Duncan 67372 Owner's Manual

From serial number 06148
Hide thumbs
Table of Contents

Advertisement

Quick Links

Owners Manual
Vineyard Seeder

From Serial Number 06148

Head Office:
P.O. Box 2018
Hilton Highway, Washdyke
Timaru, New Zealand
Telephone (03) 688 2029
Facsimile (03) 688 2821
Australian Branch:
4B SIlverton Close
Laverton North 3026
Melbourne, Australia
Telephone (03) 9314-9666
Facsimile (03) 9314-6810
Pt. No. 67372
Issue 0806

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 67372 and is the answer not in the manual?

Questions and answers

Summary of Contents for Duncan 67372

  • Page 1: From Serial Number

    Head Office: Australian Branch: P.O. Box 2018 4B SIlverton Close Hilton Highway, Washdyke Laverton North 3026 Timaru, New Zealand Melbourne, Australia Telephone (03) 688 2029 Telephone (03) 9314-9666 Facsimile (03) 688 2821 Facsimile (03) 9314-6810 Pt. No. 67372 Issue 0806...

  • Page 3: Table Of Contents

    Maintenance Notes ....30 Parts Lists ....... 31 Pt. No. 67372 Issue 0806...

  • Page 4: Acquisition And Warranty

    Introduction Acquisition & Warranty On delivery of your new Duncan Ag Vineyard Seeder please check that the machine is not damaged. In cases of shipping damage, please ask your dealer to arrange for the appropriate claim to be lodged immediately. Assemble any parts supplied loose and inspect your machine with the aid of this manual to familiarise yourself with its features.

  • Page 5: Description Of Machine

    Description of Machine The Duncan Ag Vineyard Seeder is either a single curved disc or double disc drill with dual boxes for seed and fertilizer. The drill is carried and operated from the three point linkage of the tractor. The sowing depth control is achieved from two trailing wheels with individual wheel retraction stops.

  • Page 6: Safety Symbols On Machine

    ATTENTION On the machine important safety information is indicated by these symbols. These highlight general safety aspects in regard to the machine rather than specific hazards. Do not ride or allow passengers on the machine. Under no circumstances are passengers to be permitted on the machine while it is in operation or being transported.

  • Page 7: Safety - General

    Duncan Ag has made every effort to highlight all risks to personnel or property. Owners and operators have a A prohibition should responsibility to exercise care and safe work practices at be observed under all all times in the vicinity of the machine.

  • Page 8: Appropriate Dress

    SAFETY - General (Continued) Appropriate Dress Wear close fitting clothing and avoid rings or other forms of jewellery which could become caught in the machinery. People with long hair must have it securely fixed and confined close to the head. Refer to local safety standards for protective clothing and recommended safety equipment.

  • Page 9: Handle Agricultural Chemicals Safely

    Check that the guards have been securely fitted and that any adjustments have been made correctly. Where possible, disconnect or isolate the drive mechanism to the implement. Lower the machine onto the ground when not in use. Pt. No. 67372 Issue 0806...

  • Page 10: Practise Safe Maintenance

    SAFETY - General (Continued) Practise Safe Maintenance Keep the machine in safe working condition. Routine maintenance and regular servicing will help reduce risks and prolong the life of the machine. General Maintenance Accidents occur most frequently during servicing and repair. The following general rules must be followed when maintaining or working with machinery: •...

  • Page 11: Safety - Machine Specific

    Slippery When Wet Hazardous areas include: • Footboard. • All smooth surfaces on the frame structure. Keep Clear Hazardous areas include: • Between the tractor and Vineyard Seeder. • Immediately adjacent to the Vineyard Seeder side. Pt. No. 67372 Issue 0806...
  • Page 12 SAFETY - Machine Specific (Continued) Hazard Points on the Vineyard Seeder (Continued) Guards Gearbox deflection and flap handle guards are provided to avoid grape vines getting caught up in componentry. They also assist in preventing hands getting caught up in sprockets, drive chains and chain tensioners.

  • Page 13: Safety Decals & Safety Guards

    ‘Slippery When Wet’ Refer Page 10 & 33 ‘Keep Clear’ Refer Page 10 & 33 Arrows Refer Page 33 Gearbox Deflection Guard Refer Page 10 & 33 Flap Handle Guard Refer Page 10 & 33 ‘40 km/hr’ Pt. No. 67372 Issue 0806...

