Digital Media Transport
ND-S1
Instruction Manual
Thank you for purchasing an Onkyo product. Please
read this manual carefully before making any con-
nections or using this product. By following these
instructions, you'll get the best audio performance
and the most listening pleasure from your Onkyo
product. Keep this manual for future reference.
E
n
Precautions ............................... 3
Features..................................... 4
Supplied Accessories................ 5
Getting to Know the ND-S1 ..... 6
Connecting the ND-S1.............. 8
Your iPod .................................10
Through the ND-S1.................13
Troubleshooting .....................14
Specifications..........................15
Advertisement
Table of Contents
Related Manuals for Onkyo ND-S1
Summary of Contents for Onkyo ND-S1
-
Page 1: Table Of Contents
Precautions ....... 3 Features........4 Digital Media Transport Supplied Accessories....5 ND-S1 Getting to Know the ND-S1 ..6 Instruction Manual Using the Remote Controller ... 7 Connecting the ND-S1....8 Playing the Music and Videos on Your iPod .........10 Syncing Your iPod to Your PC.. -
Page 2: Important Safety Instructions
WARNING: WARNING AVIS TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT RISK OF ELECTRIC SHOCK RISQUE DE CHOC ELECTRIQUE DO NOT OPEN NE PAS OUVRIR EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of CAUTION: uninsulated “dangerous voltage”... -
Page 3: Precautions
GERMANY frequency energy and, if not installed and used in accordance with the instructions, may cause harmful declare in own responsibility, that the ONKYO product described in this instruction manual is in compliance with the interference to radio communications. However,... -
Page 4: Features
• When the amp or AV receiver is already On, the eration” in its name indicates the first gen- ND-S1 turns On. So to turn on the ND-S1 when the amp or AV eration of that particular iPod. receiver is set to Standby, on the remote controller •... -
Page 5: Supplied Accessories
Supplied Accessories Make sure you have the following accessories. • AC adapter • Optical audio cable • USB cable • Remote controller • Video cable • cable • Instruction Manual * In catalogs and on packaging, the letter at the end of the product name indicates the color. -
Page 6: Getting To Know The Nd-S1
This connection should not be used 3 STANDBY indicator with some components. See page 8 for Lights up when the ND-S1 is on Standby. If details. your iPod is charging during Standby, it 2 OPTICAL AUDIO OUT jack flashes slowly. -
Page 7: Using The Remote Controller
• If another remote controller of the same type for a long time, remove the battery to pre- is used in the same room, or the ND-S1 is vent damage from leakage or corrosion. installed close to equipment that uses infra- •... -
Page 8: Connecting The Nd-S1
“DOCK, ” do not connect the cable, other- wise a malfunction may occur. • Do not place the ND-S1 on top of a compo- nent that gets warm or one with has air vents Optical digital on top, as it may interfere with that compo-... - Page 9 Otherwise, it may not connect properly and a malfunction may occur. • Do not insert your iPod into the ND-S1 with- out the adapter that came with it, as it may put unnecessary strain on the iPod or ND-S1’s dock connector, causing permanent...
-
Page 10: Playing The Music And Videos On Your Ipod
Press and hold to fast forward or rewind. 2. Insert your iPod into the ND-S1 (see page 4 Play/Pause [L] button Press to start playback on your iPod. Your 3. Press the remote controller’s Play/Pause iPod will turn on automatically if it’s not... - Page 11 ■ System Off trol to adjust the playback volume. When you turn off your amp or AV receiver, the • While your iPod is inserted in the ND-S1, its ND-S1 and iPod automatically go on Standby. volume control has no effect.
-
Page 12: Syncing Your Ipod To Your Pc
1. Using the included USB cable, connect the case you’ll need to press the [SYNC/UNSYNC] ND-S1’s USB port to a USB port on your PC. button again to sync. 2. Press the [SYNC/UNSYNC] button. -
Page 13: Playing The Music On Your Pc Through The Nd-S1
Use your amp or AV receiver’s volume con- trol to adjust the playback volume. Note: • If the ND-S1 is not recognized as a USB audio device even after restarting your PC, in the Control Panel, open “Sounds & Audio Devices”... -
Page 14: Troubleshooting
• Make sure all plugs are pushed in all the way. control your iPod is selected. • Make sure the ND-S1 is connected to the cor- • If you’re using the remote controller that rect input jacks on your amp or AV receiver. If came with your amp or AV receiver, be sure there’s no video, check your video connec-... -
Page 15: Specifications
Specifications ■ PC System requirements Power supply: 100–240 V AC adapter (5V/1A) • Windows XP (SP2 or later) or Windows Vista • 1 GHz or faster processor Power consumption: 3.5 W • At least 512 MB of memory USB consumption: 250 mA •... - Page 16 Unit 1&12, 9/F, Tower 1, Ever Gain Plaza, 88, Container Port Road, Kwai Chung, N.T., HONG KONG Tel: +86-852-2429-3118 Fax: +86-852-2428-9039 http://www.ch.onkyo.com/ I0908-1 SN 29400153 (C) Copyright 2009 ONKYO CORPORATION Japan. All rights reserved. * 2 9 4 0 0 1 5 3 *...
