AG Neovo TV-02 Specifications

MULTIPLE INPUT TV TUNER BOX
TV-02
FEATURES
125 channel cable ready
Multiple video inputs
Supports resolution up to 1280 x 1024
Supports 16:9 wide screen mode
Switchable input sources
Multi-channel preview for program
searching
Picture-in-Picture
Closed caption decoding (American option)
Teletext helps the programming of TV
channels and programs into the TV tuner
(European option)
3:2 pull-down correction eliminating jitter
from DVD movies (only for NTSC system)
3D-motion adaptive deinterlace
Progressive scan
37-button remote control
Matches any AG Neovo display
SPECIFICATION
System Signal Interface
Max. Output Resolution 1280 x 1024 (SXGA)
Frequency Range
No. Of Channels
Resolution
Input S-Video
Component
CVBS
Analog Input
TV Antenna
Audio Input
Output Analog Output
Audio Signal Interface
Audio Output
Controls User Controls
Remote Control
Colors Available Color
Regulation Safety & EMI
Power Power AC
Consumption
Dimensions Net (W x H x D)
Packing (W x H x D)
Weight Net Weight
Gross Weight
Packing 1 Pallet
20' Container
40' Container
All specifications are subject to change without prior notice.
The name AG Neovo is a trademark of Associated Industries China, Inc.
All other trademarks are the property of their respective owners.
NTSC/PAL/SECAM
48.25MHz ~ 855.25MHz
125 Channels
640 x 480 @ 60Hz/75Hz
800 x 600 @ 60Hz/75Hz
1024 x 768 @ 60Hz/75Hz
1280 x 1024 @ 60Hz/75Hz
4-Pin Mini Din S-Video
Component YpbPr
CVBS Jack
15-Pin D-Sub
Coaxial TV Cable
3.5mm Audio Line-in
15-Pin D-Sub
MTS Stereo Audio Signal
3.5mm Audio Line-out
3.5mm Headphone Jack
Channel Up/Down,
Volume Up/Down, Source,
Power
37 Buttons
Cool Grey
CE, FCC
110V ~ 240V±10%
50 ~ 60Hz
<6.5W (On)
<0.5W (Stand-by)
255 x 130 x 32mm
(10.0" x 5.1" x 1.3")
288 x 294 x 65mm
(11.3" x 11.6" x 2.6")
1.2Kg (2.7lbs)
1.9Kg (4.1lbs)
200 Sets
2,000 Sets
4,000 Sets
www.agneovo.com
Copyright © 2005 AG Neovo. All rights reserved.
Version 4.0, 03/01/2005