  • Page 14: Transport

    Transport Raise the three point linkage as high as possible to maximise ground clearance. Ensure ground clearance is sufficient. Do not transport with the wheels in contact with the ground. Ensure that all linkage pins and security clips are fitted and are secure.
  • Page 15 If possible use a floating top link. When sowing over ridges the drive wheel may loose contact with the ground temporary. Fig 2 Disc penetration ability will improve as discs sharpen with initial use. Pt. No. 67372 Issue 0806...

  • Page 16: Sowing Chart

    Vineyard Seeder Sowing Chart Row Spacing 180 Seed Rate (kg/ha) Test Seed Type/ Thousand Seed Hints Gearbox Setting Position Wgt., TSW*(gm) Position Type Wheat (41.2) 82.22 103.66122.65144.91167.63 188.64 Oats Full (37.2) 79.67 98.98 117.82 138.24158.57 176.73 Barley Full (45.7) 94.71 116.69 141.94165.34190.38 214.3 Ryecorn (25.8) 95.76 119.16 143.69166.88193.88 218.10...

  • Page 17: Basic Calibration Procedure

    Sowing Chart. The control levers are located on the LH end of the seedbox, (opposite end to the gearbox). Number “1” corresponds to the minimum (closed) position and “10” the maximum gap (Fig 5). Fig 5 Pt. No. 67372 Issue 0806...

  • Page 18: Seed Calibration

    Basic Calibration Procedure (Continued) Seed Calibration The calibration test should be done to confirm the required seed rate and is done with the drill stationary and level. Seed Calibration Procedures Remove the calibration tray from the storage brackets on the seedbox. Place the calibration tray (1) adjacent to the seeder units (Fig 6).
  • Page 19 11 Where a coated seed is used it is advisable to check the calibration after 1 hectare as dressings can tend to create a coating on the seed metering wheels thus changing the the flowing properties of the seed which in turn alters the seed rate. Pt. No. 67372 Issue 0806...

  • Page 20: Recalculating The Constant

    Basic Calibration Procedure (Continued) Recalculating the Constant It is especially important in arable situations to check the rolling circumference of the tyre when in the cultivated area to be sown, and if necessary, to recalculate the constant and hence the number of crank turns.

  • Page 21: Calibration Deviations

    69.4m, place the crank handle over the hexagonal drive dog on the gearbox. Move the machine forward over the measured distance, counting the number of turns of the crank handle as you go. Using this number of crank turns repeat the calibration. Pt. No. 67372 Issue 0806...

  • Page 22: Sowing Of Fine Seeds

    Basic Calibration Procedure (Continued) Sowing Fine Seeds For sowing fine seeds the Vineyard Seeder is equipped as standard with a combined normal and fine seed “Elite” metering wheel (1). During grain sowing and other larger varieties of seed both the normal and fine seed metering wheels are coupled and both rotate.

  • Page 23: Sowing Small Seeds

    Sowing Small Seeds Calibration with Disconnected Agitator Shaft The fine seed metering wheel used in Duncan Drills is especially well suited for sowing small seeds such as rape. Due to the intensive action caused by the agitator the seeds can adhere to each other, or be damaged, causing irregular sowing/germination.

  • Page 24: Sowing Peas

    Peas having the size and shape as illustrated in Fig 13 (e.g. White Field Peas), can be sown without problems with all Duncan Drills with this type of metering wheel. The flap should be set to a gap of at least “3” on the flap setting lever (Page 15, Fig 3).
  • Page 25 It is advisable as with all things electronic to have a backup of your totals. We suggest you record these on a daily basis in a notebook or diary. Pt. No. 67372 Issue 0806...

  • Page 26: Calibration Notes

    Vineyard Seeder Calibration Notes...

  • Page 27: General

    Caution must be exercised. Box set lifting eye profile - these profiles are are provided for easy removal of the dual boxes from the pedestals. Do not use when boxes are loaded nor to lift the machine. Pt. No. 67372 Issue 0806...

