Focal SB 25 A1 Specification Sheet

SB 25 A1
A c c e s s 1 e n c l o s u r e
MDF vented box, 16mm (5/8") thick, internal
damping material
More rigidity, less vibrations
Type
Max. power
Nom. power
Sensitivity (2.8V / 1m)
Frequency response
Height
Base depth
Lenght
Focal® is a trademark of Focal-JMlab® - BP 374 - 108, rue de l'Avenir - 42353 La Talaudière cedex
France - Tel. 00 33 4 77 43 57 00 - Fax 00 33 4 77 37 65 87 - www.focal-fr.com - SCFR070105/1
50mm (2") / 4 layers voice coil
High power handling
25cm (10") subwoofer, all weather
woven glass fi ber cone
Dynamic bass, humidity resistant
Vented box
25cm (10") subwoofer
400W
200W
92dB
42Hz - 500Hz
13/16
300mm (11- ")
3/4
375mm (14- ")
432mm (17")
NBR surround
Excellent reliability
It makes the difference
• Excellent dimensions/performances ratio
• Dynamic and high power handling
• The Focal sound
Streamlined port
No chuffl ing noise
