Fostex Manual MN04 Owner's Manual page 3

CONNECTING THE AC ADAPTOR/INSTALLING THE BATTERY
DC IN jack
<NOTE>
Unplug the AC adaptor from the wall outlet if the MN04 is not to be
used for long hours or extensive periods of time.
INTERCONNECTING EXAMPLE WITH EXTERNAL EQUIPMENT
As shown in example below, by interconnecting MN04 as a sub mixer with a multitracker having few input ports, a multitude of sound sources
can then be mixed and recorded by the multitracker.
MN04
MIC MIC
LINE ALC ON
PAN PAN
R L R
10
10
5 5
0 0
1 2
Sound source 1
Sound source 2
BLOCK DIAGRAM
COMP
ALC
CH1
-10dBV
-60dBV
CH2
-10dBV
CH3
-10dBV
CH4
-10dBV
Plug the AC adaptor cable
into the MN04 DC IN jack
and plug the AC adaptor
into the wall outlet.
AC adaptor
+ -
L
STEREO OUT
STANDBY ON
DC IN
9V
MN04
PAN
PAN
PEAK
L R L
R L
10
10 10
5
5 5
0
0 0
3 4 MASTER
Sound source 3
Sound source 4
INPUT LEVEL
INPUT LEVEL
INPUT LEVEL
INPUT LEVEL
Battery Compartment
R
<NOTE>
Plug a microphone into channel 1.
Channels 2~4 are exclusively line level inputs.
STEREO BUSS
L R
PAN
PAN
PAN
PAN
Open the mixer bottom battery
compartment lid by hand, correctly
connect the plug to the battery,
and place battery in compartment
and replace lid as before.
<NOTE>
Be sure to remove the battery if it
is not to be used for long hours or
extensive periods of time. If not,
it could result in leaking electrolyte
Plug
Battery
from the battery which can ruin
your new mixer.
Multitracker
Sound source 6
Sound source 5
PEAK LED
MASTER
L
STEREO OUT
-10dBV
R
PHONES
