Summary of Contents for Anie Jooltool
- Page 1 OWNER’S MANUAL 1-888-337-1230 WWW.JOOLTOOL.COM INFO@JOOLTOOL.COM...
-
Page 2: Power Tool Safety Rules
POWER TOOL SAFETY RULES Please read and understand all instructions before using your JOOLTOOL® System Failure to follow instructions listed below may result in serious personal injury, electric shock and / or fire. WORK AREA Always secure the machine unit to a bench top... -
Page 3: Personal Safety
POWER TOOL SAFETY RULES PERSONAL SAFETY Avoid accidental starting. Make certain speed control switch is “OFF” before plugging in. Leaving the speed control switch “ON” can lead to accidents. Do not leave unit unattended. Always turn the unit “OFF” regardless of the situation or circumstance. -
Page 4: Electrical Safety
Should it require some, it should only be performed by an authorized service center or by the manufacturer, JOOLTOOL®. Do not attempt to repair or service any part of the tool yourself. Doing so may result in electric shock, injury or... - Page 5 Your JOOLTOOL™ may have an automatic “power-down” safety feature. When excessive pressure is detected, the disc speed is reduced. If this happens, reset your JOOLTOOL™ : turn the switch to “OFF” , unplug & replug the cord. Always use accessories and attachments for their intended applications.
- Page 6 BACKPAD. Avoid using damaged or cracked BACKPADS as they may break apart. Always use JOOLTOOL™ BACKPADS on your JOOLTOOL™ System with its original spindle. This will guarantee that your discs will always be perfectly centered and give you optimal results.
- Page 7 POWER TOOL SAFETY RULES ABRASIVE SAFETY - INSTALLATION & OPERATION Always remove all protective backing film off abrasive disc before applying onto the BACKPAD. Always make sure all adhesive residue from used abrasive and/or dust particles have been completely removed from the BACKPAD before applying a new abrasive.
- Page 8 BACKPADS. This will ensure that you get the longest life & efficiency out of your abrasives and your JOOLTOOL™. If you require additionnal BACKPADS, please contact your nearest JOOLTOOL™ retailer, order directly from us at 1-888-337-1230 or online at www.jooltool.com.
- Page 9 Cushion. Backing with the NINJA Design. TURNING YOUR JOOLTOOL “ON” Your JOOLTOOL’ s power switch is also the speed control. (Located at the bottom of unit) To turn “ON” , simply twist the knob clockwise to the desired speed. To turn “OFF” , twist the knob counter-clockwise...
-
Page 10: Operation
OPERATION HOLDING THE WORKPIECE REMEMBER! ROTATION OF THE DISC IS COUNTER-CLOCKWISE DO NOT POINT ANY EDGE OR TIP TO THE OPPOSITE OF DIRECTION OF ROTATION! Hold the workpiece directly UNDERNEATH the disc. Apply the workpiece to the BOTTOM of the SPINNING disc GENTLY and with EVEN pressure. - Page 11 OPERATION THESE ARE GENERAL RULES OF OPERATION INTENDED AS GUIDELINES ONLY. FOR MORE INFORMATION, CONSULT THE PROVIDED INSTRUCTIONAL DVD. FOR LONG FLAT-EDGED TOOLS RULE OF THUMB: Follow the steps described on the previous page while GRADUALLY & EVENLY moving/gliding the tool’s edge from RIGHT to LEFT under the disc. You may stop anytime by simply lowering the tool as described previously in STEP 3.
- Page 12 Depends on Buffing & Polishing Felt Disc Compound Metal, Glass, Stone PLEASE SEE BELOW FOR ADDITIONAL ACCESSORIES THAT BROADEN YOUR JOOLTOOL EXPERIENCE NINJA™ Makes Grit Switching Faster and Simpler! Have One for Each Grit: “TWIST ON - TWIST OFF”! BACKPADS NINJA™...
- Page 13 OPERATION THESE ARE GENERAL RULES OF OPERATION INTENDED AS GUIDELINES ONLY. FOR MORE INFORMATION, CONSULT THE PROVIDED INSTRUCTIONAL DVD. USING THE NINJA SEE-THRU™ FELT WHEEL IMPORTANT! MOUNT YOUR FELT DISC ONTO A BACKPAD BEFORE USE! ONLY when using the FELT DISC for the VERY FIRST time, you should charge the wheel HEAVILY with POLISHING COMPOUND to a high saturation.
- Page 14 REMOVING THE FRONT LIP Your JOOLTOOL’s removable front lip allows additional clearance for larger items or near-perpendicular grinding. To remove the lip, simply follow these steps. (Reverse steps to re-install) STEP 1...
-
Page 15: Removing The Hood
INSTALLING THE FLEX-SHAFT ATTACHMENT You can take your JOOLTOOL experience to the next level by installing the FLEX-SHAFT attachment! The FLEX-SHAFT is fully compatible with most rotary handpieces and allows freehand sanding, polishing and countless advantages. - Page 16 FOR MORE INFORMATION, CONSULT THE PROVIDED INSTRUCTIONAL DVD. USING THE 3M™ SCOTCH-BRITE™ CLUSTER This Scotch-Brite™ Cluster is one of the most versatile wheels in the JOOLTOOL accessory line. It can be used on a variety of tasks and in a variety of ways: Removing rust, smoothing of wood grain, matte finishing, paint stripping, deburring, etc.
- Page 17 Use them on the JOOLTOOL or HANDPIECE of your choice. Brushes are available in the following sizes: 9/16” , 3/4” , 1” , 2” and 3” diameter.
- Page 18 Abrasives by BRISTLE BRUSH CHART Exclusively for JOOLTOOL APPLICATIONS BRUSHES ON METAL ON WOOD STEP REMOVES & SETS WOOD GRAIN CLEANS FIRESCALE, HEAVY RUST & SANDS, REMOVES STAIN, IDEAL METAL CASTINGS, REMOVES DEEP FOR WOOD CUTS & CARVINGS SCRATCHES, DEBURRS...
-
Page 19: Warranty Information
(1) You must retain your original bill of sale or provide proof of purchase. (2) This warranty does not extend to any JOOLTOOL power tool unit or parts that have been lost or discarded by you or to damage to the power tool unit or... - Page 20 If you are looking for an authorized source or would like to purchase directly from JOOLTOOL, please contact us! Web: www.jooltool.com E-mail: info@jooltool.com Toll-Free: 1.888.337.1230 © 2012 Jooltool. 3M is a trademark of the 3M Company and used under license. All Rights Reserved 1-888-337-1230 WWW.JOOLTOOL.COM INFO@JOOLTOOL.COM...
