Sharp LQ201U1LW01 Specifications

Tft-lcd module

Advertisement

Quick Links

LQ201U1LW01
TFT-LCD Module
(Model Number: LQ201U1LW01)
Specifications
Spec No.: LD-14115
Dated: May 29, 2002

Advertisement

loading

Summary of Contents for Sharp LQ201U1LW01

  • Page 1 LQ201U1LW01 TFT-LCD Module (Model Number: LQ201U1LW01) Specifications Spec No.: LD-14115 Dated: May 29, 2002...
  • Page 2: Device Specification

    SPEC No. LD-14115 FILE No. ISSUE : Feb.25.2002 APPROVED BY : DATE PAGE : 24 pages TFT LCD DEVELOPMENT GROUP APPLICABLE GROUP SHARP CORPORATION TFT Liquid Crystal Display Group SPECIFICATION DEVICE SPECIFICATION TFT-LCD Module MODEL No. LQ201U1LW01 □ CUSTOMER'S APPROVAL...
  • Page 3 RECORDS OF REVISION LQ201U1LW01 SPEC No. DATE SUMMARY NOTE REVISED PAGE LD-14115 Feb. 25. 2002 1 st Issue...
  • Page 4 ◎These specification sheets are the proprietary product of SHARP CORPORATION(”SHARP) and include materials protected under copyright of SHARP. Do not reproduce or cause any third party to reproduce them in any form or by any means, electronic or mechanical, for any purpose, in whole or in part, without the express written permission of SHARP.
  • Page 5 LD-14115-2 3. Mechanical Specifications Parameter Specifications Unit Display size 51 (Diagonal) 20.1 (Diagonal) Inch 408.0 (H)×306.0 (V) Active area Pixel format 1600 (H)×1200 (V) Pixel (1 pixel=R+G+B dots) Pixel pitch 0.255(H)×0.255 (V) Pixel configuration R,G,B vertical stripe Display mode Normally black 436(W)×335 (H)×27.5 (D) Unit outline dimensions *1 Mass...
  • Page 6 LD-14115-3 4. Input Terminals 4-1. TFT-LCD panel driving CN7A,CN7B (Interface signals and +12VDC power supply) Using connectors :DF19G-20P-1H (Hirose Electric Co., Ltd.) Corresponding connectors :DF19G-20S-1C (Hirose Electric Co., Ltd.) DF19G-20S-1F (Hirose Electric Co., Ltd.) Using LVDS receiver:Contained in a control IC Corresponding LVDS transmitter:THC63LVDM83R(Thine) or compatible CN7A Pin No.
  • Page 7 LD-14115-4    【Note2】 SELLVDS(Thine:THC63LVDM83R) Transmitter SELLVDS Pin No Data R0(LSB) R7(MSB) G0(LSB) G7(MSB) B0(LSB) B7(MSB) (NA) (NA) (RSV1) (RSV1) R0(LSB) R7(MSB) G0(LSB) G7(MSB) B0(LSB) B7(MSB) (NA) (NA)
  • Page 8 LD-14115-5 4-2 Interface block diagram Using receiver:Contained in a control IC. Corresponding Transmitter:THC63LVDM83R(THine electronics),DS90C383,DS90C383A(National semiconductor) (Computer side) (TFT-LCD side) RAIN0+(5) RA0~RA7 RA0~RA7 RAIN0-(6) GA0~GA7 GA0~GA7 RAIN1+(8) BA0~BA7 BA0~BA7 RAIN1-(9) RAIN2+(11) RAIN2-(12) RAIN3+(17) RAIN3-(18) RACLKIN+(14) RACLKIN-(15) A Port B Port RBIN0+(5) RB0~RB7 RB0~RB7 RBIN0-(6)
  • Page 9 LD-14115-6 < SELLVDS= Low > 1 cycle CKAIN+ CK^AIN- RAIN0+ RAIN0- RAIN1+ RAIN1- RAIN2+ RAIN2- RAIN3+ RAIN3- Tcsq CKBIN- CKBIN+ RBIN0+ RBIN0- RBIN1+ RBIN1- RBIN2+ RSV1 RBIN2- RBIN3+ RBIN3- DE: Display Enable RSV1: Reserve (Fixed GND) NA: Not Available...
  • Page 10 LD-14115-7 < SELLVDS= High > 1 cycle CKAIN+ CKAIN- RAIN0+ RAIN0- RAIN1+ RAIN1- RAIN2+ RAIN2- RAIN3+ RAIN3- Tcsq CKBIN- CKBIN+ RBIN0+ RBIN0- RBIN1+ RBIN1- RBIN2+ RSV1 RBIN2- RBIN3+ RBIN3- DE: Display Enable RSV1: Reserve (Fixed GND) NA: Not Available...
  • Page 11 LD-14115-8 4-2. Back light driving CN 1, 2, 3 (Upside) CN 4, 5, 6 (Downside) The module-side connector BHSR-02VS-01 (JST) The user-side connector SM02B-BHSS-1-TB (JST) Pin no. symbol Function V Power supply (High voltage side) high V Power supply (Low voltage side) 1pin CN1...
  • Page 12 LD-14115-9 6. Electrical Characteristics 6-1. TFT-LCD panel driving Ta=25℃ Parameter Symbol Min. Typ. Max. Unit Remark 【Note1】 Supply voltage +11.4 +12.0 +12.6 - 【Note2】 Current dissipation - - Permissive input ripple voltage mVp-p - Input voltage (Low) +0.6 SELLVDS - Input voltage (High) +2.7 +3.3...
  • Page 13 LD-14115-10 6-2. Back light driving The back light system is an edge-lighting type with six CCFTs (Cold Cathode Fluorescent Tube). The characteristics of the lamp are shown in the following table. The value mentioned below is at the case of one CCFT. CCFT Model Name:KTBE26MSTF‐A424NE209‐Z‐3(STANLEY.ELECTRIC.CO.,LTD)...
  • Page 14 LD-14115-11 7. Timing characteristics of input signals 7-1-1. Timing characteristics Parameter Symbol Min. Typ. Max. Unit Remark Clock Frequency 1/Tc 60.0 81.0 85.0 【Note1】 Skew Tcsq –4 Data enable Horizontal period 1080 1600 clock - signal 10.0 13.3 µs Horizontal period (High) clock 【Note2】...
  • Page 15 LD-14115-12 7-2 Input Data Signals and Display Position on the screen Graphics and texts can be displayed on a 1600 × 3× 1200 dots panel with 16M colors by supplying 48 bit data signal (8bit/color [256 gray scales] × 3 × 2 pixels). RA GA BA RB GB BB Two pixel-data are sampled at the same time.
  • Page 16 LD-14115-13 8. Input Signals, Basic Display Colors and Gray Scale of Each Color Data signal Colors & Gray RA0 RA1 RA2 RA3 RA4 RA5 RA6 RA7 GA0 GA1 GA2 GA3 GA4 GA5 GA6 GA7 BA0 BA1 BA2 BA3 BA4 BA5 BA6 BA7 Gray scale Scale RB0 RB1 RB2 RB3 RB4 RB5 RB6 RB7 GB0 GB1 GB2 GB3 GB4 GB5 GB6 GB7 BB0 BB1 BB2 BB3 BB4 BB5 BB6 BB7 -...
  • Page 17: Tft-Lcd-Module

