S6600G-ENG-A
GRAPHIC SCIENTIFIC CALCULATOR
• The contents of this manual are subject to change without
notice.
• No part of this manual may be reproduced in any form
without the express written consent of the manufacturer.
• In no event will the manufacturer and its suppliers being
liable to you or any other person for any damages,
expenses, lost profits, lost savings or any other damages
arising out of use of or inability to use this calculator or
manual.
• In no event will the manufacturer and its suppliers being
liable to you or any other person for any damages,
expenses, lost profits, lost savings or any other damages
arising out of loss of data and/or formulas caused by use
of this calculator or manual.
• Due to limitations imposed by printing processes, the
displays shown in this manual are only approximations
and may differ somewhat from actual displays.
Introduction
Thank you for purchasing the Graphic Scientific
Calculation.
This unit is a totally new type of advanced programmable
calculator. Besides versatile scientific functions, graph
functions also make it possible to produce a wide variety of
useful graphs.
Manual calculations can be easily performed following
written formulas (true algebraic logic). A replay function is
provided that allows confirmation or correction when key
operation errors occur. Programs can also be input by
following true algebraic logic, so repeat and/or complex
calculations are simplified.
All of this power built into a compact configuration that folds
up to slip right into your pocket.
Be sure to carefully read this manual and keep it handy for
future reference.
Important–Reset your calculator before using it for the
first time!––––––––––––––
Important––Always back up data!––––––
This product features electronic memory that is capable of
storing large volumes of data. You must also remember
Page 1
1
8/30/04, 11:05 AM
Adobe PageMaker 6.5C/PPC
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sentry CA756
Summary of Contents for Sentry CA756
- Page 1 GRAPHIC SCIENTIFIC CALCULATOR • The contents of this manual are subject to change without notice. • No part of this manual may be reproduced in any form without the express written consent of the manufacturer. • In no event will the manufacturer and its suppliers being liable to you or any other person for any damages, expenses, lost profits, lost savings or any other damages arising out of use of or inability to use this calculator or...
-
Page 2: Table Of Contents
that your data is safely stored as long as power is being Contents supplied to the memory. Data stored in memory will be ........ About the Power Supply irreparably damaged or lost entirely if you let battery power become too low, if you make a mistake while replacing Battery replacement ..............7 batteries, or if power is cut off. - Page 3 2-2 Special Functions ..........42 ......4. Program Calculations Answer (Ans) function ........42 4-1 What is a Program? ........89 Continuous calculation function ......44 Formulas ............89 Replay function..........45 Programming ............ 89 Error position display function ......46 Program storage ..........
-
Page 4: Battery Replacement
....... Battery Replacement Input Ranges of Functions If the display becomes dim, replace the battery with new ........ Specifications ..135 one according to the following procedures. Battery: CR2032 x 1 1. Turn off the Graphic Scientific Calculator. 2. With a screwdriver, remove the screws of back cover. 3. -
Page 5: Handling Precautions
9.Program clear 10.Input buffer clear 11.Replay memory clear * Never press the RESET button while internal operations are being performed. Doing so can cause irreparable damage to the memory of your calculator. The keys of this unit perform a number of different functions. -
Page 6: About The Display Layout
Program WRT T mode key pressed. key pressed. Sci: Number of significant digits specified. Fix: Number of decimal places specified. hyp: key pressed. Degrees specified at the unit of angular measurement. Radians specified at the unit of angular Exponential display During normal calculation, this unit is capable of displaying measurement. -
Page 7: Special Display Formats
• Sexagesimal value display 1.2x10 11 1 120,000,000,000 indicates that the result is equivalent to 1.2x10 . This means that you should move the decimal point in 1.2 eleven places to the right, since the exponent is positive. This results in the value 120,000,000,000. Special operation keys Shift key 1.2x10... - Page 8 angular measurement is specified as is pressed without entering a value, the current degrees. number of memories available and remaining steps will be displayed. If is pressed, unit of displayed . angular measurement is specified as radians. M-26 S-320 displayed. If is pressed, unit of angular measurement is specified as grads.
- Page 9 pressing displays it from the end. This allows the formula to be executed again by changing the values. Pressing followed by displays the insert cursor ). Entering a value while the insert cursor is displayed inserts the value in the position immediately preceding the insert cursor location.
