- Page 1 5.1 Surround Audio Processor MultiMerge2 User Manual...
- Page 2 While the MultiMerge2 has been designed to be straightforward to use, we do suggest that you spend a few minutes familiarizing yourself with the features and operational functions that are contained in this manual.
-
Page 3: Table Of Contents
Ethernet interface for loudness-compliance logging and field updates Optional HD/SDI input for 8 de-embedded audio channels from SDI group 1 or 2 All rights reserved DaySequerra Corp. Copyright 2011. All logos and trademark used herein are the property of their respective owners. Specifications subject to change. -
Page 4: Important Safety Information
The DaySequerra MultiMerge2 contains no user serviceable components inside the unit. Please contact DaySequerra for repair and upgrade information. In the event that your unit needs to be returned to the factory, contact us for a return authorization number. Please visit www.daysequerra.com and register your new MultiMerge2 so we can keep you informed of the... -
Page 5: Technical Specifications
HD/SDI input for 8 de-embedded audio channels from SDI group 1 OPTIONS or 2 WARRANTY One year, limited parts and labor NOTES [1] Does not include added latency of any options *Specifications are subject to change without notice to upgrade the performance of our products. MultiMerge2 User Manual... - Page 6 Environmental Preservation Efforts This equipment has been designed and built by DaySequerra corporation to give many years of trouble free service and is backed by our three year warranty and commitment of providing the best customer support. When the time comes to retire your product from service, it should be disposed of in accordance with local codes or ordinances.
-
Page 7: Introduction
Rack Mount Installation The MultiMerge2 chassis has four rack mounting holes and has been designed to fit in a standard 1RU space. Plastic ‘finishing’ washers are recommended to protect the painted surface around the mounting holes. Locate the air vents on each side of the unit, and be sure to keep them clear so the unit may have adequate ventilation. -
Page 8: Front Panel Controls And Indicators
UPS as long as the total load is within the UPS’ capacity. Consult your UPS manual for details. MultiMerge2 will automatically power up when AC power is applied. If AC line power is lost or momentarily interrupted, MultiMerge2 will revert to its previous state. -
Page 9: Home Screen
Figure 2. Home Screen on MultiMerge2. When you power on MultiMerge2, the display should look similar to the one pictured in Figure 2. Each field is dynamic and will show status or configured settings. Pressing the HOME key again while at this screen enters home screen selection mode that allows quick access to key functions. -
Page 10: Rear Panel Controls And Indicators
MultiMerge2 is on the HOME screen. ENTER KEY - Used to enter a menu or confirm a selection. HOME KEY - A press of this button will return MultiMerge2 to the home screen or enter home screen selection mode. - Page 11 Input 3: Toggle UpMix mode Input 4: Triggers EAS Mode NETWORK - Used for logging or to update MultiMerge2’s firmware. To connect directly to a PC without use of a network switch or hub, a crossover cable is required. Firmware updating is accomplished via UDP Port 44600.
-
Page 12: Programming Menu
Figure 3. Main Menu Screen Display The display shown on MultiMerge2 when first entering the menu is demonstrated in Figure 4. From this screen you may navigate to the rest of the menu by selecting SYSTEM MENU. This screen will also display all other readings that MultiMerge2 is generating from measuring the input audio stream. -
Page 13: Settings Menu
DaySequerra MultiMerge2 is configured to take a DHCP address by default. Device Name: Allows you to change MultiMerge2’s name as reported to DNS. Press ENTER while the cursor is over this field to go into data entry mode. Turn the knob to scroll through the available choices... -
Page 14: Diagnostics Menu
ENTER accepts the name. DHCP: Configures MultiMerge2 to look for a DHCP server for IP configuration. (Enabled or Disabled) IP Address: If DHCP is set to disabled, allows you to enter the desired IP address manually. Press ENTER while the cursor is over this field to go into data entry mode. - Page 15 Figure 8. Alarms Menu Screen Display AES Error: When enabled, Multimerge2 will alert the operator of any AES errors. Power Supply: When enabled, Multimerge2 will alert the operator if a power supply issue occurs. About Menu Model Number: Displays the model number of the unit.
-
Page 16: Faults
No Sync: AES sync has been lost. Please check the source equipment and all cable connections. Ensure that MultiMerge2 is operating in the proper input mode for your application and is looking for the source audio on the correct port. - Page 17 255.255.255.0. Select OK to close the dialog, then OK to close the properties box. 5. If MultiMerge2 is set up for DHCP, disable it and enter a static IP address within the local network range. (Example: 192.168.0.2) Details are available in the NETWORK section of this manual.
-
Page 18: Warranty
DaySequerra warrants this product to be free from defects in materials and workmanship to its original owner for one (1) year from the date of purchase. DaySequerra will repair or replace such product or part thereof that upon inspection by DaySequerra, is found to be defective in materials or workmanship subject to conditions contained herein. - Page 19 Manufactured under license from DTS Licensing Limited. DTS and the Symbol are registered trademarks and the DTS logo is a trademark of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved. MultiMerge2 User Manual...
