Single Package
Vertical Unit
Wall Sleeve
The Single Package Vertical Unit (SPVU) wall sleeve provides structural support and weather-tight seal against wind and
water infiltration for the SPVu. Three wall sleeve sizes are available to accommodate wall thickness from 5" to 15". Each
sleeve includes a factory-installed "weather guard" to cover the sleeve opening during construction.
Table of Contents
General ......................................................................... 2
Unit Features ............................................................... 2
Unit Location ............................................................... 2
Transportation Damage .............................................. 2
Unit Accessories ......................................................... 3
Grille Installation Instructions .................................... 3
Installation Instructions .............................................. 3
As a professional installer you have an obligation to
know the product better than the customer. This
includes all safety precautions and related items.
Prior to actual installation, thoroughly familiarize your-
self with this Instruction Manual. Pay special attention
to all safety warnings. Often during installation or repair
it is possible to place yourself in a position which is
more hazardous than when the unit is in operation.
December 1999
RECOGNIZE THIS SYMBOL AS A SAFETY PRECAUTION
ATTENTION INSTALLING PERSONNEL
Installation Instructions
Remember, it is your responsibility to install the
product safely and to know it well enough to be able to
instruct a customer in its safe use.
Safety is a matter of common sense...a matter of
thinking before acting. Most dealers have a list of
specific good safety practices...follow them.
The precautions listed in this Installation Manual should
not supersede existing practices but should be consid-
ered as supplemental information.
20292302
Advertisement
Related Manuals for Amana Single Package Vertical Unit Wall Sleeve
Summary of Contents for Amana Single Package Vertical Unit Wall Sleeve
- Page 1 Single Package Installation Instructions Vertical Unit Wall Sleeve The Single Package Vertical Unit (SPVU) wall sleeve provides structural support and weather-tight seal against wind and water infiltration for the SPVu. Three wall sleeve sizes are available to accommodate wall thickness from 5” to 15”. Each sleeve includes a factory-installed “weather guard”...
- Page 2 General These instructions give information relative to the Single Package Vertical Unit wall sleeve and grille installation only. The manufacturer assumes no responsibility for equipment installed in violation of any code requirements. For other related equipment refer to the proper instructions. Unit Features This unit has many features which are different than those found on conventional wall sleeves.
- Page 3 Unit Accessories Installation Instructions 1. Install the sleeve into the pre-cut opening 44”H x 21-5/ To complete the installation of this wall sleeve, an architec- 8”W. tural is required. 2. The front edge of the sleeve should protrude 1/4” from The following accessory is available for the wall sleeve: the finished outside surface of the wall (Figure 4).