  • Page 28: Maintenance & Care

    Maintenance & Care Lubrication Points on the Vineyard Seeder Lubrication Instructions Your new Duncan Ag Vineyard Seeder will give long and efficient service if given normal care and maintained properly Lubrication Precautions Keep the service area clean and dry. Only service or lubricate the machine...

  • Page 29: Maintenance Schedule

    For refilling the oil remove the 1/2” BSP plug on the top face of the gearbox (2), Castrol Oil Agri Trans Plus should be used. The total filling capacity is 1.25 litres (refer Fig 18). DO NOT OVERFILL. Fig 18 Pt. No. 67372 Issue 0806...
  • Page 30 Maintenance & Care Maintenance Schedule (Continued) 3 Roller Chains Pedestal and agitator drive chains (1) Fig 19 & (2) Fig 21 should first be checked after 20 hours of operation and thereafter every 200 hours of operation as follows:- Remove the chain, wash in kerosene and then dip them in heated grease or oil or spray them with a suitable commercial...

  • Page 31: Storage

    Check tube lengths when replacing. It is recommended that maintenance be carried out at the end of the season, giving sufficient time to obtain spare parts and/or carry out repairs if required. Pt. No. 67372 Issue 0806...

  • Page 32: Maintenance Notes

    Vineyard Seeder Maintenance Notes...

