3.0
SATA
Wire
USB 3.0 to 2.5"SATA CONNECTOR
User's Guide
Attention:
If your SATA Wire shipped with a previous
version of EZ Gig III, you can download the new
EZ Gig IV from Apricorn's website at:
http://www.apricorn.com/ezgig
Review the most current SATA Wire FAQ's at:
http://www.apricorn.com/support.php

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SATA Wire 3.0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Apricorn SATA Wire 3.0

  • Page 1 USB 3.0 to 2.5”SATA CONNECTOR User’s Guide Attention: If your SATA Wire shipped with a previous version of EZ Gig III, you can download the new EZ Gig IV from Apricorn’s website at: http://www.apricorn.com/ezgig Review the most current SATA Wire FAQ’s at: http://www.apricorn.com/support.php...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Getting to know your SATA Wire Introduction The Package Contains System Requirements Connecting your SATA Wire Device Installation Before Running the Software Before running EZ Gig we recommend EZ Gig instructions for Windows 7 & Vista Changing the default “Power Options” Upgrade Suite (CD-ROM boot) To start EZ Gig directly from the CD-ROM Connecting Your Hard Drive...
  • Page 3 SharedMemory Animation HotCopy / LiveImage Avoid exclusive read access Partitions Resizing your partitions manually Start Clone Interupting the Cloning Process Aborting the Cloning Process Interupting the Verification process Congratulations your Clone is Complete SuperDuper! Backup Software for Mac After the Clone Using the SATA Wire as a external backup drive Device Removal (Windows) SATA Wire FAQs...
  • Page 4: Getting To Know Your Sata Wire Introduction

    The SATA Wire is perfect for transferring data to bare drives. Use it to connect any 2.5” SATA notebook hard drive to your computer. With the help of Apricorn’s user-friendly cloning software, you can clone or backup your notebook drive in a snap.
  • Page 5: Connecting Your Sata Wire Device Installation

    USB 2.0). Now you can upgrade your notebook drive using the Upgrade Suite CD. Instructions for upgrading your Microsoft computer are provided on the following pages. If you are upgrading your Mac, please refer to page 27. www.apricorn.com...
  • Page 6: Before Running The Software

    EZ Gig can boot directly from the CD-ROM but you must check the BIOS Boot settings to make sure that “CD-ROM” is higher in the boot order than the C: drive. www.apricorn.com...
  • Page 7: Ez Gig Instructions For Windows 7 & Vista

    Click on “Power Options” to launch the program. On the left window click on “Choose when to turn off display” and make the changes as listed below. Turn Display Off Never Put computer to sleep Never Once you have completed the clone go to “Power Options” and restore the default settings. www.apricorn.com...
  • Page 8: Upgrade Suite (Cd-Rom Boot)

    <F12> key, others use the <ESC> key), and the boot option is only available for a few seconds at startup before the BIOS falls back into the normal boot order. 4) Once the BIOS is set correctly, the CD-ROM should boot-up the computer and start the EZ Gig software. www.apricorn.com...
  • Page 9: Connecting Your Hard Drive

    If you have EZ Gig on a CD, please choose the Start option (proceed to page 11 of this manual to continue). If you downloaded EZ Gig from Apricorn’s website, you can either choose the Start option (go to page 11) or create a bootable EZ Gig CD to use in the future (go to page 10 for instructions).
  • Page 10: Creating A Bootable Ez Gig Cd

    Creating a Bootable EZ Gig CD If you downloaded EZ Gig from Apricorn’s website, you have the option of creating a bootable EZ Gig CD, floppy disk or thumb drive to use in the future. To create a bootable media disk follow the appropriate directions below: •...
  • Page 11: Cloning Your Hard Drive With Ez Gig

    Cloning your hard drive with EZ Gig Click the “Let’s Get Started” button to proceed. EZ Gig will then scan for connected drives. This may take a few moments. www.apricorn.com...
  • Page 12: Selecting The Source Drive

    Source Drive. This is the drive you would like to copy from and in most cases is the internal drive in your notebook. NOTE: Your computer’s internal drive will usually be denoted by the prefix AHCI or IDE. Select the appropriate drive from the menu and click “Next” to continue. www.apricorn.com...
  • Page 13: Selecting The Destination Drive

    Select the appropriate drive from the menu and click “Next” to continue. Speed Test Click the Speed Test icon on either the Source or Destination drive for an estimate of the drive’s read speed. From this estimate, a rough estimate of the clone time may be gauged www.apricorn.com...
  • Page 14: Drive Verification

    At this point you can also modify the default options for your clone using the “Advanced Options” button. Only select this option if you would like to change your options from the default (go to page 19 for more info on Advanced Options). www.apricorn.com...
  • Page 15: Data Select

    To deselect files from the clone click the “Data Select” button, this will open the Data Select feature. On the “You are almost ready to Clone” screen, you may press the “Data Select” button to open the Data Select feature. www.apricorn.com...
  • Page 16: Using The Data Select Feature

    In order to decrease the size of the clone (i.e. the Source image), EZ Gig enables you to deselect files from the cloning process to save space. The files you may deselect from the cloning process are from the folders: Documents My Videos My Music My Pictures www.apricorn.com...
  • Page 17: Analyzing Files

    “Select Folders to Analyze” column. EZ Gig will then analyze the space used in the ajoining “Space Used” column. To analyze the EZ Gig will then amount of space display the space used by each used in the ajoining folder, select column the appropriate checkbox. www.apricorn.com...
  • Page 18: Selecting Folders To Omit

