thermostat functions
Unique 'Warmer & Cooler' commands
Compatible with thermostat models:
T1700, T1800, T1900, T2700, T2800 T2900
Consult VENSTAR for a complete list.
OWNER'S
OWNER'S
MANUAL
MANUAL
Venstar Inc. 08/07
/RECEIVER
ACC0431
Advertisement
Related Manuals for Venstar ACC0431
Summary of Contents for Venstar ACC0431
-
Page 1: Remote Control
& Receiver & Receiver Allows remote control operation of basic thermostat functions Unique ‘Warmer & Cooler’ commands Compatible with thermostat models: T1700, T1800, T1900, T2700, T2800 T2900 Consult VENSTAR for a complete list. OWNER’S OWNER’S MANUAL MANUAL Venstar Inc. 08/07... - Page 2 Overview This accessory allows for the remote operation of the most basic thermostat functions. There are five buttons on the remote control. One for Off, two for Fan control, one for Warmer and one for Cooler. The communication from the remote control to the receiver is uni-directional, without feedback to the user.
- Page 3 Operation Press the Warmer or Cooler buttons and the heating - cooling system will operate as outlined in pages 4 through 8. If the thermostat was off prior to a Warmer or Cooler button press, the system will turn on in the last mode (Auto or Manual changeover) of operation prior to pressing Off.
- Page 4 Warmer & Cooler Commands in Manual Changeover If the thermostat is configured for Manual Heat/Cool changeover: WARMER button press while in Heat or Off mode: When the thermostat receives a Warmer command (button press) through the remote control and the heater is not running, the set point will be raised above the room temperature to start the heater operation.
- Page 5 Warmer & Cooler Commands in Manual Changeover If the thermostat is configured for Manual Heat/Cool changeover: COOLER button press while in Cool or Off mode: When the thermostat receives a Cooler command (button press) through the remote control and the air conditioner is not running, the set point will be lowered below the room temperature to start the cooling operation.
- Page 6 Warmer & Cooler Commands in Auto Changeover If the thermostat is configured to Auto Heat/Cool changeover: WARMER button press while in Auto or Off mode: When the thermostat receives a warmer command (button press) through the remote control, and the heater is not running, the set points will be raised to start the heater operation.
- Page 7 Warmer & Cooler Commands in Auto Changeover If the thermostat is configured to Auto Heat/Cool changeover: COOLER button press while in Auto or Off mode: When the thermostat receives a Cooler command (button press) through the remote control and the air conditioner is not running, the set points will be lowered to start the air conditioning operation.
- Page 8 Examples of Typical Operation The following 3 examples illustrate operation when the thermostat is Off. Example #1 The thermostat was turned off the prior day while in Auto changeover mode. The following will occur if the Warmer button is pressed while the thermostat is off: The thermostat changes from Off to Auto.
- Page 9 Connection eries PLATINUM COMMERCIAL PROGRAMMABLE THERMOSTAT I2:00 AUTO Accessory release button MODE HUMIDITY PROGRAM HOLIDAY OVERRIDE SET CLOCK OUTDOOR Accessory jack located on thermostat bottom To connect the IR Receiver to the thermostat; insert the IR receiver plug into the accessory Jack of the thermostat.
- Page 10 Remote Control Battery Replacement Front View Rear View Battery Door Replace battery with CR 2025 or equivalent. A replacement remote control may be purchased separately, P/N ACC0433 Page 10...
-
Page 11: Warranty
Warranty One-Year Warranty - This Product is warranted to be free from defects in material and workmanship. If it appears within one year from the date of original installation, whether or not actual use begins on that date, that the product does not meet this warranty, a new or remanufactured part, at the manufacturer’s sole option to replace any defective part, will be provided without charge for the part itself provided the defective part is returned to the distributor through a qualified servicing dealer.
