McIntosh MC452 Connection Diagram

1
A
Note: Refer to the MC452 Owner's Manual page 8 for additional connection information.

Connection Legend:

Data Cable*- Digital Signal Cable -
Sensor/Keypad Cable - Network/RS232 Cable -
Power Control Cable* - Ground Wire -
Audio Signal Cable - AC Power Cords -
Video Signal Cable - Loudspeaker Cable -
RF Signal Cable -
*
2 conductor shielded with 1/8 inch stereo mini phone plug on each end.
Right Loudspeaker System
-
+
McIntosh Laboratory, Inc. 2 Chambers Street Binghamton, New York 13903-2699 Phone: 607-723-3512 www.mcintoshlabs.com Part No. 04124300

MC452 Connection Diagram

Connect to
AC Outlet
Audio Preamplifier
Left Loudspeaker System
-
+
