3.3

Output Tab

Custom label

Monitor

Output volume

Crossover control
PEQ control
Mute control
Polarity control
Output delay
3.3.1 Custom Label
The custom label feature allows you to input a user defined label for each output channels: A handy feature to remember the output
configuration of your system.
3.3.2 Monitor
Allows you to monitor the input meter of that specific channel on a RMS meter. Note that the information is shown in dBFS
3.3.3 Output volume
A fader control for 0 to -70dB digital gain control. Similar to the input volume control.
3.3.4

Crossover

Controls for the Low& High pass filters are available when clicking on the Xover (crossover) button:
The log scale graph gives you the equivalent response of the applied filter. By pointing the mouse anywhere on the plotted curve, the
dB attenuation and respective frequency are displayed.
www.Soundstream.com / For more info please contact tech@soundstream.com Features and Specifications are subject to change
Master volume
control
P 10