-
Page 10: Numeric/Decimal Point/Exponent Input Keys
calculation or to advance to the next execution after a calculation result is obtained. Answer/Minus key Pressing followed by will recall the last calculation result. When used during program execution, the last result calculated is recalled. Press following key to entering a numeric value to make that value negative. -
Page 11: Graph Keys
Graph keys • clears the graph display (" done" is Used to produce a variety of graphs. displayed). These keys cannot be used in the BASE-N mode. Function keys Graph/Original zoom key Press for functional calculation. Various uses are available in combination with the key, and/or depending on the •... - Page 12 • When pressed following the key in the BASE-N • When pressed following the key in the BASE-N mode, the subsequently entered value is specified as a mode,the subsequently entered value is specified as an decimal value. octal value. Square/Fraction key Reciprocal/Factorial key •...
-
Page 13: Contrast Adjustment
• Press in the BASE-N mode to enter C (12 ) of a hexadecimal value. Parenthesis keys Trigonometric function/ • Press the open parenthesis key and the closed parenthesis key at the position required in a formula. Inverse trigonometric • When pressed following the key, a comma or function keys . -
Page 14: Calculation Priority Sequence
BASE-N calculations only. or, xor, xnor Pressing any other key besides , or Relational operators < , > , = , * When functions with the same priority are used in series, well as ) cancels contrast adjustment. execution is performed from right to left. * If the display becomes dim and difficult to read, even if In 120 {In( 120)}... -
Page 15: Calculation Modes
Binary, octal, decimal, hexadecimal conversion and calculations, as well as logical operations. Function calculations and graph drawing cannot be performed. 3.SD mode Standard deviation calculation (single-variable statistics). 4. LR mode Regression calculation (paired-variable statistics). With so many modes available, calculations should always be performed after confirming which mode is active. -
Page 16: Overflow And Errors
10 digits and displayed. And the displayed mantissa can be used for the next calculation. 3 x 10 ÷ 7 = * Values are stored in memory with 12 digits for the mantissa and 2 digits for the exponent. Overflow and errors If the calculation range of the unit is exceeded, or incorrect inputs are made, an error message will appear on the display window and subsequent operation will be impossible. -
Page 17: Number Of Input Characters
(5) Mem ERROR (6) Syn ERROR (7) Arg ERROR Besides these, there are a "Ne ERROR" (nesting error) and a "Go ERROR". These errors mainly occur when using programs. Number of input characters This unit features a 127-step area for calculation execution. One function comprises one step. -
Page 18: Corrections
Operations to clear the display depend upon the type of display being shown: Graphs: Text: Pressing the key causes a cleared text display to appear if pressed during a graph display. Corrections • To make corrections in a formula that is being input, use keys to move to the position of the error and press the correct keys. -
Page 19: Memory
If, However, more is to be added to the formula, advance the cursor using the key to the end of the formula for input. • If an unnecessary character has been included in a formula, use the keys to move to the position of the error and press the key. - Page 20 values with 12 digits for a mantissa and 2 digits for an exponent can be stored. To store 123.45 in memory A : Values are assigned to a memory using the followed by the memory name. To store the sum of memory A + 78.9 in memory B : TO add 74.12 to memory B : •To check the contents of a memory , press the name of...
-
Page 21: Memory Expansion
• To store the same numeric value to multiple memories, press followed by To store a value of 10 in memories A through Memory expansion Though there are 26 standard memories, they can be expanded by changing program storage steps to memory. Memory expansion is performed by converting 8 steps to one memory. - Page 22 To initialize the number of memories (to return the number to 26), enter a zero for the value in the memory expansion sequence outlined above. * Though a maximum of 50 memories can be added, if a program has already been stored and the number of remaining steps is less than the desired expansion, an error will be generated.
-
Page 23: Manual Calculations
Manual Calculations Arithmetic operations • Arithmetic operations are performed by pressing the keys in the same sequence as in the formula. • For negative values, press before entering the value. • For mixed arithmetic operations, multiplication and division are given priority over addition and subtraction. -
Page 24: Parenthesis Calculations
Parenthesis calculations... -
Page 25: Memory Calculations
Memory calculations • The contents of memories are not erased when power is off. They are cleared by pressing followed by and then... -
Page 26: Specifying The Number Of Decimal Places, The Number Of Significant Digits And The Exponent Display
Specifying the number of decimal places, the number of significant digits and the exponent display • To specify the number of decimal places, press followed by , a value indicating the number of places (0-9) and then • To specify the number of significant digits, press followed by , a value indicating the number of significant digits (0-9 to set from 1 to 10 digits) and then... -
Page 28: Answer (Ans) Function
Answer function The Answer function stores the result of the most recent calculation. Once a numeric value or numeric expression is entered and is pressed, the result is stored by this function. To recall the stored value, press the key. When pressed, "Ans"... - Page 29 123+456 = 579 789-579 = 210 Numeric values with 12 digits for a mantissa and 2 digits for an exponent can be stored in the Ans memory. The Ans memory is not cleared even if the power of the unit is turned off.
