1 General description

1.1 General information

1.1.1 Module Features

WISMO Quik Q24x6 sub-series is a range of self-contained E-GSM
900/1800 or 850/1900 dual-band modules including the following features:
1.1.1.1 Overall dimensions
• 58.4 x 32.2 x 3.9 mm.
1.1.1.2 Power consumption
• 2 Watts E-GSM 900/GSM 850 radio section running under 3.6 Volts.
• 1 Watt GSM1800/1900 radio section running under 3.6 Volts.
1.1.1.3 Power supply voltage
• Digital section running under 2.8 Volts.
• 3V only SIM interface (for both 1.8 V and 5 V SIM interface with
external adaptation, refer to § 0 and 2.2.6.3 ).
1.1.1.4 Module capability
• Real Time Clock with calendar.
• Battery charge management.
• Echo Cancellation + noise reduction.
• Full GSM or GSM/GPRS software stack.
• Complete shielding.
• Complete interfacing through a 60-pin connector:
o
o
o
o
o
o

1.1.2 Module external connection

WISMO Quik Q24x6 sub-series has two external connections:
• RF connection pads (to the antenna),
• 60-pin General Purpose Connector (GPC) to Digital, Keyboard, Audio
and Supply.
