Introducing the USB SoundWave 7.1
The USB SoundWave 7.1 is a portable sound controller that
simulates 7.1-channel sound to headphones or 2-channel
speakers.
Features and Benefits
•
Virtual 7.1-channel sound provides home-theater
quality surround sound via headphones or stereo
speakers
•
Built-in amplifier for rich and powerful sound
•
Supports EAX 2.0, A3D 1.0, and Microsoft
DirectSound 3D
•
Xear 3D software offers 27 environment effects
and 3 environment sizes, plus a 10-band equalizer
with presets or manual configuration
•
Supports Plug & Play and obtains power from USB
port
Serial Number Sticker
For future product return or exchange, this serial number
is required. Please keep it for your reference.
04-0421D
USB SoundWave 7.1
Quick Installation Guide
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SIIG USB SoundWave 7.1
Summary of Contents for SIIG USB SoundWave 7.1
- Page 1 USB SoundWave 7.1 Quick Installation Guide Introducing the USB SoundWave 7.1 The USB SoundWave 7.1 is a portable sound controller that simulates 7.1-channel sound to headphones or 2-channel speakers. Features and Benefits • Virtual 7.1-channel sound provides home-theater quality surround sound via headphones or stereo speakers •...
-
Page 2: System Requirements
An available USB port • Windows 7 (32-/64-bit) / Vista (32-/64-bit) / XP ® (32-/64-bit) / Server 2003 & 2008 (32-/64-bit) / 2000 Package Contents • USB SoundWave 7.1 • USB extension cable • Software CD • Quick installation guide Layout... -
Page 3: Driver Installation
Audio Configuration Utility, Mixer, Equalizer and virtual 7.1-channel sound from headphones or stereo speakers, install the Xear 3D software and driver from the software CD. Note: Plug in the USB SoundWave 7.1 and allow the Windows driver to load before inserting the software CD. Windows 7 Insert the software CD. - Page 4 For Windows Vista: Click Allow. For Server 2008: Continue to step #3. Click Yes, I want to restart my computer now, then click Finish to complete the installation. For Windows XP / Server 2003 / 2000 Insert the software CD. Autorun should start the installation.
- Page 5 Speaker Configuration Make sure to log in as Administrator or an account with administrator rights. Windows 7 Click Start, Control Panel, Hardware and Sound. Click Sound. Select Speakers USB Audio Device, click Configure. Follow on-screen instructions to complete. Windows Vista / Server 2008 Click Start, Control Panel, Classic View.
- Page 6 Double click Sounds and Multimedia. Click Audio tab, under Sound Playback, click Advanced, then click the Speakers tab. Click the drop down list and select your speaker. Click OK to save the settings. Uninstalling Xear 3D Software Windows 7 Click Start, Control Panel, Programs. Click Programs and Features.
- Page 7 Step 1: Submit your RMA request. Go to www.siig.com, click Support, then RMA to submit a request to SIIG RMA. Your RMA request will be processed, if the product is determined to be defective, an RMA number will be issued.
- Page 8 Fremont, CA 94538-3152, USA Phone: 510-657-8688 USB SoundWave 7.1 is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. All other names used in this publication are for identification only and may be trademarks of their respective owners.
