Wavecom GX64 GSM 27.010 Multiplexer Feature Application Note page 20

Priority: 1
F9 03 FF 15 81 11 01 00 01 0A 1F 00 00 00 FB F9
F9
Opening
Flag
01
Priority: 1
*
GR/GS64 only supports parameter negotiation of N1: Maximum Frame Size. As a result both
N2 and K parameters are set to 0.
* Windows size K is not applicable in basic option
F9 07 3F 01 DE F9
F9
Opening
Flag
F9 07 73 01 15 F9
F9
Opening
Flag
Establish DLC2
F9 03 FF 15 83 11 02 00 01 0A 1F 00 03 01 FB F9
F9
Gx64 APPLICATION NOTE
27.010 MUX Feature
Page: 20/24
N1: 31 N1: 0
T1: 10
Lower 8 bit Higher 8 bits
03 FF 15 81
Parameter
DLC Length
UIH Negotiation
0 10
Response
0A 1F 00
N1: 31 N1: 0
T1: 10
Lower 8 bit Higher 8 bits
07 3F 01
DLC 1 SABM Length = 0
07 73 01
DLC 1 UA Length = 0
03 FF 15 83
