Summary of Contents for TerraTec Cameo Convert
- Page 1 English Manual (Hardware) Version: 17.06.04...
- Page 2 CE Declaration TerraTec Electronic GmbH, Herrenpfad 38, D-41334 Nettetal, Germany hereby declare that the product: Cameo Convert to which this declaration refers is in compliance with the following standards or standardizing documents: 1. EN 55022 Class B 2. EN 55024 3.
-
Page 3: Table Of Contents
Application examples ......................9 Bridge between analog video device / TV and PC ............. 9 Bridge between AV and DV camcorders................9 Appendix ..........................10 Service at TerraTec......................10 Broken?!..........................11 General terms and conditions of service .................12 Glossary ..........................13... -
Page 4: Preface
The Cameo Convert is a professional product that forms a bridge between the worlds of analog and digital video. We're convinced that the Cameo Convert will be both very useful and a lot of fun for you for a long time to come. -
Page 5: Product Description
Just what you need, whenever you need it. It's all there: a full range of accessories CAMEO CONVERT comes with a complete accessory package to cover all of your video transfer needs. It includes suitable connector cables (two DV cables, S video cable, A/V cable, Scart- composite adapter) and a powerful PC software package, including Ulead VideoStudio 8 for professional video editing and archival on (S)VCD or DVD. -
Page 6: Connections
Connections The front panel v w x y 6-pin DV (FireWire™, IEEE1394) interface for DV In/Out This LED is lit when the selected video source is DV * This LED is lit when the selected video source is AV * This LED is lit when 12-bit encoding is used for the sound * This LED is lit when 16-bit encoding is used for the sound * S video (Y/C) input... -
Page 7: Getting Started
Getting started Please use the included power supply j. Simply switch the Cameo Convert on j. It's now ready to use. Options Two buttons are located on the top of the unit. Input signal Press the “SOURCE” button to choose whether you would like to convert AV to DV (LED ... -
Page 8: Advanced Settings
Advanced settings It's not necessary to change these settings in the everyday use of the Cameo Convert. Never- theless, we would like to give you an overview of the functions of the individual DIP switches. To access the DIP switches, carefully remove the cover g. -
Page 9: Application Examples
XP, click the “Hardware” tab and then the “Device Manager” button. Press the SOURCE button of the Cameo Convert once to select AV as the video source. The LED must light up. Now launch your software. For more information on ULEAD VideoStudio 8, please see the o- ther manual. -
Page 10: Appendix
“Rien ne va plus—Nothing's working” can happen to the best systems. If this happens to you, the TerraTec team is happy to offer its service and support. Your first move should be to check our website http://www.terratec.com/ for current answers to frequently asked questions and the latest drivers. -
Page 11: Broken
Broken?! Before you send the device back, be sure to contact us! Make a note of the name of your sup- port contact and follow these simple instructions: · Please fill out the service request form provided with your CameoConvert clearly and completely. -
Page 12: General Terms And Conditions Of Service
The warranty will not apply to damage caused by improper packaging. 6. Foreign manufactured products Devices that are not manufactured or distributed by TerraTec Electronic GmbH will be re- turned and a processing fee will be charged. 7. Repairs liable to your expense Repairs out of the warranty period are liable to your expense. -
Page 13: Glossary
Glossary AVI—A Windows video format. Bit rate—The bit rate indicates the volume of the data stream per second. A higher bit rate results in higher quality. A distinction is made between constant bit rates (e.g. for -> VCD) and variable bit rates, e.g. for -> SVCD and -> DVD. Unlike constant bit rates, variable bit rates ad- just the size of the data stream according to the video material. - Page 14 DirectDraw—DirectDraw is a graphics standard initiated by Microsoft. Its features include the capability to write graphics data directly to the memory of the graphics board for the fluid display of video material. Dropped frames—These are individual images missing from the video data stream, usually due to a slow hard drive.
- Page 15 IEEE 1394—This is a universal bus system originally developed by Apple for digital data com- munications. The devices are connected by cables with a maximum length of 4.5 m. The sys- tem supports transfer rates of up to 400 Mbps. However, a standard has not been established for video data due to the lack of specifications for the format of video data using this bus.
- Page 16 NTSC—NTSC is a video standard used in the USA and Japan. NTSC has a higher frame rate than PAL (30 frames or 60 -> fields per second), but a lower resolution (525 rows, with 480 visible). Color depiction in NTSC is realized in -> YIQ. PAL—This is the most common video standard in Europe.
- Page 17 45-50 minutes of video material. The bit rate (audio and video) of an SVCD may not exceed 2.6 Mbps. SVCDs can be viewed using many standalone DVD players. Timeline—The timeline is the time axis upon which you position and edit your video clips. Transition—see Fading Trimming—This refers to adjusting the length of a video clip at the beginning and/or end.