-
Page 30: Continuous Calculation Function
Continuous calculation function Even if calculations are concluded with the key, the result obtained can be used for further calculations. Such calculations are performed with 10-digit mantissa of the displayed value. To calculate ÷ 3.14 after 3 x 4 = 12: To calculate 1 ÷... -
Page 31: Replay Function
Replay function This function stores the latest formula executed. After execution is complete, pressing either the key will display the formula. Pressing will display the formula from the beginning, with the cursor located under the first character. Pressing will display the formula from the end, with the cursor located at the space following the last character. -
Page 32: Error Position Display Function
Error position display function When an ERROR message appears, press to display the calculation with the cursor located at the step that caused the error. You can also clear an error by pressing and then reenter the values and formulas from the beginning. -
Page 33: Angular Measurement Units
* The final result of a multistatement is always displayed, regardless of whether a " " symbol is input at the end of the last statement in the chain. * Consecutive calculations contained in multistatements cannot be performed. Angular measurement units •... -
Page 35: Trigonometric Functions And Inverse Trigonometric Functions
Trigonmetric functions and inverse trigonometric functions • Be sure to set the unit of angular measurement before performing trigonometric function and inverse trigonometric function calculations. • The operations noted below cannot be performed in the BASE-N mode. -
Page 36: Logarithmic And Exponential Functions
Logarithmic and exponential functions • The operations noted below cannot be performed in the BASE-N mode. -
Page 37: Hyperbolic Functions And Inverse Hyperbolic
Hyperbolic funcitions and inverse hyperbolic functions • The operations noted below cannot be performed in the BASE-N mode. -
Page 38: Coordinate Transformation
Coordinate transformation • Your calculator lets you convert between rectangular coordinates and polar coordinates. •Rectangular coordinates •Polar coordinates • Calculation results are stored in variable memory I and variable memory J. Contents of variable memory I are displayed first. To display contents of memory J, press •... -
Page 39: Other Functions
Other functions ( ,x! , ,Ran# , Abs, Int , Frac ) • The operations noted below cannot be performed in the BASE-N mode. -
Page 41: Fractions
Fractions • Fractions are input and displayed in the following order : integer, numerator,denominator. - Page 43 • Binary, octal, decimal and hexadecimal calculations, conversions and logical operations are performed in the BASE-N mode (press • The number system (2,8,10,16) is set by respectively pressing followed by . A A corresponding symbol "b", "o", "d", or "h" appears on the display.
- Page 44 • Negative numbers in binary, octal and hexadecimal are expressed as two's complements. • To distinguish the A, B, C, D, E and F used in the hexadecimal system from standard letters, they appear as shown in the chart below. Binary Positive : 1111111111 Negative : 1111111111...