    Clone” screen. The Data Select button will have a check mark to the left, indicating that you have choosen to omit files from the clone. To continue with the clone, click the “Next” button (go to page 21). www.apricorn.com...
  • Page 19: Advanced Options

    SmartCopy enables you to clone your file systems in a fraction of time usually required - this option is chosen by default Media Direct (Dell) Used to deactivate MediaDirect software on the Destination drive. Check your Dell notebook specs to see if you have Media Direct on your system. www.apricorn.com...
  • Page 20: More Advanced Options

    More Advanced Options To access additional advanced options, click on the Apricorn logo in the bottom right corner of the “Advanced Options” window FastCopy Special copy algorithm. Can increase the regular copy speed up to double. SafeRescue Special algorithm for data recovery. Tries to recover as large areas on the drive as possible.
  • Page 21: Hotcopy / Liveimage

    This is the most reliable way for creating an identical copy, but it may interfere with other programs running at the same time. If this option is selected, EZ Gig tries to create a HotCopy or a LiveImage at first. www.apricorn.com...
  • Page 22: Partitions

    When used in the Default mode, EZ Gig will automatically resize your partitions according to the new hard drive space. However, EZ Gig also gives the option of keeping your partition sizes the same or allows you to resize your partition sizes manually. www.apricorn.com...
  • Page 23: Resizing Your Partitions Manually

    Once you have resized the partitions to the desired size, choose “Apply Adjustment” which will then close the window. Once the “Adjust Partition” window is closed, close the “Advanced Options” window by clicking the “Close Window” button. www.apricorn.com...
  • Page 24: Start Clone

    EZ Gig will keep you up-to-date with the status of the clone throughout the entire process with a progress bar and percentage completed. Depending on your system size a clone can take anywhere from several minutes to a couple of hours. www.apricorn.com...
  • Page 25: Interupting The Cloning Process

    The copy itself is already finished at that point of time. When the final report is read, EZ Gig will report that the clone is only partially verified. www.apricorn.com...
  • Page 26: Congratulations Your Clone Is Complete

    Once you have finished your clone, click “Quit EZ Gig”. You will then be prompted to turn your computer off and disconnect the attached hard drive. www.apricorn.com...
  • Page 27: Superduper! Backup Software For Mac

    SuperDuper! Backup Software for Mac 1. Insert Apricorn CD into your CD-ROM drive 2. When the Apricorn CD appears on your desktop, double click to open. 3. Double click on the SuperDuper!.dmg icon 4. This will open the package and mount a drive on your desktop.
  • Page 28: After The Clone

    Microsoft website with complete instructions for both XP, Vista & 7) Follow instructions in the appropriate section of this manual for cloning to create a full bootable backup or just use as an external storage device. www.apricorn.com...
  • Page 29: Device Removal (Windows)

    USB device to be removed. If you receive an error message that says “The device cannot be stopped right now. Try stopping the device again later.” Close all Windows and Programs that are using files from the Drive, then repeat the procedure. www.apricorn.com...
  • Page 30: Sata Wire Faqs

    PATA connectors. If your laptop requires a SATA hard drive you must replace it with a SATA hard drive. Use Apricorn’s hard drive configurator at www.apricorn.com to make sure you are getting the correct drive for your laptop or notebook computer.
  • Page 31 A clone is for disaster recovery purposes (i.e. when your drive fails and you need to get back up and running). You should not make a clone of your drive and put it in another or multiple machines. There are licensing issues for the software on your machine. www.apricorn.com...
  • Page 32 NTFS file system. 12. Can I boot Windows to my USB Device? No. Because of limitations (both hardware and software) Windows is currently prevented from booting and running off a USB drive. www.apricorn.com...
  • Page 33: Ez Gig Faqs

    If keyboard or mouse (or both) do not function with EZ Gig, this is usually due to a wrong legacy emulation setting in BIOS setup. On most computers, you can fix this problem by changing (activating or deactivating, depending on the current setting) the emulation for PS/2 devices in BIOS www.apricorn.com...
  • Page 34 If EZ Gig does not recognize a hard disk, there can be several reasons. Perhaps the controller which the disk is connected to has not been found (See next section: IDE controller not found). A further possible reason can be a non-standardly connected hard disk. This is for example the case if www.apricorn.com...
  • Page 35 Apart from that the unaffected area remains possibly unused during a later usage, such a copy is usually comparable to a real clone as far as the capacity of use is concerned because the target contains entirely all data of the source www.apricorn.com...
  • Page 36 (with the option SafeRescue) with the help of special data recovery strategies within a proper troubleshooting run. During the troubleshooting run, the number of the indicated write errors can decrease according to the areas on the target medium, which could be recovered. www.apricorn.com...
  • Page 37 In case of an error-free copying process, EZ Gig should not report any verification errors and signalize a 100% conformity of source and target. www.apricorn.com...
  • Page 38: Contacting Technical Support

    2. Simply call Apricorn’s technical support department with your upgrade kit part number and a description of the problem(s) you are experiencing. 3. If the Apricorn representative finds cause for a return, they will issue an RMA number. Please write this number down.
  • Page 39: Warranty Conditions

    And/oR InAbIlITy To Follow The wRITTen InSTRucTIonS PRovIded In ThIS InSTRuc- TIon guIde: 2. by The uSe oF PARTS noT MAnuFAcTuRed oR Sold by APRIcoRn; 3. by ModIFIcATIon oF The PRoducT; oR 4. AS A ReSulT oF SeRvIce, AlTeRnATIon oR RePAIR by Anyone oTheR ThAn APRIcoRn And ShAll be voId.
  • Page 40 12191 Kirkham Road Poway, CA, U.S.A. 92064 1-858-513-2000...
