- Page 1 Be Strong. ™ Installation Manual M-Series LCD Monitor Bracket Model:NV915 P/N: 001-1959 Rev C (08/13/2007)
-
Page 2: Table Of Contents
Table of Contents FCC Information Safety Precautions Specifications Components & Tools Needed Installation Procedure Quick Reference Guide Important Contact Information... -
Page 3: Fcc Information
A T T E N T I O N • Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void the users authority to operate the equipment. Nautilus LCD Installation ®... -
Page 4: Safety Precautions
Important Safety Precautions To reduce the risk of fire, electrical shock or ImPoRTaNT! other injuries, follow these safety precautions when installing, using and maintaining your Save these instructions NV915 LCD TV Monitor. Read all instructions before using. This symbol appearing throughout this manual means: W A R N I N G Pay Attention! Be Alert! Your Safety Is Involved! W A R N I N G... -
Page 5: Specifications Components & Tools Needed
8.0 lbs/ 3.63 kg • 6mm allen Wrench Net Weight: 4.75 lb/ .15 kg • Wire Cutter Product Dimensions: 49cm (L) x 17cm (W) x 43cm (H) 19.3” (L) x 6.7” (W) x 16.9” (H) • Phillips Head Screwdriver Nautilus LCD Installation ®... -
Page 6: Installation Procedure
Installation Procedure Step 1 Remove the Console Phillips Head Screw Tools Needed: Phillips Head Screwdriver 1-1 Use a Phillips Head Screwdriver to remove the four screws that secure the Console. Step 2 Locate the LCD wires and remove the wire tie. LCD Wires Tools Needed: Wire cutter or similar... - Page 7 Step 4 Remove the Back Cover of the LCD Bracket Back Cover Tools Needed: Phillips Head Screwdriver 4-1 Use a Phillips Head Screwdriver to remove the four screws and washers securing the Back Cover to the Bracket. Phillips Head Screw Nautilus LCD Installation ®...
- Page 8 Installation Procedure Step 5 Attach the LCD Bracket Pass Wires through Bracket Plastic Cover Parts needed: LCD Bracket Four 1/4” x 1” Phillips Head Screws LCD Wires Tools Needed: Phillips Head Screwdriver 5-1 Pass the LCD wires through the Bracket between the metal plate and the plastic cover as shown.
- Page 9 Bracket as shown. Step 6 Prepare to install the LCD Monitor Back Cover Tools Needed: Phillips Head Screwdriver 6-1 Use a Phillips Head Screwdriver to remove the Back Cover of the LCD monitor. (Figure a) Figure a Nautilus LCD Installation ®...
- Page 10 Installation Procedure Step 7 Attach the LCD Monitor LCD Monitor Bracket Tools Needed: 6mm allen wrench 7-1 Position the LCD monitor on the Bracket (Figure a) with the metal Tabs resting between the upright prongs discussed in Step 6. (Detail a) 7-2 Install the m10 allen Bolts and Lock Washers.
- Page 11 International Coaxial Adapters Power Antenna Power Antenna These connections are not used in this configuration For alternative configurations please refer to the LCD monitor owners manual. Antenna Power Connections are REVERSED for the NV915 LCD Digital Monitor. Nautilus LCD Installation ®...
- Page 12 Installation Procedure Step 9 Replace the Back Covers Tools Needed: Bracket Back Cover Phillips Head Screwdriver 9-1 Use the m4 Screws and Washers from the Hardware Kit to replace the Back Cover of the Bracket (Figure a) and the LCD monitor. (Figure B) NOTE: Use the two longer screws on the raised portion of the LCD Monitor Back cover.
- Page 13 Secure the Power Brick to the Power Connector and the Coaxial Cable to the Coax Connector on the mounting Plate as shown. Mounting Plate TV Coax Connector TV Power Connector Power For Unit Nautilus LCD Installation ®...
- Page 14 Installation Procedure ATTENTION: The following steps apply to pre-wired Commercial Ellipticals only. For non pre-wired instructions, refer to the appropriate LCD wiring manual for the unit. Right Shroud Step 10 Remove Right Shroud Tools Needed: Phillips Head Screwdriver 10-1 Use a Phillips Head Screwdriver to remove the Right Shroud.
- Page 15 13-1 Replace the Right Shroud removed in Step 14 Connect LCD Wires 14-1 make appropriate Coax and Power connections where LCD Wires exit the unit. NOTE: International versions will require supplied Coaxial Connection adapter. (Figure C) International Coaxial Adapters Figure C Nautilus LCD Installation ®...
- Page 16 Installation Procedure Installation is complete. For specific instructions on setup and use of the LCD monitor please refer to the LCD monitor Users manual...
-
Page 17: Quick Reference Guide
Volume Down Volume UP mute Video Input Source (Video/S-Video, antenna) Channel Down Channel Up Numeric Channel Keys For specific instructions on setup and use of the LCD monitor please refer to the LCD monitor Users manual. Nautilus LCD Installation ®... -
Page 18: Important Contact Information
IMPoRTanT ConTaCT nuMBeRS If you need assistance, please have both the serial number of your machine and the date of purchase available when you contact the appropriate Nautilus office listed below. INTERNATIONAL OFFICES: OFFICES IN THE UNITED STATES: For technical assistance and a list of distributors in your area, e-mail: cstech@nautilus.com... - Page 19 , visit www.nautilusinc.com. © 2007 nautilus, Inc. all rights reserved. nautilus, the nautilus logo, and Be Strong are either registered trademarks or trademarks of nautilus, Inc. all other marks are either registered trademarks or trademarks of their respective companies.