-
Page 45: Binary, Octal, Decimal, Hexadecimal Calculations
Binary, octal, decimal, hexadecimal conversions Negative expressions... -
Page 46: Basic Arithmetic Operations Using Binary, Octal,Decimal And Hexadecimal Values
Basic arithmetic operations using binary, octal,decimal and hexadecimal values... -
Page 47: Logical Operations
Logical operations Logical operations are performed through logical products (and), logical sums (or), negation (Not), exclusive logic sums (xor), and negation of exclusive logical sums (xnor). -
Page 48: Standard Deviation
Standard deviation • Standard deviation calculations are performed in the SD mode ( ). "SD" appears on the display. • Before beginning calculations, the statistical memories are cleared by pressing followed by and then • Individual data are input using •... -
Page 49: Regression Calculation
* Erroneous data clearing/correction I (Correct data • If only x data is repeated (x data having the same value), operation: 51 enter y data y data followed by a value representing the number of times the If 50 is entered, enter correct data after pressing data is repeated, and then •... -
Page 50: Linear Regression
* Erroneous data clearing/correction ( correct data Linear regression operation: 10 1003 If 11 1003 is entered, enter correct data after pressing If 11 1003 is entered, enter correct data after pressing If 11 1003 was entered previously, enter correct data after pressing 11 1003 Logarithmic regression •... -
Page 51: Exponential Regression
Exponential regression • The regression formula is y = A•e B•x (Iny = InA + Bx). Enter the y data as the logarithm of y(ln), and the x data the same as that for linear regression. • Estimated values , and based on the regression formula can be calculated using the following formulas: •... -
Page 52: Power Regression
Power regression Graphs • The regression formula is y=A•x (lny=InA + BInx). Enter both data x and y as logarithms (In). • Estimated values , and based on the regression formula can be calculated using the following formulas: The COMP mode of the RUN mode should be used when graphing functions. -
Page 53: Range Parameters
the range of the first graph. The first graph is produced each axis, as well as their scales (distance between hash marks). Before drawing a graph, you should first by using the previously mentioned operation ( function specify range parameters to set the size of the graph. key] •... - Page 54 Press to return to the display that was shown before Press to return to the display that was shown before entering the range display. entering the range display. You can input range parameters as expressions (such as • Checking range parameters 2 ) and these expressions are automatically converted to the values.
-
Page 55: User Generated Function Graphs
User generated function graphs After performing range settings, user generated graphs can be drawn simply by entering the function (formula) after pressing Here, let's try drawing a graph for y=2x + 3x -4. * If the maximum and minimum values of an axis are equal, Set the ranges to the values shown below. -
Page 56: Zoom Function
* Be sure to input variable X ( ) into the formula when using built-in graphs for overdraw. If variable X is not included in the second formula, the second graph is produced after clearing the first graph. Zoom function This function lets you enlarge or reduce the x - and y-coordinates. -
Page 57: Trace Function
• Reducing a graph • To specify the zoom factors within a program Use the following formal to specify the zoom factors in a To reduce the graph for y=sinx by a factor of 1.5 on program. the x-axis and 2.0 on the y-axis. Use the following Factor (Xfactor), (Yfactor) range parameters for the original graph. - Page 58 first...
-
Page 59: Plot Function
As you can see above, the Trace and Zoom functions can (including the blinking pointer ) created with the Plot be used to locate the pointer at an approximate point, and function with a straight line. With this function, user generated lines can be added to graphs to make them then produces a readout of the coordinates. -
Page 60: Graph Scroll Function
Next, a perpendicular will be drawn from the same point on the graph to the y-axis. First, plot the point on the graph and use the cursor key ( ) to move the pointer to the y- axis. This can be accomplished using Plot X,Y since the x-y coordinates of the point on the graph are stored in the X and Y memories. -
Page 61: Program Calculations
Program Calculations The following examples are presented to show you some ways that the graphing functions can be used effectively. To graph the function y=x +27x+50 This unit has a built-in program feature that facilitates Use the following range parameters. repeat calculations. -
Page 62: Program Storage
When are pressed,the system mode changes to With this unit,the operations performed for manual the WRT mode.Then,the number of remaining steps is calculations can be used as they are in a program.Once indicated.The number of remaining steps is decreased program execution starts,it will continue in order without when programs are input or when memories are expanded. -
Page 63: Program Execution
After these operations are complete,the program is stored. * Program calculations are performed automatically with each press of when it is pressed after data is input or *After the program is stored,press to return to the after the result is read. RUN mode. -
Page 64: Formulas
Formulas The octahedron program can be changed to a tetrahedron For a surface area S,volume V and one side A, S and V for program by deleting the parts marked with wavy lines,and a regular tetrahedron are defined as: changing those that are marked with straight lines. In actual practice,this would be performed as follows: Programming As with the previous example,the length of one side is... -
