Cooper Wheelock WFP Installation Instructions

273 Branchport Ave.
Long Branch, N.J. 07740
(800) 631-2148
(800) 397-5777
www.cooperwheelockinc.com
Use this product according to this instruction manual. Please keep this instruction manual for future reference.

GENERAL:

Wheelock's WP-KIT, WFP and WFPA are weatherproof mounting accessories for Wheelock outdoor products.
The WP-KIT allows a customer to surface mount a weatherproof (WP) backbox (IOB, WPBB & WPSBB) to a recessed electrical
box (concealed conduit). The WFP and WFPA kits allow a customer to flush mount WP products (ASWP, MT, MTWP, ET70WP,
RSSWP, AH-12WP, & AH-24WP) without an external WP backbox.
Surface Mount to
Recessed Box
Flush Mount to
Recessed Box

GENERAL APPLICATION NOTES:

1. Please refer to the INSTALLATION INSTRUCTIONS provided for each notification appliance before proceeding with
your installation. These instructions cover the use of WP-KIT, WFPA & WFP ONLY.
2. Use mounting screws supplied with this product and mount to backbox as shown in the figures A-F.
WP-KIT APPLICATION NOTES (Figures A-B):
1. Open rear knockouts in backbox for wire entrance and mounting screws.
2. Insert plugs into the mounting tab slots.
3. Remove the backing from the gasket and affix to the back of the WP backbox. Ensure that gasket is flat and centered.
4. Use mounting screws supplied with this product and mount WP backbox to the recessed backbox in the wall until gasket
compression is even and about half of the original thickness.
5. For rough or uneven wall surfaces apply outdoor graded silicon caulking around gasket (not supplied).
WFPA & WFP APPLICATION NOTES (Figures C-F):
1. Use mounting screws supplied to install the adapter plate to the recessed backbox until plate is near to wall surface.
2. For rough or uneven wall surfaces apply outdoor graded silicon caulking around gasket (not supplied).
3. Continue to tighten screws until adapter plate contacts the wall evenly.
4. Use mounting screws supplied to mount appliance to adapter plate. Tighten until gasket compression is even and about half
of the original thickness.
Copyright 2006 Cooper Wheelock, Inc. All rights reserved.
Thank you for using our products.
INSTALLATION INSTRUCTIONS
WEATHERPROOF KIT (W
WEATHERPROOF FLUSH PLATE AS (WFPA)
WEATHERPROOF FLUSH PLATE (WFP)
Mounting Model/Kit
WP-KIT
WFPA
WFP
P-KIT)
Table 1: Model Code
Used With
IOB, WPBB & WPSBB
ASWP
AH-12WP, AH-24WP, MT-12/24, MTWP, RSSWP,
ET70WP & ET-1010
Mounting
Figure
A, B
C, D, E
F
P84762 B
Sheet 1 of 3
