Cooper Wheelock XRT-T-40 Overview

Description:
Cooper Wheelock's Explosion Proof Relays are precision built
of extremely rugged materils for long, trouble-free life in hazard-
ous and diffi cult enviornmentjs. Designed primarily for telephone
systems, they sense low voltage AC or DC and switch 115 and
220 volts AC at 60 Hz or 115 volts DC with contact arrangement;
single-pole, normally open, double A (double make in parallel).
The XRT-T-40 has a 0.45 microfared blocking capacitor in series
with the coil and a one megohm resistor across the capacitor.
The XRT-T-40 is FCC registered.
The XRT Explosion Proof Relay is designed to switch high (115
or 220) voltage using low voltage, such as ringing current in
telephone systems, as the controlling voltage. These units can
switch devices controlled by low current controlling systems.
The units are easy to handle and install, and provide convenient
access to coil and contact terminals.
273 Branchport Avenue
Long Branch, NJ 07740
Phone: (800) 631-2148
Fax: (732) 222-2588
www.cooperwheelock.com
Series XRT Explosion Proof Relay
The units are UL listed and CSA approved for the following hazard-
ous atmospheres:
• CLASS I, GROUP C
Atmospheres containing ethyl and ether vapors
• CLASS I, GROUP D
Atmospheres containing gasoline, petroleum, naphtha,
alcohols, acetone, benzene, lacquer solvent vapors, and
natural gas
• CLSSS II, GROUP F
Atmospheres containing carbon black, coal, or coke dust
• CLASS II, GROUP G
Atmospheres containing fl our, starch, and grain dusts
Specifi cation and Ordering Information:
Model Order Operating
Number Code Voltage
XRT-T-40 0221 90V-20 Hz
WE ENCOURAGE AND SUPPORT NICET CERTIFICATION
XRT-T-40
U
L
®
3 YEAR WARRANTY
Made in USA
XRT 5/06
