Instruction Manual
QUICK SETUP
Model : TX-SR577
Thank you for purchasing this product.
This quick setup sheet shows the typical hookup method for connecting
speakers and AV components (DVD player, TV, cable/satellite receiver).
For more detailed hookup information and operating instructions,
please see the Instruction Manual.
Speaker Layout (Main Room)
TV
TV
Front
Front
Left
Left
Surround
Surround
Listener
Listener
Left
Left
Surround
Surround
Back
Back
Left
Left
Front
Front
Right
Right
Center
Center
Surround
Surround
Right
Right
Surround
Surround
Back
Back
Right
Right
Speaker Hookup
Front right
speaker
1/2''-5/8'' (12-15mm)
5/8''
(15mm)
Powered
Surround back
subwoofer
right speaker
See the other side of this sheet for the AV component hookup.
(C) Copyright 2009 ONKYO CORPORATION Japan. All rights reserved.
Front left
speaker
Center
speaker
Surround right
Surround left
Surround back
speaker
speaker
left speaker
SN 29400007
* 2 9 4 0 0 0 0 7 *
