Leakage clamp-on tester

Advertisement

Quick Links

User's
CL360
Manual
Leakage Clamp-on Tester
リーククランプテスタ
Precautions for Safe Use of the Instrument
When handling the instrument, ALWAYS observe all of the cautionary notes
on safety given below. Yokogawa M&C Corporation is not at all liable for
damage resulting from misuse of this product by the user that is contrary to
these cautionary notes.
Various symbols are used on the instrument and in this manual to ensure the
product is used safety and to protect operators and property from possible
hazards or damage. The following safety symbols are used where appropri-
ate. Read the explanations carefully and familiarize yourself with the symbols
before reading the text.
The instrument and this manual use the following safety symbols:
Danger! Handle with Care.
This symbol indicates that the operator must refer to an explanation
in the User's Manual in order to avoid the risk of personal injury or
death and/or damage to the instrument.
Double Insulation
This symbol indicates double insulation.
AC Voltage/Current
This symbol indicates AC voltage or current.
Ground
This symbol indicates ground (earth)
WARNING
Indicates that there is a possibility of serious personal injury or loss of life if
the operating procedure is not followed correctly and describes the precau-
tions for avoiding such injury or loss of life.
CAUTION
Indicates that there is a possibility of serious personal injury of damage to the
instrument if the operating procedure is not followed correctly and describes
the precautions for avoiding such injury or damage.
NOTE
Draws attention to information essential for understanding the op-
eration and features.
IM CL360
IM CL360
IM CL360
2003.06 2 版(MC)
i
Contents
Precautions for Safety Use of the Instrument --------------------------- i
1. Instrument Layout ------------------------------------------------------------ 1
2. Measurement ------------------------------------------------------------------ 3
2.1
Preparation For Measurement ------------------------------------------------ 3
2.2
Ac Current Measurement ----------------------------------------------------- 3
2.3
How To Use The Frequency Selector Switch ----------------------------- 4
2.4
How To Use Peak Hold Function--------------------------------------------- 5
2.5
2.6
How To Use Data Hold Function ------------------------------------------- 10
2.7
How To Use Output Terminal -------------------------------------------- 10
3. Battery Replacement ------------------------------------------------------ 11
4. Specifications ---------------------------------------------------------------- 12
5. Calibration and After-sales Service ------------------------------------ 15
WARNING
● Never make measurement on a circuit above 600V AC.
● Do not use the instrument in an atmosphere where any flammable or ex-
plosive gas is present.
● Do not attempt to make measurement in the presence of flammable gas-
ses, fumes, vapor or dust. Otherwise, the use of the instrument may cause
sparking, which can lead to an explosion.
● Avoid using the instrument if it has been exposed to rain or moisture or if
your hands are wet.
● Do not exceed the maximum allowabIe input of any measurement range.
● Never open the battery compartment cover when making measurement.
● Do not use the instrument if there is any damage to the casing or when the
casing is removed.
● Do not install substitute parts or make any modification to the instrument.
Return the instrument to Yokogawa M&C or your distributor for repair or
re-calibration.
● Always switch off the instrument before opening the battery compartment
cover for battery replacement.
WARNING
To avoid damage to the instrument or electric shock!
The restrictions on the maximum voltage level for which the CL360 testers
can be used, depend on the over-voltage categories specified by the safety
standards. These category specifications are formulated to protect operators
against transient impulse voltage in power lines.
Function
OVERVOLTAGE
CATEGORY II
AC 1000A rms
A
Measuring circuit voltage :
Over-voltage category I (CAT.I):
Signal level, special equipment or parts of equipment, telecommunication, electronic
etc., with smaller transient over-voltages than CAT.II.
Over-voltage category II (CAT.II)
Local level, appliance, portable equipment etc., with smaller transient over-voltages
than CAT.III.
Over-voltage category III (CAT.III):
Distribution level, fixed installation, with smaller transient over-voltages than CAT.IV.
ii
Maximum Allowable Input
OVERVOLTAGE
CATEGORY III
AC 1000A rms
Measuring circuit voltage :
AC 600V rms
AC 300V rms
IM CL360

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CL360 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for YOKOGAWA CL360

  • Page 1 WARNING When handling the instrument, ALWAYS observe all of the cautionary notes on safety given below. Yokogawa M&C Corporation is not at all liable for ● Never make measurement on a circuit above 600V AC. damage resulting from misuse of this product by the user that is contrary to ●...
  • Page 2 ● Use a damp cloth and detergent for cleaning the instrument. Do not use abrasives or solvents. NOTE ● Radiation immunity affects the accuracy of CL360 testers under the condi- tions specified in EN 61000-4-3:1997. ● If equipment generating strong electromagnetic interference is located nearly, the testers may malfunction.
  • Page 3: Instrument Layout

    To eliminate these superimposed components and measure only in the fundamental fre- quency, Model CL360 has a high-cut filter circuit, which can be activated by setting the frequency selector switch to the 50/60Hz position.
  • Page 4 NOTE ● WIDE (40Hz to over 1kHz) : ● Model CL360 uses an analogue peak hold circuit to ensure a quick re- Covers a wide frequency band from mains supply to high frequencies sponse to input current. Because of the nature of this circuit, the peak hold generated by such equipment as inverters.
  • Page 5: Battery Replacement

    Frequency Can be monitored by connecting a digital multimeter, or a recorder, which Selector Wave at enables many hours of monitoring. With the CL360 in the peak hold mode, 50/60Hz position DC voltage corresponding to 1/ of a peak current value can be held and outputted.
  • Page 6 Should any failure occur while you are using the tester, follow the instructions given below. If the tester still fails to operate correctly and needs repair, con- tact the vendor from whom you purchased the instrument or the nearest Yokogawa M&C sales office. Condition Possible Cause...
  • Page 7 YOKOGAWA CORPORATION OF AMERICA (U.S.A.) Phone: 1-770-253-7000 Facsimile: 1-770-251-2088 YOKOGAWA EUROPE B. V. (THE NETHERLANDS) Phone: 31-334-64-1611 Facsimile: 31-334-64-1610 YOKOGAWA AMERICA DO SUL S. A. (BRAZIL) Phone: 55-11-5681-2400 Facsimile: 55-11-5681-1274 YOKOGAWA ENGINEERING INSTRUMENTS KOREA CORPORATION (KOREA) Phone: 82-2-551-0660 to -0664 Facsimile: 82-2-551-0665 YOKOGAWA AUSTRALIA PTY.