    LD-14115-14 9. Optical Characteristics Ta=25℃, Vcc =+12V Parameter Symbol Condition Min. Typ. Max. Unit Remark θ11 - CR≧10 【Note1,4】 Deg. Viewing Vertical θ12 - range Angle θ21,θ22 - Deg. Horizontal CR θ=0° - - Contrast ratio 【Note2,4】 τd - ms 【Note3,4】...
  • Page 18 LD-14115-15 【Note1】Definitions of viewing angle range: 【Note2】Definition of contrast ratio: The contrast ratio is defined as the following. Luminance (brightness) with all pixels white Contrast Ratio (CR) = Luminance (brightness) with all pixels black 【Note3】Definition of response time: The response time is defined as the following figure and shall be measured by switching the input signal for "black"...
  • Page 19 LD-14115-16 10. Handling Precautions Be sure to turn off the power supply when inserting or disconnecting the cable. Be sure to design the cabinet so that the module can be installed without any extra stress such as warp or twist. Since the front polarize is easily damaged, pay attention not to scratch it.
  • Page 20 LD-14115-17 12.Reliability test items Test item Conditions Ta=60℃ 240h High temperature storage test Low temperature storage test Ta=-25℃ 240h Ta=40℃ ; 95%RH 240h High temperature & high humidity operation test (No condensation) High temperature operation test Ta=50℃ 240h (The panel temp. must be less than 60℃) Low temperature operation test Ta=0℃...
  • Page 21 (the last figures of Serial No. 23 XXXXXX the Christian Era) Lot No. MADE IN JAPAN A production month (1~9,X,Y,Z) 2) Packing Label   ① Model No. (LQ201U1LW01)  ② Lot No. (Date)  ③ Quantity LQ201U1LW01 LQ201U1LW01 LQ201U1LW01 (4S) (4S)LQ201U1LW01 (4S) (4S)...
  • Page 22 LD-14115-19 14.Carton storage condition Temperature 0℃ to 40℃ Humidity 95%RH or less Reference condition : 20℃ to 35℃ , 85%RH or less (summer) : 5℃ to 15℃ , 85%RH or less (winter) ・the total storage time (40℃,95%RH) : 240H or less Sunlight Be sure to shelter a product from the direct sunlight.