Page 65: Debugging When An Error Message Is Generated
After a program has been created and input,it will sometimes generate error messages when it is executed,or it will produce unexpected results.This indicates that there is an error somewhere within the program that needs to be corrected. Such programming errors are referred to as "bugs", while correcting them is called "debugging". -
Page 66: Checkpoints For Each Type Of Error
Mem ERROR (memory error) Arg ERROR Indicates the attempt to use a memory name such as Z Check whether values specified by (Sci) or [5] without having expanded memories. (Fix) are within the range of 0~9. Also check whether Arg ERROR ( Argument error) values specified by Goto, Lbl, or Prog commands are Indicates the argument of a command or specification in within 0-9.Also ensure that memory expansion using... -
Page 67: Program Area And Calculation Mode Specification In The Wrt Mode
Program area and calculation mode specification in the WRT mode At this time, each press of a cursor key will Besides normal function calculations, to perform binary, cause the cursor to move to the next sequential step, For octal, decimal and hexadecimal calculations and example: conversions, standard deviation calculations, and regression calculations in a program, a calculation mode... -
Page 68: Cautions Concerning The Calculation Modes
Cautions concerning the calculation modes All key operations available in each calculation mode can be stored as programs, but, depending on the calculation mode, certain commands of functions cannot be used. BASE-N mode • Function calculations cannot be performed. • Units of angular measurement cannot be specified. •... -
Page 69: Jump Commands
* Hereinafter, commas (,) will be used to separate steps for the sake of clarity, Add “Goto 1” to the end of the program, and add “Lbl 1”to the beginning of program as the branch destination. The programs for this unit are made based upon manual If this is simply left the way it is , however, the volume will calculations. -
Page 70: Conditional Jumps
condition is true, execution advances to the statement Calculate y=ax+b when the value for x following If the condition is not true,the statement changes each time , while a and b can also following is skipped and execution jumps to the change depending upon the calculation. -
Page 71: Count Jumps
then Goto 1 returns execution to Lbl 1. Execution from Lbl 2 will display the sum that has been stored in memory B. Actually, the display command “ ” is inserted following B , but here it can be omitted. The following illustration shows the flow of the program: Increase memory A by one....Isz A A Decrease memory B by one ..Dsz B... -
Page 72: Summary
<Summary> Determine the altitude at one-second intervals of a ball thrown into the air at an initial velocity of Vm/ sec and an angle of S °. The formula is expressed as: h=Vsin t-1/2gt with g=9.8, with the effects of air resistance being disregarded. -
Page 73: Subroutines
Subroutines Simultaneously execute the two previously A program contained in a single program area is called a “ presented programs to calculate the surface main routine” . areas and volumes of a regular octahedron Often used program segments stored in other program and tetrahedron. -
Page 74: Array-Type Memories
of P1, the result of P9 needs no further modification and so Proper utilization of subscripts shortens programs and is immediately displayed upon return to P1. makes them easier to use. Calculation of the volumes is also performed in a similar Negative values used as subscripts are counted in relation manner. -
Page 75: Application Of The Array-Type Memories
A[1] A[2] A[3] A[4] A[5] A [0] A[1] A[2] A[3] A[4] A[5] A[6] A [23] A[24] A[25] A[26] A[27] The content of memory C (A[2]) is decreased from 5 to 0 B[-1] B [0] B[1] B[2] B[3] B[4] B[5] B[22] B[23] B[24] B[25] B[26] in steps of 1. -
Page 76: Symbols
Example program 2 The same memories are used as in Example 1, but two types of memory names are used and the x and y data kept separate. Alphabetic characters, numbers, calculation command , A , : , Defm , 7 , : , symbols, etc, can be displayed as messages. - Page 77 This program calculates the x power of 2. A prompt of “N =? ” appears for data input. The result is displayed by pressing while “x=” is displayed . When an input data is not the x power of 2, the display “ NO “ appears and execution returns to the beginning for reinput .
-
Page 78: Function Reference
Function Reference Program the equation for the first graph. Graph, X, X ,4, -, X, x ,3,-,2,4,X,x ,+, 4, X, +,8,0 Manual Calculations Finally program the equation for the second graph. Graph, 1, 0, X, -,3, 0 Total 27 steps When inputting this program, press after input of the first equation. - Page 81 Program Calculations...
-
Page 82: Error Message Table
Error Message Table... - Page 83 Input Ranges of Functions...
- Page 84 Specifications Graph functions Built-in function (20 types) sin, cos, tan, sin graphs: , tan , sinh, cosh, tanh, sinh , cosh , tanh , log, In, Types of graphs: User generated function graphs Rectangular coordinates Graph functions: Range specification, Overdraw, Trace, Zoom (xf,x , factor, original (resume)), plot, Line,...
- Page 85 Linear regression - number of data, sum of x , sum of y, sum of squares of x, sum of squares of y, mean of x, mean of y, standard deviation of x , standard deviation of y , constant term, regression coefficient, correlation coefficient, estimated value of x, estimated value of y.
