Cooper Wheelock PRM-150 Specification

PRM-150 Line Level Pre-Amplifi er

Available features and options:

Boosts the audio signal from 600
ohm CO and audio page ports to a
level capable of driving a maximum
of 150 self-amplifi ed speakers
Compensates for audio signal loss
on long cable run
One way paging CO port interface
Contains volume control
24 VDC/25mA
In/Out impedance: 600 ohms/4
ohms
Input level: -15dBM to +10dB
Max audio output level: 0.8 VRMS
Series PRM-150
2.55
5
4
6
3
2
1
0 10
Long Branch, NJ INC.
6-10 06/06
PRM-150 Line Level Pre-Amplifi er
Surface mount
PRM-150
7
4.72
8
9
Order Code
3793
(800) 631-2148 • www.cooperwheelock.com