  • Page 33: From Serial Number

    Head Office: Australian Branch: P.O. Box 2018 4B Silverton Close Hilton Highway, Washdyke Laverton North 3026 Timaru, New Zealand Melbourne, Australia. Telephone (03) 688 2029 Telephone (02) 9314-9666 Facsimile (03) 688 2821 Facsimile (02) 9314-6810 Pt. No. 67372 Issue 0806...
  • Page 34 Vineyard Seeder Complete Assembly 28 35 36 37...
  • Page 35 Decal Arrow (36mm x 24mm) 43904 Decal ‘Keep Clear’ (128mm x 25mm) 27375 Jack Stand Assembly 17439 Jack Lock Pin 45271 R Clip 43912 Decal ‘40 km/hr’ *See SAFETY - Machine Specific (Page 11) for Decal Locations Pt. No. 67372 Issue 0806...
  • Page 36 Vineyard Seeder Mainframe & Wheel Leg Arrangment 14 15 12 13...
  • Page 37 Wheel Retraction Stop 27738 Wheel Retraction Stop (Alternative) 11760 Buffer Block (Complete with M6 Nyloc) 19093 Clamp Plate Assembly 16164 45271 R Clip Note: Item 16 (27738) is available to give greater lift (70mm approximately) Pt. No. 67372 Issue 0806...
  • Page 38 Vineyard Seeder Wheel Leg & Axle Assembly...
  • Page 39 Wheel Bearing 18611 Axle Oil Seal 43007 1/4” UNF Grease Nipple 11361 Hub Cap 45143 M24 H/D Flat Washer 27743 Drive Axle Spacer 27747 Leg Pivot Shaft 45186 M10x12 S/H Grub Screw 45141 M24 Nyloc Nut Pt. No. 67372 Issue 0806...
  • Page 40 Vineyard Seeder Single Disc Dragbars...
  • Page 41 M10 Spring Washer φ 27460 Corrugated Hose 38x540 (Not shown) φ 27461 Corrugated Hose 38x605 (Not shown) φ 27462 Corrugated Hose 38x630 (Not shown) φ 27463 Corrugated Hose 38x655 (Not shown) 27280 Single Coulter Front Frame Assy Pt. No. 67372 Issue 0806...
  • Page 42 Vineyard Seeder Double Disc Dragbars...
  • Page 43 45131 M12 Plain Nut 27377 Dragbar Axle Assy φ 27460 Corrugated Hose 38 x 540 (Not shown) φ 27461 Corrugated Hose 38 x 605 (Not shown) φ 27463 Corrugated Hose 38 x 655 (Not shown) Pt. No. 67372 Issue 0806...
  • Page 44 Vineyard Seeder Complete Drive Arrangement...
  • Page 45 1/2” BS Chain x 47 Links (Gearbox to Boxshaft) 22294 Sprocket Key (6 x 6 x 25) 45180 M8 x 10 Socket Head Grub Screw Refer Page 44 Front Box Shaft Chain Tensioner Refer Page 45 Rear Box Shaft Chain Tensioner Pt. No. 67372 Issue 0806...
  • Page 46 Vineyard Seeder Front Box Shaft Chain Tensioner Item Part No. Description Qty. 22535 Nylon Roller 22480 RH Arm Assembly 22522 LH Torsion Spring 23376 Chain Tensioner Anchor 45132 M16 Half Nut 45461 M16x65 Bolt...
  • Page 47 Vineyard Seeder Rear Box Shaft Chain Tensioner Item Part No. Description Qty. 22535 Nylon Roller 22480 RH Arm Assembly 22523 RH Torsion Spring 23376 Chain Tensioner Anchor 45132 M16 Half Nut 45461 M16x65 Bolt Pt. No. 67372 Issue 0806...
  • Page 48 Vineyard Seeder Gearbox Input Drive System Item Part No. Description Qty. 26568 Hexagonal Drive Shaft (Left Hand Thread) 43876 Drive Cassette 21/21T 27764 Hexagonal Transfer Drive Shaft 43858 Drive Cassette 17/21T 27745 Cassette Drive Axle 27737 Cassette Drive Spacer 45155 M20 Light Flat Washer 45403S M6 x25 Set Screw...
  • Page 49 Housing, Bearing, Press Steel, PFT47 (2 Flanges = 1 Housing) 45137 Nut, M8, Nyloc 45181 Grubscrew, M8 x 12, Socket Head 45411S Set Screw, M8 x 20, Zinc Plate Locking Collar (Part of item 4 and not supplied separately) Pt. No. 67372 Issue 0806...
  • Page 50 Vineyard Seeder Gearbox Final Assembly 14, 15, 16, 17...
  • Page 51 Bolt, M8 x 20 Class 4.6, Zinc Plated 45151 Washer, Flat, M8, Light 25762 Gearbox Final Assembly (Includes items 1 to 13 and items 15, to 17) 27341 Crank Adaptor (Not Illustrated) 22294 Sprocket Key (Not Illustrated) Pt. No. 67372 Issue 0806...
  • Page 52 Vineyard Seeder Seedbox Assembly 25, 33, 35 7, 27, 21 Lid Hinge Detail Location Tab Detail 14, 29 13, 29 25, 30, 33, 17, 21, 28 Latch Rod Detail 25, 33, 36 Gearbox not illustrated for clarity...
  • Page 53 45433S M12 x 30 Set Screw Refer Page 52 Front Agitator Drive Assembly Refer Page 52 Rear Agitator Drive Assembly 45907 M6 x 12 Pan Head Pozi Drive M/C Screw 43726 Transfer - Vineyard Seeder Pt. No. 67372 Issue 0806...
  • Page 54 Vineyard Seeder Agitator Drives Item Part No. Description Qty.* 22414 Agitator Drive Rear Housing 22415 Agitator Drive Front Housing 22416 Agitator Drive Spacer 22418 3/8” Pitch x 20mm Bore 21T Sprocket 22422 3/8” Pitch x 20mm Bore 15T Sprocket 22417 3/8”...
  • Page 55 M8 x 16 Grade 316 Stainless Steel Set Screw 45137SS M8 Grade 316 Stainless Steel Nyloc Nut 47600 M30 ISO Fine Zinc Plated Hex Lock Nut *Quantities shown are sufficient for one box Plain (RH) End Centre Bearing Drive (LH) End Pt. No. 67372 Issue 0806...
  • Page 56 Vineyard Seeder Seeder Mechanism...
  • Page 57 Hectaremeter Kit, (Includes items 2 to 6) 43400 Hectaremeter 43408 Hectaremeter Manual 43404 Magnet and Clamp 43403 Sensor, with Locknuts 43453 Hectaremeter Cable 43461 Recharging Cable 43894 Electronic Scales (Not shown) 43456 Calculator (Not shown) 43457 Sealtop Plastic Container (Not shown) Pt. No. 67372 Issue 0806...
  • Page 58 Vineyard Seeder Press Wheel Arrangement Note position of RH Press Wheel Arm...
  • Page 59 (shown), except for the hand of the arm assembly. Note the location of the right hand press wheel system on the layout (Page 56). Note: Press wheel arrangement available only for double discs Pt. No. 67372 Issue 0806...
